John Deere 3025E vs Kioti CK2610

Across 8 measurable specs, the Kioti CK2610 leads 8 categories to 0. Machine pages: John Deere 3025E and Kioti CK2610.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	John Deere3025E	KiotiCK2610

▶Engine
Engine Manufacturer	Yanmar	KIOTI (Daedong)
Engine Model	3TNV88F-EPJT2	CK2610: 3A165LWM-U; CK2610 HST: 3A165LWH-U
Engine Type	Diesel, naturally aspirated, direct injection	3 cylinder, in-line vertical, water-cooled 4-cycle diesel
No. of Cylinders	3	3
Displacement	100.2 in³	100.5 in³
Rated Engine Speed	2400 rpm	2600 rpm
Engine Power (Gross)	24.4 hp	24.5 hp
PTO Power	19.4 hp	CK2610: 21.7 hp; CK2610 HST: 21.5 hp
Engine Emissions Constraints	Tier 4	Tier 4
Cooling System Type	Water pump	Water-cooled
Air Cleaner	Dry type with safety element	Not Published
Fuel System	Direct injection	Not Published
Alternator	55 A, 12 V	Not Published
▶Hydraulics
Pump Type	Implement/steering pump: tandem gear pump; hydrostatic pump: PV axial-piston pump	Gear
Implement Flow	5.3 gpm	Not Published
Steering Flow	4.0 gpm	Not Published
Total Hydraulic Flow	9.3 gpm	11.7 gpm
Overall Hydraulic Pump Flow	9.3 gpm	11.7 gpm
Hydraulic System Type	Open center	Open center
Rear Remote Hydraulic Flow	Not Published	Not Published
No. of Standard Remote Valves	Not Published	None (2 optional)
No. of Optional Remote Valves	Up to 2 (optional)	2 (4 ports)
▶Fluid Capacity
Fuel Tank Capacity	7.5 gal	9 gal
Coolant Capacity	5.2 qt	Not Published
Crankcase Capacity	4.5 qt	Not Published
Transmission / Hydraulic System Capacity	5.5 gal	Not Published
Front Axle Fluid Capacity	4 qt	Not Published
▶PTO & Hitch
PTO Type	Not Published	Live
PTO Rear	540 rpm	540 rpm
Mid-PTO Availability	Not Published	Optional, 2,000 rpm
Category, 3-Point Hitch	Category I	Category I
Hitch Lift Capacity	Not Published	Not Published
Hitch Lift Capacity (at 24”)	1,356 lb	1,631 lb
Lift Control Type	Not Published	Position control
▶Transmission & Drivetrain
Transmission Type	Hydrostatic transmission (HST)	CK2610: Manual; CK2610 HST: Hydrostatic
No. of Speeds	Not Published	CK2610: 9F/3R; CK2610 HST: Infinite, 3 range
Max Travel Speed (Forward)	Not Published	CK2610: 10.08 mph; CK2610 HST: 10.31 mph
Max Travel Speed (Reverse)	Not Published	CK2610: 6.58 mph; CK2610 HST: 9.25 mph
Clutch	Not Published	CK2610: Dry dual stage; CK2610 HST: Dry single stage
Differential Lock & Limited Slip Options	Not Published	Rear differential lock (standard)
▶Chassis, Steering & Controls
Frame Type	Open operator station (OOS)	Not Published
Steering	Power steering	Hydrostatic power steering
Brakes	Wet disc	Wet multi-disc
Seat Suspension & Adjustability	Not Published	Not Published
Front Axle Type	4WD (MFWD)	4WD, mechanical engagement (standard)
Front Axle Rating	1,760 lb	Not Published
Drawbar Capacity	880 lb (maximum vertical load)	Not Published
▶Dimensions & Maneuverability
Overall Width	56.9 in (min. rear tread, standard R1 tires); 61.7 in (max. rear tread, larger R4 tires)	54.5 in
Wheelbase	62.8 in	65.7 in
Ground Clearance	12.7 in (R4 tires)	13.4 in
Min. Turn Radius without Brakes	Not Published	8 ft (with brake applied)
Height to Top of ROPS	95.3 in	99.2 in
Height to Top of ROPS (folded)	Not Published	Not Published
Height to Top of Cab Model	Not Published	Not Published
Overall Length	115.9 in (with 3-point hitch)	120.9 in (with 3-point hitch)
▶Weight
Tractor Weight (Base)	2,222 lb	CK2610: 2,646 lb; CK2610 HST: 2,701 lb
Weight with ROPS and Loader	2,972 lb	Not Published
Weight with Cab and Loader	Not Published	Not Published
▶Tire Options
Tire Size & Options	R1 Bar, R3 Turf, R4 Industrial	Front AG 7-16 (Turf 28x8.5-15/6, Industrial 27x8.5-15); Rear AG 11.2-24 (Turf 41x14-20/4, Industrial 15-19.5)
R1 Agricultural - Front	7-14	7-16
R1 Agricultural - Rear	11.2-24	11.2-24
R3 Turf - Front	27X8.50-15	28x8.5-15/6
R3 Turf - Rear	41X14-20	41x14-20/4
R4 Industrial - Front	25X8.50-14 or 27X8.50-15	27x8.5-15
R4 Industrial - Rear	15-19.5 or 43x16-20	15-19.5
▶Loader & Attachments
Quick Attach Loader System	Quick-change attachment carrier	Quick-attach (QA) bucket
Loader Model	300E	KL2610
Loader Lift Height	84 in (at pivot pin)	98.4 in (KL2610 loader)
Loader Lift Capacity (Full Height)	1,186 lb (at pivot pin)	KL2610: 1,252 lb (at pivot pin)
Loader Breakout Force	1,704 lb (at pivot pin)	KL2610: 2,110 lb (at pivot pin)
▶Warranty
Warranty Length & Coverage	Basic 24 months or 2,000 hours; powertrain 72 months or 2,000 hours	Not Published
▶ITC Company Accessories
Accessories that fit	None tagged yet	Brush Guard Side Guards $199.99 Bolt onto the side of the OEM guard and offers wrap around protection Kioti CK2610/20 CK3510/20 CK4010/20 Brush Screen Insert $250.00 Kioti DK10/20 & CK10/20 with 6 bolt Grill Guard Brush Screen Insert $250.00

Find a John Deere dealer near you→Find a KIOTI dealer near you→

John Deere 3025E vs Kioti CK2610: Quick Answers

Which has more horsepower, the John Deere 3025E or the Kioti CK2610?

The Kioti CK2610 leads on engine hp at 24.5 hp hp, compared to 24.4 hp hp for the John Deere 3025E.

Which has more PTO horsepower, the John Deere 3025E or the Kioti CK2610?

The Kioti CK2610 leads on pto hp at 21.7 hp hp, compared to 19.4 hp hp for the John Deere 3025E.

Which is heavier, the John Deere 3025E or the Kioti CK2610?

The Kioti CK2610 leads on weight at 2,701 lb lb, compared to 2,222 lb lb for the John Deere 3025E.

Which has more loader lift capacity, the John Deere 3025E or the Kioti CK2610?

The Kioti CK2610 leads on loader lift at 1,252 lb lb, compared to 1,186 lb lb for the John Deere 3025E.

Which has more three-point hitch lift capacity, the John Deere 3025E or the Kioti CK2610?

The Kioti CK2610 leads on 3-pt lift (24 in) at 1,631 lb lb, compared to 1,356 lb lb for the John Deere 3025E.
