| Engine Manufacturer | Kubota | Kubota |
|---|
| Engine Model | D1803 | F (2WD gear), DT (4WD gear): D1803-CR-E4-LB3; HST (4WD): D1803-CR-E4-LB4 |
|---|
| Engine Type | Diesel, 3-cylinder, liquid-cooled | Liquid-cooled, 3-cylinder, 4-cycle, multi-valve diesel, naturally aspirated, common rail direct injection |
|---|
| No. of Cylinders | 3 | 3 |
|---|
| Displacement | 111.4 in³ | 111.4 in³ |
|---|
| Rated Engine Speed | 2700 rpm | 2700 rpm |
|---|
| Engine Power (Gross) | 37.4 hp | 37.5 hp |
|---|
| PTO Power | Gear: 31.5 hp; HST: 30 hp | F (2WD gear), DT (4WD gear): 32.1 hp; HST (4WD): 30.6 hp |
|---|
| Engine Emissions Constraints | Tier 4 | Tier 4 |
|---|
| Cooling System Type | Not Published | Liquid-cooled, water with pressurized radiator |
|---|
| Air Cleaner | Not Published | Dry paper single element |
|---|
| Fuel System | Not Published | Common rail (CRS) direct injection, electronic fuel injection |
|---|
| Alternator | Not Published | 40 A, 12 V |
|---|
|
|---|
| Pump Type | Not Published | Open center tandem pump, gear type |
|---|
| Implement Flow | 6.3 gpm | 6.3 gpm |
|---|
| Steering Flow | Not Published | 3.8 gpm |
|---|
| Total Hydraulic Flow | Not Published | 10.1 gpm |
|---|
| Overall Hydraulic Pump Flow | Not Published | 10.1 gpm |
|---|
| Hydraulic System Type | Open center | Open center |
|---|
| Rear Remote Hydraulic Flow | Not Published | Not Published |
|---|
| No. of Standard Remote Valves | Not Published | Not Published |
|---|
| No. of Optional Remote Valves | Not Published | Up to 3 (self canceling detent valve or float detent valve options) |
|---|
|
|---|
| Fuel Tank Capacity | 10 gal | 11.1 gal |
|---|
| Coolant Capacity | Not Published | 6.3 qt |
|---|
| Crankcase Capacity | Not Published | 7.1 qt |
|---|
| Transmission / Hydraulic System Capacity | Gear: 7.1 gal; HST: 6.2 gal | F (2WD gear): 7.4 gal; DT (4WD gear): 7.5 gal; HST (4WD): 6.2 gal |
|---|
| Front Axle Fluid Capacity | Not Published | 4.8 qt |
|---|
|
|---|
| PTO Type | Not Published | Live independent PTO with hydraulic clutch |
|---|
| PTO Rear | 540 rpm | 540 rpm |
|---|
| Mid-PTO Availability | Not Published | No mid-PTO offered |
|---|
| Category, 3-Point Hitch | Category I | Category I |
|---|
| Hitch Lift Capacity | Not Published | 1998 lb |
|---|
| Hitch Lift Capacity (at 24”) | Not Published | 1433 lb |
|---|
| Lift Control Type | Not Published | Position control |
|---|
|
|---|
| Transmission Type | Gear: 8-speed constant mesh; HST: hydrostatic | F (2WD gear), DT (4WD gear): Synchronized shuttle gear transmission, 8F/8R; HST (4WD): Hydrostatic transmission, 3-range |
|---|
| No. of Speeds | Gear: 8F/4R; HST: infinite (3-range) | F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range |
|---|
| Max Travel Speed (Forward) | Not Published | F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph |
|---|
| Max Travel Speed (Reverse) | Not Published | F (2WD gear), DT (4WD gear): 13.1 mph; HST (4WD): 12.7 mph |
|---|
| Clutch | Not Published | F (2WD gear), DT (4WD gear): Dry type dual stage; HST (4WD): Dry type single stage |
|---|
| Differential Lock & Limited Slip Options | Rear differential lock standard | Rear differential lock standard |
|---|
|
|---|
| Frame Type | Not Published | Two-post foldable ROPS (factory certified) with retractable seat belt |
|---|
| Steering | Hydrostatic power steering | Integral power steering |
|---|
| Brakes | Wet disc | Mechanical wet disc type, pedals can be locked together |
|---|
| Seat Suspension & Adjustability | Not Published | Not Published |
|---|
| Front Axle Type | Bevel gear front axle | F (2WD gear): Tubular steel, non-adjustable tread spacing; DT (4WD gear), HST (4WD): Bevel gear front axle, non-adjustable tread spacing |
|---|
| Front Axle Rating | Not Published | 2865 lb (at 41.3 in tread, 2WD and 4WD models) |
|---|
| Drawbar Capacity | Not Published | 730 lb |
|---|
|
|---|
| Overall Length with 3-Point Hitch | 2WD: 110.6 in; 4WD: 106.3 in | F (2WD gear): 119.1 in; DT (4WD gear), HST (4WD): 116.3 in |
|---|
| Overall Width | 55.1 in | 55.1 in |
|---|
| Wheelbase | 63.3 in | 63.3 in |
|---|
| Ground Clearance | 2WD: 13.6 in; 4WD: 13.4 in | F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.5 in |
|---|
| Min. Turn Radius without Brakes | Not Published | F (2WD gear): 8.9 ft; DT (4WD gear), HST (4WD): 10.5 ft |
|---|
| Height to Top of ROPS | 91.7 in | 91.7 in |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | Not Published | Not Published |
|---|
|
|---|
| Tractor Weight (Base) | 2WD gear: 2480 lb; 4WD gear: 2657 lb; 4WD hydro: 2668 lb | F (2WD gear): 2590 lb; DT (4WD gear): 2767 lb; HST (4WD): 2778 lb |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | 2WD: 5.00-15 front; 4WD: 7.2-16 front; 11.2-24 rear | R1 Agricultural (standard); R3 Turf; R4 Industrial (4WD) |
|---|
| R1 Agricultural - Front | 2WD: 5.00-15; 4WD: 7.2-16 | F (2WD gear): 5-15 (7.5L-15 optional); DT (4WD gear), HST (4WD): 7.2-16 |
|---|
| R1 Agricultural - Rear | 11.2-24 | 11.2-24 |
|---|
| R3 Turf - Front | 2WD: 23x8.50-12; 4WD: 25x8.50-14 | F (2WD gear): 23x8.5-12; DT (4WD gear), HST (4WD): 25x8.5-14 |
|---|
| R3 Turf - Rear | 13.6-16 | 13.6-16 |
|---|
| R4 Industrial - Front | 27x8.50-15 (4WD) | 27x8.5-15 (4WD) |
|---|
| R4 Industrial - Rear | 15-19.5 | 15-19.5 (4WD) |
|---|
|
|---|
| Quick Attach Loader System | LA524 quick attach loader | LA525: 2-Lever Quick Coupler, no tools required to attach and detach loader |
|---|
| Loader Model | LA524 | LA525 |
|---|
| Loader Lift Height | LA524: 94.3 in | LA525: 94.3 in |
|---|
| Loader Lift Capacity (Full Height) | LA524: 1131 lb (at pin) | LA525: 1131 lb |
|---|
| Loader Breakout Force | LA524: 2462 lbf (at pin) | LA525: 2462 lbf |
|---|
|
|---|
| Warranty Length & Coverage | Not Published | 24 months or 1500 hours (general) |
|---|
