LS Tractor MT125 vs LS Tractor XJ2025H

Every published spec for both machines, side by side. The verdict below is computed straight from the spec sheets, not opinion.

Across 9 measurable specs, the LS Tractor XJ2025H leads 7 categories to 2. Machine pages: LS Tractor MT125 and LS Tractor XJ2025H.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Spec	LS Tractor MT125	LS Tractor XJ2025H
Engine HP (hp)	▲ 24.7 hp	24.4 hp
PTO HP (hp)	17.2 hp	▲ 18.5 hp
Weight (lb)	1,444 lb	▲ 1,609 lb
Loader Lift (lb)	902 lb	▲ 1,091 lb
3-Pt Lift (24 in) (lb)	728 lb	▲ 1,058 lb
Lift Height (in)	72.6 in	▲ 85.7 in
Breakout Force (lbf)	▲ 1,836 lbf	1,426 lbf
Hydraulic Flow (gpm)	6.7 gpm	▲ 8.5 gpm
Travel Speed (mph)	8.7 mph	▲ 11.5 mph

The headline numbers at a glance.

LS Tractor MT125LS Tractor XJ2025H

Engine HPhp

▲24.7 hp

24.4 hp

PTO HPhp

17.2 hp

▲18.5 hp

Weightlb

1,444 lb

▲1,609 lb

Loader Liftlb

902 lb

▲1,091 lb

3-Pt Lift (24 in)lb

728 lb

▲1,058 lb

Share↓ Image 𝕏 f ✉

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	LS TractorMT125	LS TractorXJ2025H


Engine Manufacturer	Yanmar	Mitsubishi
Engine Model	3TNV80F	S3L2
Engine Type	3-cylinder, indirect injection (swirl chamber), water-cooled	3-cylinder, indirect injection, water-cooled
No. of Cylinders	3	3
Displacement	77.3 in³	80.4 in³
Rated Engine Speed	3000 rpm	2500 rpm
Engine Power (Gross)	24.7 hp	24.4 hp
PTO Power	17.2 hp	18.5 hp
Engine Emissions Constraints	Tier 4	Tier 4
Cooling System Type	Water-cooled	Water-cooled
Air Cleaner	Dry	Dry
Fuel System	In-line injection pump	Indirect injection
Alternator	40 A, 12 V	50 A, 12 V

Pump Type	Gear pump, transmission driven	Transmission drive
Implement Flow	4.6 gpm	5.9 gpm
Steering Flow	2.1 gpm	2.6 gpm
Total Hydraulic Flow	6.7 gpm	8.5 gpm
Overall Hydraulic Pump Flow	6.7 gpm	8.5 gpm
Hydraulic System Type	Open center system, position control	Position control
Rear Remote Hydraulic Flow	Not Published	Not Published
No. of Standard Remote Valves	None	None
No. of Optional Remote Valves	1 set (2 quick couplers, optional)	2 quick couplers (optional)

Fuel Tank Capacity	6.6 gal	6.6 gal
Coolant Capacity	0.9 gal	1.0 gal
Crankcase Capacity	0.8 gal	1.1 gal
Transmission / Hydraulic System Capacity	3.0 gal (3.4 gal with front-end loader; 4.7 gal with front-end loader and backhoe)	5.3 gal
Front Axle Fluid Capacity	0.5 gal	0.8 gal

PTO Type	Independent (electro-hydraulic)	Independent (electro-hydraulic)
PTO Rear	Standard (540 rpm)	Standard (540 rpm)
Mid-PTO Availability	Standard (2,500 rpm)	Standard (2,000 rpm)
Category, 3-Point Hitch	Category I	Category I
Hitch Lift Capacity	992 lb	1,433 lb
Hitch Lift Capacity (at 24”)	728 lb	1,058 lb
Lift Control Type	Position control	Manual position control

Transmission Type	Hydrostatic Drive	Hydrostatic Drive
No. of Speeds	2 ranges	2 ranges
Max Travel Speed (Forward)	8.70 mph	11.5 mph
Max Travel Speed (Reverse)	5.22 mph	7.2 mph
Clutch	N/A	Not Published
Differential Lock & Limited Slip Options	Mechanical pedal type	Mechanical pedal type

Frame Type	Not Published	Not Published
Steering	Hydrostatic power steering	Hydrostatic power steering
Brakes	Wet, multi-disc	Wet, multi-disc
Seat Suspension & Adjustability	Adjustable forward and backward via seat lever; reversible seat optional	Not Published
Front Axle Type	Front wheel mechanical assist (4WD)	Front wheel mechanical assist (4WD)
Front Axle Rating	Not Published	Not Published
Drawbar Capacity	Hitch: 882 lb vertical, 3,527 lb horizontal; drawbar with clevis: 772 lb vertical, 3,527 lb horizontal	Horizontal load: 3,527 lb; Vertical load: 551 lb pulled / 882 lb pushed

Overall Width	47 in	44.9 in
Wheelbase	56 in	59 in
Ground Clearance	Not Published	Not Published
Min. Turn Radius without Brakes	7.87 ft	8.2 ft (with brake applied)
Height to Top of ROPS	87 in	84.5 in
Height to Top of ROPS (folded)	Not Published	Not Published
Height to Top of Cab Model	Not Published	Not Published
Overall Length	97 in (bumper to link)	103 in (bumper to link)

Tractor Weight (Base)	1,444 lb	1,609 lb
Weight with ROPS and Loader	Not Published	Not Published
Weight with Cab and Loader	Not Published	Not Published

Tire Size & Options	Front 18x8.50-10, rear 26x12.0-12; offered in industrial or turf	Agricultural, Turf, Industrial
R1 Agricultural - Front	Not Published	23X10.50-12
R1 Agricultural - Rear	Not Published	255/75-15.3
R3 Turf - Front	18x8.50-10	23x8.5-12
R3 Turf - Rear	26x12.0-12	33x12-16.5
R4 Industrial - Front	18x8.50-10	23x8.5-12
R4 Industrial - Rear	26x12.0-12	33x12-16.5

Quick Attach Loader System	Not Published	LL2102: Bobcat-type quick attachment (ISO 24410), latch handle with latch pin
Loader Model	LL1102; LL1700; LL1001	LL2102
Loader Lift Height	LL1001: 72.6 in (at pivot pin)	LL2102: 85.7 in
Loader Lift Capacity (Full Height)	LL1001: 902 lb (at pivot pin, maximum height)	LL2102: 1,091 lb (at pivot pin, max height)
Loader Breakout Force	LL1001: 1,836 lb (at pivot pin)	LL2102: 1,426 lb (at pivot pin)

Warranty Length & Coverage	6-year limited warranty	6-year limited warranty

Find a LS Tractor dealer near you

LS Tractor MT125 vs LS Tractor XJ2025H: Quick Answers

Which has more horsepower, the LS Tractor MT125 or the LS Tractor XJ2025H?: The LS Tractor MT125 leads on engine hp at 24.7 hp hp, compared to 24.4 hp hp for the LS Tractor XJ2025H.
Which has more PTO horsepower, the LS Tractor MT125 or the LS Tractor XJ2025H?: The LS Tractor XJ2025H leads on pto hp at 18.5 hp hp, compared to 17.2 hp hp for the LS Tractor MT125.
Which is heavier, the LS Tractor MT125 or the LS Tractor XJ2025H?: The LS Tractor XJ2025H leads on weight at 1,609 lb lb, compared to 1,444 lb lb for the LS Tractor MT125.
Which has more loader lift capacity, the LS Tractor MT125 or the LS Tractor XJ2025H?: The LS Tractor XJ2025H leads on loader lift at 1,091 lb lb, compared to 902 lb lb for the LS Tractor MT125.
Which has more three-point hitch lift capacity, the LS Tractor MT125 or the LS Tractor XJ2025H?: The LS Tractor XJ2025H leads on 3-pt lift (24 in) at 1,058 lb lb, compared to 728 lb lb for the LS Tractor MT125.

More Head-to-Heads

Category Verdict

Spec	LS Tractor MT125	LS Tractor XJ2025H
Engine HP (hp)	▲ 24.7 hp	24.4 hp
PTO HP (hp)	17.2 hp	▲ 18.5 hp
Weight (lb)	1,444 lb	▲ 1,609 lb
Loader Lift (lb)	902 lb	▲ 1,091 lb
3-Pt Lift (24 in) (lb)	728 lb	▲ 1,058 lb
Lift Height (in)	72.6 in	▲ 85.7 in
Breakout Force (lbf)	▲ 1,836 lbf	1,426 lbf
Hydraulic Flow (gpm)	6.7 gpm	▲ 8.5 gpm
Travel Speed (mph)	8.7 mph	▲ 11.5 mph

The headline numbers at a glance.

LS Tractor MT125LS Tractor XJ2025H

Engine HPhp

▲24.7 hp

24.4 hp

PTO HPhp

17.2 hp

▲18.5 hp

Weightlb

1,444 lb

▲1,609 lb

Loader Liftlb

902 lb

▲1,091 lb

3-Pt Lift (24 in)lb

728 lb

▲1,058 lb

Share↓ Image 𝕏 f ✉

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	LS TractorMT125	LS TractorXJ2025H


Engine Manufacturer	Yanmar	Mitsubishi
Engine Model	3TNV80F	S3L2
Engine Type	3-cylinder, indirect injection (swirl chamber), water-cooled	3-cylinder, indirect injection, water-cooled
No. of Cylinders	3	3
Displacement	77.3 in³	80.4 in³
Rated Engine Speed	3000 rpm	2500 rpm
Engine Power (Gross)	24.7 hp	24.4 hp
PTO Power	17.2 hp	18.5 hp
Engine Emissions Constraints	Tier 4	Tier 4
Cooling System Type	Water-cooled	Water-cooled
Air Cleaner	Dry	Dry
Fuel System	In-line injection pump	Indirect injection
Alternator	40 A, 12 V	50 A, 12 V

Pump Type	Gear pump, transmission driven	Transmission drive
Implement Flow	4.6 gpm	5.9 gpm
Steering Flow	2.1 gpm	2.6 gpm
Total Hydraulic Flow	6.7 gpm	8.5 gpm
Overall Hydraulic Pump Flow	6.7 gpm	8.5 gpm
Hydraulic System Type	Open center system, position control	Position control
Rear Remote Hydraulic Flow	Not Published	Not Published
No. of Standard Remote Valves	None	None
No. of Optional Remote Valves	1 set (2 quick couplers, optional)	2 quick couplers (optional)

Fuel Tank Capacity	6.6 gal	6.6 gal
Coolant Capacity	0.9 gal	1.0 gal
Crankcase Capacity	0.8 gal	1.1 gal
Transmission / Hydraulic System Capacity	3.0 gal (3.4 gal with front-end loader; 4.7 gal with front-end loader and backhoe)	5.3 gal
Front Axle Fluid Capacity	0.5 gal	0.8 gal

PTO Type	Independent (electro-hydraulic)	Independent (electro-hydraulic)
PTO Rear	Standard (540 rpm)	Standard (540 rpm)
Mid-PTO Availability	Standard (2,500 rpm)	Standard (2,000 rpm)
Category, 3-Point Hitch	Category I	Category I
Hitch Lift Capacity	992 lb	1,433 lb
Hitch Lift Capacity (at 24”)	728 lb	1,058 lb
Lift Control Type	Position control	Manual position control

Transmission Type	Hydrostatic Drive	Hydrostatic Drive
No. of Speeds	2 ranges	2 ranges
Max Travel Speed (Forward)	8.70 mph	11.5 mph
Max Travel Speed (Reverse)	5.22 mph	7.2 mph
Clutch	N/A	Not Published
Differential Lock & Limited Slip Options	Mechanical pedal type	Mechanical pedal type

Frame Type	Not Published	Not Published
Steering	Hydrostatic power steering	Hydrostatic power steering
Brakes	Wet, multi-disc	Wet, multi-disc
Seat Suspension & Adjustability	Adjustable forward and backward via seat lever; reversible seat optional	Not Published
Front Axle Type	Front wheel mechanical assist (4WD)	Front wheel mechanical assist (4WD)
Front Axle Rating	Not Published	Not Published
Drawbar Capacity	Hitch: 882 lb vertical, 3,527 lb horizontal; drawbar with clevis: 772 lb vertical, 3,527 lb horizontal	Horizontal load: 3,527 lb; Vertical load: 551 lb pulled / 882 lb pushed

Overall Width	47 in	44.9 in
Wheelbase	56 in	59 in
Ground Clearance	Not Published	Not Published
Min. Turn Radius without Brakes	7.87 ft	8.2 ft (with brake applied)
Height to Top of ROPS	87 in	84.5 in
Height to Top of ROPS (folded)	Not Published	Not Published
Height to Top of Cab Model	Not Published	Not Published
Overall Length	97 in (bumper to link)	103 in (bumper to link)

Tractor Weight (Base)	1,444 lb	1,609 lb
Weight with ROPS and Loader	Not Published	Not Published
Weight with Cab and Loader	Not Published	Not Published

Tire Size & Options	Front 18x8.50-10, rear 26x12.0-12; offered in industrial or turf	Agricultural, Turf, Industrial
R1 Agricultural - Front	Not Published	23X10.50-12
R1 Agricultural - Rear	Not Published	255/75-15.3
R3 Turf - Front	18x8.50-10	23x8.5-12
R3 Turf - Rear	26x12.0-12	33x12-16.5
R4 Industrial - Front	18x8.50-10	23x8.5-12
R4 Industrial - Rear	26x12.0-12	33x12-16.5

Quick Attach Loader System	Not Published	LL2102: Bobcat-type quick attachment (ISO 24410), latch handle with latch pin
Loader Model	LL1102; LL1700; LL1001	LL2102
Loader Lift Height	LL1001: 72.6 in (at pivot pin)	LL2102: 85.7 in
Loader Lift Capacity (Full Height)	LL1001: 902 lb (at pivot pin, maximum height)	LL2102: 1,091 lb (at pivot pin, max height)
Loader Breakout Force	LL1001: 1,836 lb (at pivot pin)	LL2102: 1,426 lb (at pivot pin)

Warranty Length & Coverage	6-year limited warranty	6-year limited warranty

Find a LS Tractor dealer near you

LS Tractor MT125 vs LS Tractor XJ2025H: Quick Answers

Which has more horsepower, the LS Tractor MT125 or the LS Tractor XJ2025H?

The LS Tractor MT125 leads on engine hp at 24.7 hp hp, compared to 24.4 hp hp for the LS Tractor XJ2025H.

Which has more PTO horsepower, the LS Tractor MT125 or the LS Tractor XJ2025H?

The LS Tractor XJ2025H leads on pto hp at 18.5 hp hp, compared to 17.2 hp hp for the LS Tractor MT125.

Which is heavier, the LS Tractor MT125 or the LS Tractor XJ2025H?

The LS Tractor XJ2025H leads on weight at 1,609 lb lb, compared to 1,444 lb lb for the LS Tractor MT125.

Which has more loader lift capacity, the LS Tractor MT125 or the LS Tractor XJ2025H?

The LS Tractor XJ2025H leads on loader lift at 1,091 lb lb, compared to 902 lb lb for the LS Tractor MT125.

Which has more three-point hitch lift capacity, the LS Tractor MT125 or the LS Tractor XJ2025H?

The LS Tractor XJ2025H leads on 3-pt lift (24 in) at 1,058 lb lb, compared to 728 lb lb for the LS Tractor MT125.
