| Engine Manufacturer | Kubota | Kubota |
|---|
| Engine Model | V2403-CR-TE4 | V2403CR-T |
|---|
| Engine Type | 4-cylinder in-line, common rail direct injection, turbocharged diesel | Common rail direct injection, liquid-cooled, turbocharged 4-cylinder diesel |
|---|
| No. of Cylinders | 4 | 4 |
|---|
| Displacement | 148.5 in³ | 148.6 in³ |
|---|
| Rated Engine Speed | 2600 rpm | 2700 rpm |
|---|
| Engine Power (Gross) | 57.9 hp | 54.7 hp |
|---|
| PTO Power | 50 hp | F (2WD gear), DT (4WD gear): 45.7 hp; HST (4WD): 44.2 hp |
|---|
| Engine Emissions Constraints | Tier 4 | Tier 4 |
|---|
| Cooling System Type | Liquid-cooled, pressurized radiator with recovery tank | Liquid-cooled |
|---|
| Air Cleaner | Dry paper dual element, 8 in diameter, pre-cleaner standard | Dry, dual element |
|---|
| Fuel System | Common rail direct injection | Common rail direct injection |
|---|
| Alternator | 45 A | 45 A |
|---|
|
|---|
| Pump Type | Gear pump | Not Published |
|---|
| Implement Flow | 10.6 gpm | 9.5 gpm |
|---|
| Steering Flow | 6.1 gpm | 4.9 gpm |
|---|
| Total Hydraulic Flow | 16.5 gpm | 14.4 gpm (9.5 + 4.9, computed) |
|---|
| Overall Hydraulic Pump Flow | 16.5 gpm | Not Published |
|---|
| Hydraulic System Type | Open center | Open center |
|---|
| Rear Remote Hydraulic Flow | Not Published | Not Published |
|---|
| No. of Standard Remote Valves | 1 (SCD) | Not Published |
|---|
| No. of Optional Remote Valves | 2 optional (3 maximum) | Up to 3 (optional) |
|---|
|
|---|
| Fuel Tank Capacity | 17.7 gal | 13.5 gal |
|---|
| Coolant Capacity | 8.5 qt | 6.9 qt |
|---|
| Crankcase Capacity | 7.6 qt | 9.9 qt |
|---|
| Transmission / Hydraulic System Capacity | 50.7 qt | 11.6 gal |
|---|
| Front Axle Fluid Capacity | No front axle oil, 2WD (M5660SUH); 6.9 qt front differential case plus 3.2 qt per bevel gear case (M5660SUHD) | Not Published |
|---|
|
|---|
| PTO Type | Hydraulic independent PTO, self-modulating multi-plate wet clutch with brake | Live independent hydraulic PTO with PTO brake, wet clutch |
|---|
| PTO Rear | 540 rpm (540/540E optional) | 540 rpm |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | Category I and II | Category I and II |
|---|
| Hitch Lift Capacity | 4189 lb | Not Published |
|---|
| Hitch Lift Capacity (at 24”) | 3307 lb | 2310 lb |
|---|
| Lift Control Type | Position control | Position control standard, draft control optional |
|---|
|
|---|
| Transmission Type | Fully synchronized 4-speed main gear shift with hi-lo range and hydraulic shuttle, 8F/8R | F (2WD gear), DT (4WD gear): Gear-drive with synchronized shuttle, 8F/8R (4-speed main, partially synchronized 3rd and 4th, 2-range); HST (4WD): Hydrostatic transmission, 3-range |
|---|
| No. of Speeds | 8F/8R | F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range |
|---|
| Max Travel Speed (Forward) | 18.2 mph | F (2WD gear), DT (4WD gear): 16.0 mph; HST (4WD): 16.1 mph |
|---|
| Max Travel Speed (Reverse) | 18.6 mph | F (2WD gear), DT (4WD gear): 14.7 mph; HST (4WD): 14.5 mph |
|---|
| Clutch | Multiple wet disc | F (2WD gear), DT (4WD gear): Dry single plate; HST (4WD): No clutch |
|---|
| Differential Lock & Limited Slip Options | Rear differential lock standard (mechanical) | Rear differential lock standard (mechanical) |
|---|
|
|---|
| Frame Type | Not Published | Two-post foldable ROPS |
|---|
| Steering | Hydrostatic power steering | Hydrostatic power steering |
|---|
| Brakes | Mechanical wet disc | Mechanical wet disc |
|---|
| Seat Suspension & Adjustability | Fully adjustable suspension seat with retractable seat belt | High-back suspension seat |
|---|
| Front Axle Type | Adjustable tubular steel, 2WD (M5660SUH); Cast iron bevel pinion drive with 55 degree turning angle, 4WD (M5660SUHD) | 4WD: Bevel gear type |
|---|
| Front Axle Rating | 4410 lb at 55.9 in tread spacing (M5660SUH); 5290 lb at 55.9 in tread spacing (M5660SUHD) | Not Published |
|---|
| Drawbar Capacity | 2200 lb | 1650 lb |
|---|
|
|---|
| Overall Length with 3-Point Hitch | 138.7 in (M5660SUH); 136 in (M5660SUHD) | F (2WD gear): 127.8 in; DT (4WD gear), HST (4WD): 125.2 in (w/o 3P) (without 3-point hitch) |
|---|
| Overall Width | 73.2 in | 69.7 in |
|---|
| Wheelbase | 82 in (M5660SUH); 80.7 in (M5660SUHD) | 74.6 in |
|---|
| Ground Clearance | 16.3 in | F (2WD gear): 15.9 in; DT (4WD gear), HST (4WD): 15.2 in |
|---|
| Min. Turn Radius without Brakes | 10.8 ft (M5660SUH); 12.8 ft (M5660SUHD) | F (2WD gear): 8.5 ft; DT (4WD gear), HST (4WD): 8.9 ft (w/brake) (with brake applied) |
|---|
| Height to Top of ROPS | 95.3 in | 95.7 in |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | Not Published | Not Published |
|---|
|
|---|
| Tractor Weight (Base) | 4189 lb (M5660SUH); 4387 lb (M5660SUHD) | F (2WD gear): 3474 lb; DT (4WD gear): 3716 lb; HST (4WD): 3734 lb |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | 2WD: 6.50-16, 7.5-16, 9.5L-15 fronts with 14.9-28 or 16.9-28 R1 rears; R3 29x12.50-15 / 21.5L-16.1 and LSW; 4WD: 9.5-22 or 280/85R20 fronts with 14.9-28 R1 rears; R3 29x12.50-15 / 21.5L-16.1; R4 12.5/80-18 / 16.9-24 | Standard ag: 7.5L-15 (2WD) or 9.5-16 (4WD) front, 14.9-26 rear |
|---|
| R1 Agricultural - Front | 6.5-16 (M5660SUH); 8.3-24 (M5660SUHD) | F (2WD gear): 7.5L-15; DT (4WD gear), HST (4WD): 9.5-16 |
|---|
| R1 Agricultural - Rear | 14.9-28 | 14.9-26 |
|---|
| R3 Turf - Front | 29x12.50-15 | Not Published |
|---|
| R3 Turf - Rear | 21.5L-16.1 | Not Published |
|---|
| R4 Industrial - Front | 12.5/80-18 (M5660SUHD) | Not Published |
|---|
| R4 Industrial - Rear | 16.9-24 (M5660SUHD) | Not Published |
|---|
|
|---|
| Quick Attach Loader System | LA1154SU: 2-lever quick attach coupler standard | LA1065: 2-lever quick coupler standard |
|---|
| Loader Model | LA1154SU (printed LA1154 in the 2014 brochure) | LA1065 |
|---|
| Loader Lift Height | LA1154: 130.9 in (height position); 115.7 in (power position) | LA1065: 111.2 in |
|---|
| Loader Lift Capacity (Full Height) | LA1154: 2469 lb (height position); 2928 lb (power position) | LA1065: 2275 lb |
|---|
| Loader Breakout Force | LA1154SU: 4230 lbf (height position); 5354 lbf (power position) | Not Published |
|---|
|
|---|
| Warranty Length & Coverage | All usage - Basic Standard Limited: 24 months or 2000 hours; Limited Powertrain: 36 months or 3000 hours. | Not Published |
|---|
