Kubota B2401DTN vs Kubota BX2360

Across 6 measurable specs, the Kubota B2401DTN leads 5 categories to 1. Machine pages: Kubota B2401DTN and Kubota BX2360.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	KubotaB2401DTN	KubotaBX2360

▶Engine
Engine Manufacturer	Kubota	Kubota
Engine Model	D1105	D902
Engine Type	E-TVCS, liquid cooled, 3-cylinder diesel	Liquid-cooled, 3-cylinder diesel
No. of Cylinders	3	3
Displacement	68.5 in³	54.8 in³
Rated Engine Speed	2600 rpm	3200 rpm
Engine Power (Gross)	21.9 hp	23 hp
PTO Power	19.2 hp	17.7 hp
Engine Emissions Constraints	Tier 4	Not Published
Cooling System Type	Liquid Cooled	Liquid-cooled
Air Cleaner	Dual paper element	Not Published
Fuel System	Not Published	Indirect injection
Alternator	40 A	40 A, 12 V
▶Hydraulics
Pump Type	Dual pump	Not Published
Implement Flow	4.4 gpm	Not Published
Steering Flow	2.6 gpm	Not Published
Total Hydraulic Flow	7.0 gpm	6.2 gpm
Overall Hydraulic Pump Flow	7.0 gpm	6.2 gpm
Hydraulic System Type	Open center	Open center
Rear Remote Hydraulic Flow	Not Published	Not Published
No. of Standard Remote Valves	Not Published	Not Published
No. of Optional Remote Valves	1	Not Published
▶Fluid Capacity
Fuel Tank Capacity	6.1 gal	6.6 gal
Coolant Capacity	4.0 qt	2.8 qt
Crankcase Capacity	3.3 qt	3.3 qt
Transmission / Hydraulic System Capacity	3.3 gal	3.06 gal
Front Axle Fluid Capacity	0.8 gal	Not Published
▶PTO & Hitch
PTO Type	Transmission driven with one way clutch	Live independent, wet hydraulic clutch
PTO Rear	540, 980 rpm	540 rpm
Mid-PTO Availability	Not Published	Standard mid-PTO, 2500 rpm
Category, 3-Point Hitch	Category I	Category I
Hitch Lift Capacity	1,653 lb	1,210 lb
Hitch Lift Capacity (at 24”)	1,290 lb	680 lb
Lift Control Type	Position control valve	Directional control with auto-return lever
▶Transmission & Drivetrain
Transmission Type	Gear (9 Forward, 3 Reverse)	Hydrostatic transmission with High-Low gear shift, 2-range
No. of Speeds	9 Forward, 3 Reverse	2-range
Max Travel Speed (Forward)	10.9 mph	8.1 mph
Max Travel Speed (Reverse)	5.6 mph	6.2 mph
Clutch	Dry single plate	Not Published
Differential Lock & Limited Slip Options	Standard	Differential lock (pedal operated)
▶Chassis, Steering & Controls
Frame Type	Not Published	Roll Over Protective Structure (ROPS)
Steering	Integral type power steering	Hydrostatic power steering
Brakes	Multi-plate wet disc	Wet disc
Seat Suspension & Adjustability	Fore and aft slide adjustment (position adjust lever)	Not Published
Front Axle Type	Not Published	Selectable 2WD and 4WD
Front Axle Rating	Not Published	Not Published
Drawbar Capacity	660 lb	Not Published
▶Dimensions & Maneuverability
Overall Width	35.6 in	44.5 in (with turf tires)
Wheelbase	61.4 in	55.1 in
Ground Clearance	11 in	8.7 in (front axle)
Min. Turn Radius without Brakes	6.9 ft (with brake applied)	7.5 ft
Height to Top of ROPS	75.2 in	70.3 in
Height to Top of ROPS (folded)	Not Published	Not Published
Height to Top of Cab Model	Not Published	Not Published
Overall Length	92.9 in (without 3-point hitch)	95.5 in (with 3-point hitch)
▶Weight
Tractor Weight (Base)	1,433 lb	1,290 lb (with ROPS)
Weight with ROPS and Loader	Not Published	Not Published
Weight with Cab and Loader	Not Published	Not Published
▶Tire Options
Tire Size & Options	Farm (R1): 5-12 front, 8-16 rear	Turf, bar (ag) or industrial: 18x8.5-10 front, 26x12-12 rear
R1 Agricultural - Front	5-12	18x8.5-10
R1 Agricultural - Rear	8-16	26x12-12
R3 Turf - Front	Not Published	18x8.5-10
R3 Turf - Rear	Not Published	26x12-12
R4 Industrial - Front	Not Published	18x8.5-10
R4 Industrial - Rear	Not Published	26x12-12
▶Loader & Attachments
Quick Attach Loader System	Not Published	Not Published
Loader Model	Not Published	LA243
Loader Lift Height	Not Published	LA243: 71.3 in (at pivot pin)
Loader Lift Capacity (Full Height)	Not Published	LA243: 750 lb (pivot pin, max. height)
Loader Breakout Force	Not Published	LA243: 992 lbf
▶Warranty
Warranty Length & Coverage	Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours	Not Published
▶ITC Company Accessories
Accessories that fit	Kubota B2301/B2401/B2601 Brush Guard Insert Kit $259.00	None tagged yet

Find a Kubota dealer near you→

Kubota B2401DTN vs Kubota BX2360: Quick Answers

Which has more horsepower, the Kubota B2401DTN or the Kubota BX2360?

The Kubota BX2360 leads on engine hp at 23 hp hp, compared to 21.9 hp hp for the Kubota B2401DTN.

Which has more PTO horsepower, the Kubota B2401DTN or the Kubota BX2360?

The Kubota B2401DTN leads on pto hp at 19.2 hp hp, compared to 17.7 hp hp for the Kubota BX2360.

Which is heavier, the Kubota B2401DTN or the Kubota BX2360?

The Kubota B2401DTN leads on weight at 1,433 lb lb, compared to 1,290 lb lb for the Kubota BX2360.

Which has more three-point hitch lift capacity, the Kubota B2401DTN or the Kubota BX2360?

The Kubota B2401DTN leads on 3-pt lift (24 in) at 1,290 lb lb, compared to 680 lb lb for the Kubota BX2360.
