| Engine Manufacturer | Kubota | Kubota |
|---|
| Engine Model | F (2WD gear), DT (4WD gear): D1803-CR-E4-LB1; HST (4WD): D1803-CR-E4-LB2 | Not Published |
|---|
| Engine Type | Liquid-cooled, 3-cylinder, 4-cycle, multi-valve diesel, naturally aspirated, common rail direct injection | Vertical, liquid-cooled, 4-cycle diesel, indirect injection (E-TVCS) |
|---|
| No. of Cylinders | 3 | 3 |
|---|
| Displacement | 111.4 in³ | 111.4 in³ |
|---|
| Rated Engine Speed | 2700 rpm | 2700 rpm |
|---|
| Engine Power (Gross) | 33 hp | 35.7 hp |
|---|
| PTO Power | F (2WD gear), DT (4WD gear): 27.7 hp; HST (4WD): 26.2 hp | F (2WD gear), DT (4WD gear): 30 hp; HST (4WD): 28.5 hp |
|---|
| Engine Emissions Constraints | Tier 4 | Tier 4 |
|---|
| Cooling System Type | Liquid-cooled, water with pressurized radiator | Liquid-cooled |
|---|
| Air Cleaner | Dry paper single element | Not Published |
|---|
| Fuel System | Common rail (CRS) direct injection, electronic fuel injection | Indirect injection (E-TVCS) |
|---|
| Alternator | 40 A, 12 V | 40 A, 12 V |
|---|
|
|---|
| Pump Type | Open center tandem pump, gear type | Not Published |
|---|
| Implement Flow | 6.3 gpm | 6.3 gpm |
|---|
| Steering Flow | 3.8 gpm | 3.8 gpm |
|---|
| Total Hydraulic Flow | 10.1 gpm | 10.1 gpm (6.3 + 3.8, computed) |
|---|
| Overall Hydraulic Pump Flow | 10.1 gpm | Not Published |
|---|
| Hydraulic System Type | Open center | Open center |
|---|
| Rear Remote Hydraulic Flow | Not Published | Not Published |
|---|
| No. of Standard Remote Valves | Not Published | Not Published |
|---|
| No. of Optional Remote Valves | Up to 3 (self canceling detent valve or float detent valve options) | Up to 3 |
|---|
|
|---|
| Fuel Tank Capacity | 11.1 gal | 9.0 gal |
|---|
| Coolant Capacity | 6.3 qt | Not Published |
|---|
| Crankcase Capacity | 7.1 qt | Not Published |
|---|
| Transmission / Hydraulic System Capacity | F (2WD gear): 7.4 gal; DT (4WD gear): 7.5 gal; HST (4WD): 6.2 gal | 7.3 gal |
|---|
| Front Axle Fluid Capacity | 4.8 qt | 4.8 qt |
|---|
|
|---|
| PTO Type | Live independent PTO with hydraulic clutch | F (2WD gear), DT (4WD gear): Live-continuous running; HST (4WD): Live-continuous with overrunning clutch |
|---|
| PTO Rear | 540 rpm | 540 rpm |
|---|
| Mid-PTO Availability | No mid-PTO offered | Not Published |
|---|
| Category, 3-Point Hitch | Category I | Category I |
|---|
| Hitch Lift Capacity | 1998 lb | 1998 lb |
|---|
| Hitch Lift Capacity (at 24”) | 1433 lb | 1435 lb |
|---|
| Lift Control Type | Position control | Position control |
|---|
|
|---|
| Transmission Type | F (2WD gear), DT (4WD gear): Synchronized shuttle gear transmission, 8F/8R; HST (4WD): Hydrostatic transmission, 3-range | F (2WD gear), DT (4WD gear): Sliding gear and constant mesh, 8F/4R; HST (4WD): Hydrostatic transmission, 3-range |
|---|
| No. of Speeds | F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range | F (2WD gear), DT (4WD gear): 8F/4R; HST (4WD): 3-range |
|---|
| Max Travel Speed (Forward) | F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph | F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph |
|---|
| Max Travel Speed (Reverse) | F (2WD gear), DT (4WD gear): 13.1 mph; HST (4WD): 12.7 mph | F (2WD gear), DT (4WD gear): 4.7 mph; HST (4WD): 12.7 mph |
|---|
| Clutch | Dry type single stage | F (2WD gear), DT (4WD gear): Dry-type dual stage; HST (4WD): Dry-type single stage |
|---|
| Differential Lock & Limited Slip Options | Rear differential lock standard | Rear differential lock standard |
|---|
|
|---|
| Frame Type | Two-post foldable ROPS (factory certified) with retractable seat belt | Foldable ROPS (standard on all models) |
|---|
| Steering | Integral power steering | Integral type power steering |
|---|
| Brakes | Mechanical wet disc type, pedals can be locked together | Wet disc type |
|---|
| Seat Suspension & Adjustability | Not Published | Not Published |
|---|
| Front Axle Type | F (2WD gear): Tubular steel, non-adjustable tread spacing; DT (4WD gear), HST (4WD): Bevel gear front axle, non-adjustable tread spacing | 4WD: Bevel gear front axle |
|---|
| Front Axle Rating | 2865 lb (at 41.3 in tread, 2WD and 4WD models) | Not Published |
|---|
| Drawbar Capacity | 730 lb | Not Published |
|---|
|
|---|
| Overall Length with 3-Point Hitch | F (2WD gear): 119.1 in; DT (4WD gear), HST (4WD): 116.3 in | F (2WD gear): 110.6 in; DT (4WD gear), HST (4WD): 106.5 in (w/o 3P) (without 3-point hitch) |
|---|
| Overall Width | 55.1 in | 51.4 in |
|---|
| Wheelbase | 63.3 in | 63.3 in |
|---|
| Ground Clearance | F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.5 in | F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.4 in |
|---|
| Min. Turn Radius without Brakes | F (2WD gear): 8.9 ft; DT (4WD gear), HST (4WD): 10.5 ft | F (2WD gear): 7.9 ft; DT (4WD gear), HST (4WD): 8.2 ft (w/brake) (with brake applied) |
|---|
| Height to Top of ROPS | 91.7 in | 85.0 in |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | Not Published | Not Published |
|---|
|
|---|
| Tractor Weight (Base) | F (2WD gear): 2557 lb; DT (4WD gear): 2734 lb; HST (4WD): 2778 lb | F (2WD gear): 2403 lb; DT (4WD gear): 2580 lb; HST (4WD): 2600 lb |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | R1 Agricultural (standard); R3 Turf; R4 Industrial (4WD) | AG standard; turf and industrial optional |
|---|
| R1 Agricultural - Front | F (2WD gear): 5-15 (7.5L-15 optional); DT (4WD gear), HST (4WD): 7.2-16 | F (2WD gear): 5-15; DT (4WD gear), HST (4WD): 7-16 |
|---|
| R1 Agricultural - Rear | 11.2-24 | 11.2-24 |
|---|
| R3 Turf - Front | F (2WD gear): 23x8.5-12; DT (4WD gear), HST (4WD): 25x8.5-14 | 25x8.50-14 (4WD) |
|---|
| R3 Turf - Rear | 13.6-16 | 13.6-16 |
|---|
| R4 Industrial - Front | 27x8.5-15 (4WD) | 27x8.50-15 (4WD) |
|---|
| R4 Industrial - Rear | 15-19.5 (4WD) | 15-19.5 R4 (4WD) |
|---|
|
|---|
| Quick Attach Loader System | LA525: 2-Lever Quick Coupler, no tools required to attach and detach loader | LA463: quick attach/detach loader (mounting pins and hose couplers from the seat); skid steer-type quick coupler optional |
|---|
| Loader Model | LA525 | LA463 |
|---|
| Loader Lift Height | LA525: 94.3 in | LA463: 95.3 in |
|---|
| Loader Lift Capacity (Full Height) | LA525: 1131 lb | LA463: 1142 lb |
|---|
| Loader Breakout Force | LA525: 2462 lbf | Not Published |
|---|
|
|---|
| Warranty Length & Coverage | 24 months or 1500 hours (general) | Not Published |
|---|
