Across 7 measurable specs, the LS Tractor MT463 leads 4 categories to 3. Machine pages: Case IH Farmall 65C and LS Tractor MT463.
Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.
Category Verdict
| Spec | Case IH Farmall 65C | LS Tractor MT463 |
|---|
| Engine HP (hp) | ▲ 64 hp | 63 hp |
| PTO HP (hp) | 50 hp | ▲ 54.1 hp |
| Weight (lb) | ▲ 6,548 lb | 5,313 lb |
| Loader Lift (lb) | 2,734 lb | ▲ 3,426 lb |
| 3-Pt Lift (24 in) (lb) | ▲ 3,956 lb | 3,483 lb |
| Lift Height (in) | 105 in | ▲ 132.9 in |
| Breakout Force (lbf) | 3,527 lbf | n/a |
| Hydraulic Flow (gpm) | 12.9 gpm | ▲ 21.1 gpm |
The headline numbers at a glance.
Case IH Farmall 65CLS Tractor MT463
ITCUSA.COMITCUSA.COMITCUSA.COM
Weightlb
6,063 lb
▲6,548 lb
5,313 lb
Cab 2WDCab MFD
Share↓ Image𝕏f✉ Full Spec Sheet
Every published spec, side by side, including the details the graphs above don't chart.
| Spec | Case IHFarmall 65C | LS TractorMT463 |
|---|
|
|---|
| Engine Manufacturer | FPT | LS Mtron |
|---|
| Engine Model | Not Published | L4C25-T |
|---|
| Engine Type | Turbocharged diesel | In-line vertical, water cooled 4-cycle diesel, CRDI |
|---|
| No. of Cylinders | 4 | 4 |
|---|
| Displacement | 207 in³ | 152.85 in³ |
|---|
| Rated Engine Speed | 2300 rpm | 2500 rpm |
|---|
| Engine Power (Gross) | 64 hp | 63 hp |
|---|
| PTO Power | 50 hp | 54.1 hp |
|---|
| Engine Emissions Constraints | Tier 4 | Tier 4 |
|---|
| Cooling System Type | Not Published | Water-cooled |
|---|
| Air Cleaner | Not Published | Dry |
|---|
| Fuel System | Common rail | Delphi, CRDI |
|---|
| Alternator | Not Published | 70 A, 12 V |
|---|
|
|---|
| Pump Type | Dual gear pumps | Gear type, engine drive |
|---|
| Implement Flow | 12.9 gpm | 14.5 gpm |
|---|
| Steering Flow | 7.3 gpm | 6.6 gpm |
|---|
| Total Hydraulic Flow | Not Published | 21.1 gpm |
|---|
| Overall Hydraulic Pump Flow | Not Published | 21.1 gpm |
|---|
| Hydraulic System Type | Open center | Open center |
|---|
| Rear Remote Hydraulic Flow | Not Published | Not Published |
|---|
| No. of Standard Remote Valves | 2 | 2 Pairs (Front), 2 Pairs (Rear) |
|---|
| No. of Optional Remote Valves | 3 | Not Published |
|---|
|
|---|
| Fuel Tank Capacity | 23.8 gal | 24.3 gal |
|---|
| Coolant Capacity | Not Published | 3.0 gal |
|---|
| Crankcase Capacity | Not Published | 1.8 gal |
|---|
| Transmission / Hydraulic System Capacity | Not Published | 16.5 gal |
|---|
| Front Axle Fluid Capacity | Not Published | 2.3 gal |
|---|
|
|---|
| PTO Type | Independent | Independent |
|---|
| PTO Rear | 540 rpm (540/540E optional) | 540 / 540E |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | Category I/II | Category II |
|---|
| Hitch Lift Capacity | Not Published | 4,079 lb |
|---|
| Hitch Lift Capacity (at 24”) | 3,956 lb | 3,483 lb |
|---|
| Lift Control Type | Mechanical draft control (MDC), top link sensing | Position & Draft |
|---|
|
|---|
| Transmission Type | Standard: 12x12 power shuttle (wet clutch); Optional: 12x12 power shuttle (wet clutch) with creeper (20x20) | Synchro Shuttle |
|---|
| No. of Speeds | Standard: 12 forward / 12 reverse; Optional creeper: 20 forward / 20 reverse | F16 x R16 |
|---|
| Max Travel Speed (Forward) | Not Published | Not Published |
|---|
| Max Travel Speed (Reverse) | Not Published | Not Published |
|---|
| Clutch | Wet clutch | Dry single clutch |
|---|
| Differential Lock & Limited Slip Options | Mechanical rear differential lock; limited-slip MFD front axle | Mechanical differential lock (pedal) |
|---|
|
|---|
| Frame Type | Not Published | Not Published |
|---|
| Steering | Hydrostatic power steering | Hydrostatic Power Steering |
|---|
| Brakes | Hydraulic wet disc | Wet, Multi-disc |
|---|
| Seat Suspension & Adjustability | Not Published | Seat With Suspension & Armrest |
|---|
| Front Axle Type | 2WD: 2WD front axle; MFD: MFD with limited slip, electrohydraulic engagement | Not Published |
|---|
| Front Axle Rating | Not Published | Not Published |
|---|
| Drawbar Capacity | Not Published | Not Published |
|---|
|
|---|
| Overall Length with 3-Point Hitch | 145.8 in | 140 in |
|---|
| Overall Width | 76 in | 72.6 in |
|---|
| Wheelbase | 2WD: 85.8 in; MFD: 84 in | 83.1 in |
|---|
| Ground Clearance | Not Published | Not Published |
|---|
| Min. Turn Radius without Brakes | Not Published | 12.8 ft (3.9 m) |
|---|
| Height to Top of ROPS | Not Published | 113.9 in |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | 98 in | Not Published |
|---|
|
|---|
| Tractor Weight (Base) | Cab 2WD: 6,063 lb; Cab MFD: 6,548 lb | 5,313 lb |
|---|
| Weight with ROPS and Loader | Not Published | 6,503 lb |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | 18.4R34 rear | Standard Ag 9.5-24 / 16.9-28; Industrial 10.5/80x18 10PR / 19.5Lx24 8PR; Large Ag 11.2-24 / 16.9-30; R14 320/85R20 119D / 420/75R34 142D |
|---|
| R1 Agricultural - Front | Not Published | 9.5-24 (Standard Ag); 11.2-24 (Large Ag) |
|---|
| R1 Agricultural - Rear | Not Published | 16.9-28 (Standard Ag); 16.9-30 (Large Ag) |
|---|
| R3 Turf - Front | Not Published | Not Published |
|---|
| R3 Turf - Rear | Not Published | Not Published |
|---|
| R4 Industrial - Front | Not Published | 10.5/80x18 10PR |
|---|
| R4 Industrial - Rear | Not Published | 19.5Lx24 8PR |
|---|
|
|---|
| Quick Attach Loader System | Compatible with L565 loader | LL5001: Standard Quick-Attach, Skid-Steer Compatible (SSQA) |
|---|
| Loader Model | L565 | LL5001 |
|---|
| Loader Lift Height | 105 in | LL5001: 132.9 in (height position); 116.8 in (power position) |
|---|
| Loader Lift Capacity (Full Height) | 2,734 lb | LL5001: 3,426 lb (height position); 3,488 lb (power position) |
|---|
| Loader Breakout Force | 3,527 lb | Not Published |
|---|
|
|---|
| Warranty Length & Coverage | Not Published | 6-year / 1,500-hour limited powertrain warranty; 2-year / 750-hour bumper-to-bumper warranty |
|---|
Case IH Farmall 65C vs LS Tractor MT463: Quick Answers
- Which has more horsepower, the Case IH Farmall 65C or the LS Tractor MT463?
- The Case IH Farmall 65C leads on engine hp at 64 hp hp, compared to 63 hp hp for the LS Tractor MT463.
- Which has more PTO horsepower, the Case IH Farmall 65C or the LS Tractor MT463?
- The LS Tractor MT463 leads on pto hp at 54.1 hp hp, compared to 50 hp hp for the Case IH Farmall 65C.
- Which is heavier, the Case IH Farmall 65C or the LS Tractor MT463?
- The Case IH Farmall 65C leads on weight at 6,548 lb lb, compared to 5,313 lb lb for the LS Tractor MT463.
- Which has more loader lift capacity, the Case IH Farmall 65C or the LS Tractor MT463?
- The LS Tractor MT463 leads on loader lift at 3,426 lb lb, compared to 2,734 lb lb for the Case IH Farmall 65C.
- Which has more three-point hitch lift capacity, the Case IH Farmall 65C or the LS Tractor MT463?
- The Case IH Farmall 65C leads on 3-pt lift (24 in) at 3,956 lb lb, compared to 3,483 lb lb for the LS Tractor MT463.
