Mahindra 1123 HST Cab vs Mahindra eMax 22L

Every published spec for both machines, side by side. The verdict below is computed straight from the spec sheets, not opinion.

Across 8 measurable specs, this matchup is a dead heat: 4 categories to the Mahindra 1123 HST Cab, 4 to the Mahindra eMax 22L. Machine pages: Mahindra 1123 HST Cab and Mahindra eMax 22L.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Spec	Mahindra 1123 HST Cab	Mahindra eMax 22L
Engine HP (hp)	▲ 22.9 hp	22 hp
PTO HP (hp)	▲ 16.8 hp	14.9 hp
Weight (lb)	▲ 1,962 lb	1,638 lb
Loader Lift (lb)	794 lb	▲ 900 lb
3-Pt Lift (24 in) (lb)	771 lb	▲ 1,323 lb
Lift Height (in)	68 in	▲ 75.3 in
Breakout Force (lbf)	1,433 lbf	▲ 2,000 lbf
Hydraulic Flow (gpm)	▲ 11.2 gpm	7.1 gpm
Travel Speed (mph)	7.3 mph	n/a

The headline numbers at a glance.

Mahindra 1123 HST CabMahindra eMax 22L

Engine HPhp

▲22.9 hp

22 hp

PTO HPhp

▲16.8 hp

14.9 hp

Weightlb

▲1,962 lb

1,638 lb

Loader Liftlb

794 lb

▲900 lb

3-Pt Lift (24 in)lb

771 lb

▲1,323 lb

at pin

Share↓ Image 𝕏 f ✉

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	Mahindra1123 HST Cab	MahindraeMax 22L


Engine Manufacturer	Mitsubishi	Kukje
Engine Model	MVL3E3	A1100N3
Engine Type	Four Stroke, Naturally Aspirated, Indirect Injection, Water-Cooled Diesel	Four-stroke, naturally aspirated, indirect injection, water-cooled diesel
No. of Cylinders	3	3
Displacement	67.2 in³	71.7 in³
Rated Engine Speed	3000 rpm	2600 rpm
Engine Power (Gross)	22.9 hp	22 hp
PTO Power	16.8 hp	14.9 hp
Engine Emissions Constraints	No DPF	Tier 4
Cooling System Type	Water-Cooled	Water-cooled
Air Cleaner	Not Published	Not Published
Fuel System	Indirect Injection	Indirect Injection
Alternator	55 A, 12 V	50 A, 12 V

Pump Type	Not Published	Not Published
Implement Flow	7.6 gpm	4.5 gpm
Steering Flow	3.8 gpm	Not Published
Total Hydraulic Flow	11.2 gpm	7.1 gpm
Overall Hydraulic Pump Flow	11.2 gpm	7.1 gpm
Hydraulic System Type	Open Center, full-live hydraulic with position control	Open Center
Rear Remote Hydraulic Flow	Not Published	Not Published
No. of Standard Remote Valves	Not Published	Not Published
No. of Optional Remote Valves	Single or dual	Not Published

Fuel Tank Capacity	6.6 gal	5.8 gal
Coolant Capacity	Not Published	3.7 qt
Crankcase Capacity	Not Published	2.3 qt
Transmission / Hydraulic System Capacity	Not Published	Not Published
Front Axle Fluid Capacity	Not Published	Not Published

PTO Type	Independent Wet Clutch	Independent
PTO Rear	540 rpm @ 2837 rpm	540 @ 2550 rpm
Mid-PTO Availability	Optional; 2500 rpm @ 2837 rpm	Available; 2000 @ 2550 rpm
Category, 3-Point Hitch	CAT I with check chains	CAT I with Check Chains
Hitch Lift Capacity	Not Published	1,323 lb
Hitch Lift Capacity (at 24”)	771 lb	Not Published
Lift Control Type	Position Control	Not Published

Transmission Type	HST - 2 Range	HST - 2 range
No. of Speeds	Infinite	Infinite
Max Travel Speed (Forward)	7.3 mph	Not Published
Max Travel Speed (Reverse)	Not Published	Not Published
Clutch	Not Published	Dry-Single
Differential Lock & Limited Slip Options	Not Published	Mechanical rear differential lock

Frame Type	Not Published	Not Published
Steering	Hydrostatic Power Steering	Power steering
Brakes	Single Pedal	Wet Disc
Seat Suspension & Adjustability	Not Published	Not Published
Front Axle Type	Not Published	Not Published
Front Axle Rating	Not Published	Not Published
Drawbar Capacity	Not Published	Not Published

Overall Width	46.3 in	45.8 in
Wheelbase	55.1 in	57.5 in
Ground Clearance	6.7 in	9.4 in
Min. Turn Radius without Brakes	7.2 ft (with brake applied)	7.2 ft
Height to Top of ROPS	Not Published	91.3 in
Height to Top of ROPS (folded)	Not Published	Not Published
Height to Top of Cab Model	80.5 in	Not Applicable
Overall Length	100.4 in	100.5 in

Tractor Weight (Base)	1,962 lb (operating weight)	1,638 lb
Weight with ROPS and Loader	Not Published	Not Published
Weight with Cab and Loader	2,368 lb (1,962 operating weight + 406 loader shipping weight, computed)	Not Published

Tire Size & Options	Turf, Industrial	Not Published
R1 Agricultural - Front	Not Published	6x12
R1 Agricultural - Rear	Not Published	9.5x16
R3 Turf - Front	18x8.5-10	20x8-10
R3 Turf - Rear	26x12-12	29x12.5-15
R4 Industrial - Front	18x8.5-10	20x8-10
R4 Industrial - Rear	26x12-12	27x12.5-15

Quick Attach Loader System	L11: Front loader skid-steer couplers for superfast hookups	25LSK: Skid steer style quick coupler, standard
Loader Model	L11	25LSK
Loader Lift Height	L11: 68 in	25LSK: 75.3 in
Loader Lift Capacity (Full Height)	L11: 794 lb (at pivot pin)	25LSK: 900 lb
Loader Breakout Force	L11: 1,433 lb	25LSK: 2,000 lb

Warranty Length & Coverage	7-Year Limited Powertrain Warranty	Not Published

Find a Mahindra dealer near you

Mahindra 1123 HST Cab vs Mahindra eMax 22L: Quick Answers

Which has more horsepower, the Mahindra 1123 HST Cab or the Mahindra eMax 22L?: The Mahindra 1123 HST Cab leads on engine hp at 22.9 hp hp, compared to 22 hp hp for the Mahindra eMax 22L.
Which has more PTO horsepower, the Mahindra 1123 HST Cab or the Mahindra eMax 22L?: The Mahindra 1123 HST Cab leads on pto hp at 16.8 hp hp, compared to 14.9 hp hp for the Mahindra eMax 22L.
Which is heavier, the Mahindra 1123 HST Cab or the Mahindra eMax 22L?: The Mahindra 1123 HST Cab leads on weight at 1,962 lb lb, compared to 1,638 lb lb for the Mahindra eMax 22L.
Which has more loader lift capacity, the Mahindra 1123 HST Cab or the Mahindra eMax 22L?: The Mahindra eMax 22L leads on loader lift at 900 lb lb, compared to 794 lb lb for the Mahindra 1123 HST Cab.
Which has more three-point hitch lift capacity, the Mahindra 1123 HST Cab or the Mahindra eMax 22L?: The Mahindra eMax 22L leads on 3-pt lift (24 in) at 1,323 lb lb, compared to 771 lb lb for the Mahindra 1123 HST Cab.

More Head-to-Heads

Category Verdict

Spec	Mahindra 1123 HST Cab	Mahindra eMax 22L
Engine HP (hp)	▲ 22.9 hp	22 hp
PTO HP (hp)	▲ 16.8 hp	14.9 hp
Weight (lb)	▲ 1,962 lb	1,638 lb
Loader Lift (lb)	794 lb	▲ 900 lb
3-Pt Lift (24 in) (lb)	771 lb	▲ 1,323 lb
Lift Height (in)	68 in	▲ 75.3 in
Breakout Force (lbf)	1,433 lbf	▲ 2,000 lbf
Hydraulic Flow (gpm)	▲ 11.2 gpm	7.1 gpm
Travel Speed (mph)	7.3 mph	n/a

The headline numbers at a glance.

Mahindra 1123 HST CabMahindra eMax 22L

Engine HPhp

▲22.9 hp

22 hp

PTO HPhp

▲16.8 hp

14.9 hp

Weightlb

▲1,962 lb

1,638 lb

Loader Liftlb

794 lb

▲900 lb

3-Pt Lift (24 in)lb

771 lb

▲1,323 lb

at pin

Share↓ Image 𝕏 f ✉

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	Mahindra1123 HST Cab	MahindraeMax 22L


Engine Manufacturer	Mitsubishi	Kukje
Engine Model	MVL3E3	A1100N3
Engine Type	Four Stroke, Naturally Aspirated, Indirect Injection, Water-Cooled Diesel	Four-stroke, naturally aspirated, indirect injection, water-cooled diesel
No. of Cylinders	3	3
Displacement	67.2 in³	71.7 in³
Rated Engine Speed	3000 rpm	2600 rpm
Engine Power (Gross)	22.9 hp	22 hp
PTO Power	16.8 hp	14.9 hp
Engine Emissions Constraints	No DPF	Tier 4
Cooling System Type	Water-Cooled	Water-cooled
Air Cleaner	Not Published	Not Published
Fuel System	Indirect Injection	Indirect Injection
Alternator	55 A, 12 V	50 A, 12 V

Pump Type	Not Published	Not Published
Implement Flow	7.6 gpm	4.5 gpm
Steering Flow	3.8 gpm	Not Published
Total Hydraulic Flow	11.2 gpm	7.1 gpm
Overall Hydraulic Pump Flow	11.2 gpm	7.1 gpm
Hydraulic System Type	Open Center, full-live hydraulic with position control	Open Center
Rear Remote Hydraulic Flow	Not Published	Not Published
No. of Standard Remote Valves	Not Published	Not Published
No. of Optional Remote Valves	Single or dual	Not Published

Fuel Tank Capacity	6.6 gal	5.8 gal
Coolant Capacity	Not Published	3.7 qt
Crankcase Capacity	Not Published	2.3 qt
Transmission / Hydraulic System Capacity	Not Published	Not Published
Front Axle Fluid Capacity	Not Published	Not Published

PTO Type	Independent Wet Clutch	Independent
PTO Rear	540 rpm @ 2837 rpm	540 @ 2550 rpm
Mid-PTO Availability	Optional; 2500 rpm @ 2837 rpm	Available; 2000 @ 2550 rpm
Category, 3-Point Hitch	CAT I with check chains	CAT I with Check Chains
Hitch Lift Capacity	Not Published	1,323 lb
Hitch Lift Capacity (at 24”)	771 lb	Not Published
Lift Control Type	Position Control	Not Published

Transmission Type	HST - 2 Range	HST - 2 range
No. of Speeds	Infinite	Infinite
Max Travel Speed (Forward)	7.3 mph	Not Published
Max Travel Speed (Reverse)	Not Published	Not Published
Clutch	Not Published	Dry-Single
Differential Lock & Limited Slip Options	Not Published	Mechanical rear differential lock

Frame Type	Not Published	Not Published
Steering	Hydrostatic Power Steering	Power steering
Brakes	Single Pedal	Wet Disc
Seat Suspension & Adjustability	Not Published	Not Published
Front Axle Type	Not Published	Not Published
Front Axle Rating	Not Published	Not Published
Drawbar Capacity	Not Published	Not Published

Overall Width	46.3 in	45.8 in
Wheelbase	55.1 in	57.5 in
Ground Clearance	6.7 in	9.4 in
Min. Turn Radius without Brakes	7.2 ft (with brake applied)	7.2 ft
Height to Top of ROPS	Not Published	91.3 in
Height to Top of ROPS (folded)	Not Published	Not Published
Height to Top of Cab Model	80.5 in	Not Applicable
Overall Length	100.4 in	100.5 in

Tractor Weight (Base)	1,962 lb (operating weight)	1,638 lb
Weight with ROPS and Loader	Not Published	Not Published
Weight with Cab and Loader	2,368 lb (1,962 operating weight + 406 loader shipping weight, computed)	Not Published

Tire Size & Options	Turf, Industrial	Not Published
R1 Agricultural - Front	Not Published	6x12
R1 Agricultural - Rear	Not Published	9.5x16
R3 Turf - Front	18x8.5-10	20x8-10
R3 Turf - Rear	26x12-12	29x12.5-15
R4 Industrial - Front	18x8.5-10	20x8-10
R4 Industrial - Rear	26x12-12	27x12.5-15

Quick Attach Loader System	L11: Front loader skid-steer couplers for superfast hookups	25LSK: Skid steer style quick coupler, standard
Loader Model	L11	25LSK
Loader Lift Height	L11: 68 in	25LSK: 75.3 in
Loader Lift Capacity (Full Height)	L11: 794 lb (at pivot pin)	25LSK: 900 lb
Loader Breakout Force	L11: 1,433 lb	25LSK: 2,000 lb

Warranty Length & Coverage	7-Year Limited Powertrain Warranty	Not Published

Find a Mahindra dealer near you

Mahindra 1123 HST Cab vs Mahindra eMax 22L: Quick Answers

Which has more horsepower, the Mahindra 1123 HST Cab or the Mahindra eMax 22L?

The Mahindra 1123 HST Cab leads on engine hp at 22.9 hp hp, compared to 22 hp hp for the Mahindra eMax 22L.

Which has more PTO horsepower, the Mahindra 1123 HST Cab or the Mahindra eMax 22L?

The Mahindra 1123 HST Cab leads on pto hp at 16.8 hp hp, compared to 14.9 hp hp for the Mahindra eMax 22L.

Which is heavier, the Mahindra 1123 HST Cab or the Mahindra eMax 22L?

The Mahindra 1123 HST Cab leads on weight at 1,962 lb lb, compared to 1,638 lb lb for the Mahindra eMax 22L.

Which has more loader lift capacity, the Mahindra 1123 HST Cab or the Mahindra eMax 22L?

The Mahindra eMax 22L leads on loader lift at 900 lb lb, compared to 794 lb lb for the Mahindra 1123 HST Cab.

Which has more three-point hitch lift capacity, the Mahindra 1123 HST Cab or the Mahindra eMax 22L?

The Mahindra eMax 22L leads on 3-pt lift (24 in) at 1,323 lb lb, compared to 771 lb lb for the Mahindra 1123 HST Cab.
