RK37S, RK37SC: single plate dry clutch, 8.86 in diameter; RK37H, RK37HC: electro-hydraulic PTO clutch assembly
Dry single plate
Differential Lock & Limited Slip Options
4WD with differential lock
Differential lock (pedal)
Frame Type
Unit frame. RK37S, RK37SC: transmission case, clutch, clutch housing, engine and front axle support bolted into one rigid unit; RK37H, RK37HC: transmission case, engine and front axle support bolted into one rigid unit
Unit frame: engine, clutch housing, transmission and front axle support bolted into one rigid assembly
Steering
Hydrostatic power steering
Hydrostatic
Brakes
Wet disc
Wet disc
Seat Suspension & Adjustability
Suspension seat with armrests & retractable seat belt
Fore and aft sliding seat with cushion strength adjustment
Front Axle Type
4WD, center-pivot reverse Eliot type
4WD center-pivot, reverse Elliott type
Front Axle Rating
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Overall Width
RK37S, RK37H: 53.5 in; RK37SC, RK37HC: 58.0 in
53.5 in
Wheelbase
RK37S, RK37H: 66.1 in; RK37SC, RK37HC: 64.5 in
66.9 in
Ground Clearance
12.8 in
12.8 in
Min. Turn Radius without Brakes
116 in
116 in
Height to Top of ROPS
RK37S, RK37H: 94.5 in
Not Published
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
RK37SC, RK37HC: 92.5 in
92.5 in
Overall Length
RK37S, RK37H: 126 in; RK37SC, RK37HC: 128 in
126 in (with 3-point hitch)
Tractor Weight (Base)
RK37S, RK37H: 3,020 lb; RK37SC, RK37HC: 3,417 lb
3,417 lb (weight with cab)
Weight with ROPS and Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Published
Tire Size & Options
R4 Industrial (standard): F 10-16.5, R 43x16-20; R1 Agricultural (optional): F 7-16, R 11.2x24; R3 Turf (optional): F 28x8.5-15, R 41x14-20; R14 (optional); Titan (USA)
Government and non-institutional: basic 24 months or 2,000 hours, powertrain 96 months or 3,000 hours; all other use: basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours
Basic 24 months or 2,000 hours, parts and labor; non-commercial: powertrain 72 months or 3,000 hours; rental and commercial: powertrain 36 months or 2,000 hours; loaders and backhoes 12 months
