▶ EngineEngine Manufacturer Kubota Kubota Engine Model V2403-CR-TE4-GL2 V2403CR-T Engine Type Liquid-cooled, 4-cycle multi valve, diesel, Turbocharged Common rail direct injection, liquid-cooled, turbocharged 4-cylinder diesel No. of Cylinders 4 4 Displacement 148.5 in³ 148.6 in³ Rated Engine Speed 2600 rpm 2700 rpm Engine Power (Gross) 56 hp 54.7 hp PTO Power 46.5 hp F (2WD gear), DT (4WD gear): 45.7 hp; HST (4WD): 44.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry paper, dual element Dry, dual element Fuel System Electronic Common Rail System (CRS) Common rail direct injection Alternator 45 A, 12 V 45 A ▶ HydraulicsPump Type Tandem pump - gear type Not Published Implement Flow 9.4 gpm 9.5 gpm Steering Flow 4.7 gpm 4.9 gpm Total Hydraulic Flow 14.1 gpm 14.4 gpm (9.5 + 4.9, computed) Overall Hydraulic Pump Flow 14.1 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Optional, up to 3 (double-acting valve or float detent valve options, any position) Up to 3 (optional) ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 13.5 gal Coolant Capacity 8.7 qt 6.9 qt Crankcase Capacity 9.9 qt 9.9 qt Transmission / Hydraulic System Capacity 11.9 gal 11.6 gal Front Axle Fluid Capacity 8.9 qt Not Published ▶ PTO & HitchPTO Type Live independent (hydraulic clutch) Live independent hydraulic PTO with PTO brake, wet clutch PTO Rear 540 rpm @ 2400 engine rpm 540 rpm Mid-PTO Availability Optional Not Published Category, 3-Point Hitch SAE Category I & II Category I and II Hitch Lift Capacity 3,858 lb Not Published Hitch Lift Capacity (at 24”) 2,976 lb 2310 lb Lift Control Type Position control Position control standard, draft control optional ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission F (2WD gear), DT (4WD gear): Gear-drive with synchronized shuttle, 8F/8R (4-speed main, partially synchronized 3rd and 4th, 2-range); HST (4WD): Hydrostatic transmission, 3-range No. of Speeds 3-range, 6 speeds (H-DS), infinitely variable in each F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range Max Travel Speed (Forward) 16.8 mph F (2WD gear), DT (4WD gear): 16.0 mph; HST (4WD): 16.1 mph Max Travel Speed (Reverse) 15.2 mph F (2WD gear), DT (4WD gear): 14.7 mph; HST (4WD): 14.5 mph Clutch Not Published F (2WD gear), DT (4WD gear): Dry single plate; HST (4WD): No clutch Differential Lock & Limited Slip Options Rear differential lock, standard Rear differential lock standard (mechanical) ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc type, mechanically activated Mechanical wet disc Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment, suspension adjust knob, backrest tilt adjustment, swivel and arm rest High-back suspension seat Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing 4WD: Bevel gear type Front Axle Rating Not Published Not Published Drawbar Capacity 1,433 lb 1650 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 135.0 in F (2WD gear): 127.8 in; DT (4WD gear), HST (4WD): 125.2 in (w/o 3P) (without 3-point hitch) Overall Width 67.3 in 69.7 in Wheelbase 75.4 in 74.6 in Ground Clearance 15.4 in F (2WD gear): 15.9 in; DT (4WD gear), HST (4WD): 15.2 in Min. Turn Radius without Brakes 9.2 ft (with brake applied) F (2WD gear): 8.5 ft; DT (4WD gear), HST (4WD): 8.9 ft (w/brake) (with brake applied) Height to Top of ROPS 98.0 in 95.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Applicable Not Published ▶ WeightTractor Weight (Base) 3,990 lb F (2WD gear): 3474 lb; DT (4WD gear): 3716 lb; HST (4WD): 3734 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard R1 (9.5-16 / 14.9-26); options: R1 (9.5-16 / 13.6-28), R4 (10-16.5 / 17.5L-24), R3 (29x12.50-15 / 44x18-20), LSW R3 (LSW305R343 / LSW610R470) Standard ag: 7.5L-15 (2WD) or 9.5-16 (4WD) front, 14.9-26 rear R1 Agricultural - Front 9.5-16 F (2WD gear): 7.5L-15; DT (4WD gear), HST (4WD): 9.5-16 R1 Agricultural - Rear 14.9-26; 13.6-28 14.9-26 R3 Turf - Front 29X12.50-15 Not Published R3 Turf - Rear 44X18-20 Not Published R4 Industrial - Front 10-16.5 Not Published R4 Industrial - Rear 17.5L-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Mechanical 2-Lever Quick Coupler (standard); Hydraulic 2-Lever Quick Coupler (optional); Single Lever Hose Quick Coupler (optional) LA1065: 2-lever quick coupler standard Loader Model LA1055 LA1065 Loader Lift Height 112.7 in LA1065: 111.2 in Loader Lift Capacity (Full Height) 2361 lb LA1065: 2275 lb Loader Breakout Force 3171 lbf (19.7 in forward of pivot pin) Not Published ▶ WarrantyWarranty Length & Coverage Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
