Kioti CK2610 vs Kioti CX2510

Across 8 measurable specs, the Kioti CK2610 leads 8 categories to 0. Machine pages: Kioti CK2610 and Kioti CX2510.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	KiotiCK2610	KiotiCX2510

▶Engine
PTO Power	21.7 hp	19.3 hp
Alternator	Not Published	n/a
Air Cleaner	Not Published	n/a
Engine Type	Liquid-cooled, diesel	S204.2 gal-F
Fuel System	Not Published	Diesel fuel (ultra-low sulfur diesel, sulfur content: 15 ppm or less)
Displacement	100.5 in³	69 in³
No. of Cylinders	3	3
Rated Engine Speed	2600 rpm	3000 rpm
Cooling System Type	Liquid-cooled	Liquid cooled
Engine Manufacturer	KIOTI (Daedong)	Daedong Industrial Co., LTD
Engine Power (Gross)	24.5 hp	21 hp
Engine Emissions Constraints	Tier 4	n/a
▶Weight
Weight with ROPS and Loader	Not Published	2,308 lb
Weight with Cab and Loader	Not Published	2,804 lb
Tractor Weight (Base)	n/a	1,488 lbs with ROPS
▶Warranty
Warranty Length & Coverage	Limited: Tractors (Non-Commercial Application) 24 months parts & labor; Extended (driveline): 48 months parts & labor	6 year powertrain warranty
▶Hydraulics
Pump Type	Not Published	Variable displacement pump
Steering Flow	Not Published	4.4 qts 1.1 gal
Implement Flow	Not Published	6.86 gpm
Total Hydraulic Flow	11.7 gpm	11.3 gpm
Hydraulic System Type	Open center	open center
Rear Remote Hydraulic Flow	Not Published	NOT FOUND
Overall Hydraulic Pump Flow	11.7 gpm	11.3 gpm
No. of Optional Remote Valves	Not Published	1
No. of Standard Remote Valves	Not Published	1 Optional (CX2510/CX2510 HST); 1 Standard (CX2510 HST CAB)
System Operating Pressure	n/a	Not specified in document
▶PTO & Hitch
PTO Rear	540 rpm	540 rpm
PTO Type	Live	Transmission (CX2510); Live (CX2510 HST/CAB)
Lift Control Type	Position control	Position
Hitch Lift Capacity	1,631 lb (at 24 in)	1,203 lb.
Mid-PTO Availability	Optional	2,000 rpm (Option on CX2510/CX2510H); 2,000 rpm (Standard on CX2510 HST CAB)
Category, 3-Point Hitch	Category 1	Category I
Hitch Lift Capacity (at 24”)	1,631 lb	700 lbs
▶Tire Options
R3 Turf - Rear	41X14-20	33×12.5-16.5
R3 Turf - Front	28X8.5-15	23×8.5-12
Tire Size & Options	R1 Agricultural, R3 Turf, R4 Industrial	Front: 7.0-12 (AG), 23×8.5-12 (Turf/Industrial); Rear: 11.2-16 (AG), 33×12.5-16.5 (Turf), 12-16.5 (Industrial)
R4 Industrial - Rear	15-19.5	12-16.5
R4 Industrial - Front	27X8.5-15	23×8.5-12
R1 Agricultural - Rear	11.2-24	11.2-16
R1 Agricultural - Front	7-16	7.0-12
▶Fluid Capacity
Coolant Capacity	Not Published	1.0 U.S. gal
Crankcase Capacity	Not Published	0.8 U.S. gal
Fuel Tank Capacity	9.0 gal	6.60 gal
Front Axle Fluid Capacity	Not Published	n/a
Transmission / Hydraulic System Capacity	Not Published	3.4 U.S. gal
▶Loader & Attachments
Loader Lift Height	98.4 in	87.8 in.
Loader Breakout Force	2,110 lb	1,843 lbs.
Quick Attach Loader System	Quick-attach (QA) bucket	Quick attach bucket, 50 in.
Loader Lift Capacity (Full Height)	1,252 lb	1,092 lbs.
▶Transmission & Drivetrain
Clutch	Dry dual stage	Dry single
No. of Speeds	9F/3R	6F/2R [CX2510] / Infinite, 2 range [CX2510 HST]
Transmission Type	9-speed gear	Manual [CX2510] / Hydrostatic [CX2510 HST]
Max Travel Speed (Forward)	10.08 mph	0.75-10.8 mph (1.22-11.8 mph) [Manual]; 0-10.7 mph (0-13.5 mph) [HST]
Max Travel Speed (Reverse)	9.6 mph	0.92-4.2 mph (1.51-4.6 mph) [Manual]; 0-7.46 mph (0-9.5 mph) [HST]
Differential Lock & Limited Slip Options	Mechanical rear	Rear Standard
▶Chassis, Steering & Controls
Brakes	Wet multi-disc	Wet Disc Type
Steering	Hydrostatic Power Steering	Hydrostatic Power Steering
Frame Type	Not Published	n/a
Front Axle Type	4WD	Four-wheel drive
Drawbar Capacity	Not Published	n/a
Front Axle Rating	Not Published	n/a
Seat Suspension & Adjustability	Fully Adjustable Suspension Seat	Adjustable suspension seat with dual armrests and seat belt
▶Dimensions & Maneuverability
Wheelbase	65.7 in	59.8 in.
Overall Width	55.1 in (R1); 63.1 in (R4)	49.4 in.
Ground Clearance	13.4 in	13.4 in.
Height to Top of ROPS	99.2 in	82.8 in.
Height to Top of Cab Model	Not Published	86.6 in.
Height to Top of ROPS (folded)	Not Published	82.8 in.
Min. Turn Radius without Brakes	Not Published	9 ft (2.75 m)
Overall Length with 3-Point Hitch	120.9 in	109.1 in. [CX2510/HST]; 111 in. [CAB]
Overall Length	n/a	110.25 in with weights; 99.33 in without weights
▶ITC Company Accessories
Accessories that fit	Brush Guard Side Guards $200.00 Bolt onto the side of the OEM guard and offers wrap around protection Kioti CK2610/20 CK3510/20 CK4010/20 Brush Screen Insert $250.00 Kioti DK10/20 & CK10/20 with 6 bolt Grill Guard Brush Screen Insert $250.00	Kioti CX2510 / CK2510 Brush Screen Insert $249.99

Kioti CK2610 vs Kioti CX2510: Quick Answers

Which has more horsepower, the Kioti CK2610 or the Kioti CX2510?

The Kioti CK2610 leads on engine hp at 24.5 hp hp, compared to 21 hp hp for the Kioti CX2510.

Which has more PTO horsepower, the Kioti CK2610 or the Kioti CX2510?

The Kioti CK2610 leads on pto hp at 21.7 hp hp, compared to 19.3 hp hp for the Kioti CX2510.

Which has more loader lift capacity, the Kioti CK2610 or the Kioti CX2510?

The Kioti CK2610 leads on loader lift at 1,252 lb lb, compared to 1,092 lb lb for the Kioti CX2510.

Which has more three-point hitch lift capacity, the Kioti CK2610 or the Kioti CX2510?

The Kioti CK2610 leads on 3-pt lift (24 in) at 1,631 lb lb, compared to 700 lb lb for the Kioti CX2510.
