John Deere 5060E vs John Deere 5067E

Every published spec for both machines, side by side. The verdict below is computed straight from the spec sheets, not opinion.

Across 9 measurable specs, the John Deere 5067E leads 3 categories to 0 (6 tied). Machine pages: John Deere 5060E and John Deere 5067E.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Spec	John Deere 5060E	John Deere 5067E
Engine HP (hp)	60 hp	▲ 67.6 hp
PTO HP (hp)	45.6 hp	▲ 53 hp
Weight (lb)	5,445 lb	▲ 5,555 lb
Loader Lift (lb)	2,453 lb	2,453 lb
3-Pt Lift (24 in) (lb)	3,192 lb	3,192 lb
Lift Height (in)	113 in	113 in
Breakout Force (lbf)	4,781 lbf	4,781 lbf
Hydraulic Flow (gpm)	18.2 gpm	18.2 gpm
Travel Speed (mph)	15.5 mph	15.5 mph

The headline numbers at a glance.

John Deere 5060EJohn Deere 5067E

Engine HPhp

60 hp

▲67.6 hp

PTO HPhp

45.6 hp

42.9 hp

▲53 hp

49 hp

OOSCabOOSCab

Weightlb

5,445 lb

▲5,555 lb

Loader Liftlb

▲2,453 lb

3-Pt Lift (24 in)lb

▲3,192 lb

Share↓ Image 𝕏 f ✉

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	John Deere5060E	John Deere5067E


Engine Manufacturer	John Deere	John Deere
Engine Model	3029H	3029H
Engine Type	Diesel, turbocharged	Diesel, turbocharged
No. of Cylinders	3	3
Displacement	179 in³	179 in³
Rated Engine Speed	2100 rpm	2100 rpm
Engine Power (Gross)	60 hp	67.6 hp
PTO Power	OOS: 45.6 hp; Cab: 42.9 hp	OOS: 53 hp; Cab: 49 hp
Engine Emissions Constraints	Tier 4	Tier 4
Cooling System Type	Liquid-cooled	Liquid cooled with overflow reservoir
Air Cleaner	Dry type with safety element	Dry type with safety element
Fuel System	Electronically controlled, high-pressure common rail	Electronically controlled, high-pressure common rail
Alternator	OOS: 70 A; Cab: 110 A	OOS: 70 A; Cab: 110 A

Pump Type	Tandem gear pump (implement + steering)	Tandem gear pump (implement + steering)
Implement Flow	11.4 gpm	11.4 gpm
Steering Flow	6.8 gpm	6.8 gpm
Total Hydraulic Flow	18.2 gpm	18.2 gpm
Overall Hydraulic Pump Flow	18.2 gpm	18.2 gpm
Hydraulic System Type	Open Center	Open Center
Rear Remote Hydraulic Flow	11.4 gpm at a single rear SCV	11.4 gpm at a single rear SCV
No. of Standard Remote Valves	1	1
No. of Optional Remote Valves	1	2

Fuel Tank Capacity	OOS: 19.6 gal; Cab: 21.6 gal	OOS: 19.6 gal; Cab: 21.6 gal
Coolant Capacity	Open operator station: 2.85 gal; Cab: 3.08 gal	Open operator station: 2.85 gal; Cab: 3.08 gal
Crankcase Capacity	9.0 qt (with filter)	9.0 qt (with filter)
Transmission / Hydraulic System Capacity	8.36 gal (9x3); 9.46 gal (12x12)	8.36 gal (9x3); 9.46 gal (12x12)
Front Axle Fluid Capacity	DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side	DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side

PTO Type	Independent	Independent
PTO Rear	540 rpm (SyncShuttle); 540/540E rpm (PowrReverser)	540 rpm (SyncShuttle); 540/540E rpm (PowrReverser)
Mid-PTO Availability	Not Published	Not Published
Category, 3-Point Hitch	Category II, convertible to I	Category II, convertible to I
Hitch Lift Capacity	3,968 lb	3,968 lb
Hitch Lift Capacity (at 24”)	3,192 lb	3,192 lb
Lift Control Type	Position control, draft control, adjustable rate of drop	Position control, draft control, adjustable rate of drop

Transmission Type	SyncShuttle (standard); PowrReverser (optional)	SyncShuttle (standard); PowrReverser (optional)
No. of Speeds	9F/3R (SyncShuttle); 12F/12R (PowrReverser)	9F/3R (SyncShuttle); 12F/12R (PowrReverser)
Max Travel Speed (Forward)	15.5 mph (SyncShuttle); 20.5 mph (PowrReverser)	15.5 mph (SyncShuttle); 20.5 mph (PowrReverser)
Max Travel Speed (Reverse)	14.2 mph (SyncShuttle); 22.3 mph (PowrReverser)	14.2 mph (SyncShuttle); 22.3 mph (PowrReverser)
Clutch	Wet traction clutch (PowrReverser)	Dual clutch, 11 in (PowrReverser)
Differential Lock & Limited Slip Options	Mechanical, rear	Mechanical, rear

Frame Type	Not Published	Not Published
Steering	Hydrostatic power steering	Hydrostatic power steering
Brakes	Hydraulically actuated wet disk brakes, self-equalizing and self-adjusting	Hydraulically actuated wet disk brakes, self-equalizing and self-adjusting
Seat Suspension & Adjustability	Mechanical suspension with weight adjustment; fore/aft and backrest angle adjustment	Mechanical suspension with weight adjustment; fore/aft and backrest angle adjustment
Front Axle Type	2WD or MFWD	2WD or MFWD
Front Axle Rating	Up to 9,612 lb (max permissible MFWD axle load w/ loader; varies by tire)	Up to 9,612 lb (max permissible MFWD axle load w/ loader; varies by tire)
Drawbar Capacity	1,675 lb (fully extended); 2,470 lb (short position)	Adjustable drawbar with interchangeable hitch balls

Overall Length with 3-Point Hitch	143.3 in	143.3 in
Overall Width	Not Published	Not Published
Wheelbase	80.7 in	80.7 in
Ground Clearance	Not Published	Not Published
Min. Turn Radius without Brakes	137.8 in (2WD); 183.1 in (4WD); 153.5 in (4WD, Carraro axle)	137.8 in (2WD); 183.1 in (4WD)
Height to Top of ROPS	Not Published	Not Published
Height to Top of ROPS (folded)	Not Published	Not Published
Height to Top of Cab Model	Not Published	Not Published

Tractor Weight (Base)	5,445 to 6,702 lb	5,555 to 6,812 lb
Weight with ROPS and Loader	Not Published	Not Published
Weight with Cab and Loader	Not Published	Not Published

Tire Size & Options	R1 Ag / R3 Turf / R4 Industrial / Snow	R1 Ag / R3 Turf / R4 Industrial / Snow
R1 Agricultural - Front	11L-15	11L-15
R1 Agricultural - Rear	14.9-28	16.9-28
R3 Turf - Front	33X15.50-15 6PR R3; 33X12.50-15 6PR R3; 29X12.5-15 4PR R3 (Premium)	33X15.50-15 6PR R3; 33X12.50-15 6PR R3; 29X12.5-15 4PR R3 (Premium)
R3 Turf - Rear	41X14.00-20 4PR R3; 44X18.00-20 4PR R3 (Premium)	41X14.00-20 4PR R3; 44X18.00-20 4PR R3 (Premium)
R4 Industrial - Front	27/12LL-15 6PR R4; 10-16.5 8PR R4; 28X8.50-15 8PR R4; 12.5/80-18 12PR R4	27/12LL-15 6PR R4; 10-16.5 8PR R4; 28X8.50-15 8PR R4; 12.5/80-18 12PR R4
R4 Industrial - Rear	17.5L-24 8PR R4; 19.5L-24 8PR R4; 16.9-30 10PR R4; 43X16.00-20 R4; 43X16.00-20 R4 (Premium); 18.4-30 10PR R4	17.5L-24 8PR R4; 19.5L-24 8PR R4; 16.9-30 10PR R4; 43X16.00-20 R4; 43X16.00-20 R4 (Premium); 18.4-30 10PR R4

Quick Attach Loader System	512 or 520M	512 or 520M
Loader Model	512 or 520M	512 or 520M
Loader Lift Height	512: 113 in; 520M: 132 in	512: 113 in; 520M: 132 in
Loader Lift Capacity (Full Height)	512: 2,453 lb; 520M: 3,523 lb	512: 2,453 lb; 520M: 3,523 lb
Loader Breakout Force	512: 4,781 lb; 520M: 4,641 lb	512: 4,781 lb; 520M: 4,641 lb

Warranty Length & Coverage	6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)	6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)

Find a John Deere dealer near you

John Deere 5060E vs John Deere 5067E: Quick Answers

Which has more horsepower, the John Deere 5060E or the John Deere 5067E?: The John Deere 5067E leads on engine hp at 67.6 hp hp, compared to 60 hp hp for the John Deere 5060E.
Which has more PTO horsepower, the John Deere 5060E or the John Deere 5067E?: The John Deere 5067E leads on pto hp at 53 hp hp, compared to 45.6 hp hp for the John Deere 5060E.
Which is heavier, the John Deere 5060E or the John Deere 5067E?: The John Deere 5067E leads on weight at 5,555 lb lb, compared to 5,445 lb lb for the John Deere 5060E.
Which has more loader lift capacity, the John Deere 5060E or the John Deere 5067E?: They are effectively tied: both machines are rated at 2,453 lb lb for loader lift.
Which has more three-point hitch lift capacity, the John Deere 5060E or the John Deere 5067E?: They are effectively tied: both machines are rated at 3,192 lb lb for 3-pt lift (24 in).
