Which has more horsepower, the TYM 4815 or the TYM 4820?

They are effectively tied: both machines are rated at 48 hp hp for engine hp.

Which has more PTO horsepower, the TYM 4815 or the TYM 4820?

The TYM 4815 leads on pto hp at 40 hp hp, compared to 38.4 hp hp for the TYM 4820.

Which has more loader lift capacity, the TYM 4815 or the TYM 4820?

The TYM 4820 leads on loader lift at 2,701 lb lb, compared to 2,200 lb lb for the TYM 4815.

Which has more three-point hitch lift capacity, the TYM 4815 or the TYM 4820?

They are effectively tied: both machines are rated at 2,425 lb lb for 3-pt lift (24 in).

TYM 4815 vs TYM 4820

Every published spec for both machines, side by side. The verdict below is computed straight from the spec sheets, not opinion.

Across 8 measurable specs, the TYM 4820 leads 4 categories to 1 (3 tied). Machine pages: TYM 4815 and TYM 4820.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Spec	TYM 4815	TYM 4820
Engine HP (hp)	48 hp	48 hp
PTO HP (hp)	▲ 40 hp	38.4 hp
Weight (lb)	4,286 lb	—
Loader Lift (lb)	2,200 lb	▲ 2,701 lb
3-Pt Lift (24 in) (lb)	2,425 lb	2,425 lb
Lift Height (in)	104.9 in	▲ 106.6 in
Breakout Force (lbf)	3,422 lbf	▲ 3,660 lbf
Hydraulic Flow (gpm)	16.5 gpm	16.5 gpm
Travel Speed (mph)	18.8 mph	▲ 19.5 mph

The headline numbers at a glance.

TYM 4815TYM 4820

Engine HPhp

▲48 hp

PTO HPhp

▲40 hp

38.4 hp

Weightlb

4,286 lb

—

Loader Liftlb

2,200 lb

▲2,701 lb

3-Pt Lift (24 in)lb

▲2,425 lb

Share↓ Image 𝕏 f ✉

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	TYM4815	TYM4820


PTO Power	40 hp	38.4 hp
Alternator	50 A, 12 V	50 A, 12 V
Air Cleaner	Dry element	Dry element
Engine Type	4-cylinder, naturally aspirated diesel	4-cylinder, naturally aspirated diesel
Fuel System	IDI	IDI
Displacement	139.6 in³	139.5 in³
No. of Cylinders	4	4
Rated Engine Speed	2600 rpm	2600 rpm
Cooling System Type	Not Published	Not Published
Engine Manufacturer	TYM	TYM
Engine Power (Gross)	48 hp	48 hp
Engine Emissions Constraints	Not Published	Tier 4

Weight with ROPS and Loader	4,286 lb	Not Published
Weight with Cab and Loader	Not Applicable	Not Applicable

Warranty Length & Coverage	Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.	Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.

Pump Type	Dual gear pump	Dual gear pump
Steering Flow	5.2 gpm	5.2 gpm
Implement Flow	11.4 gpm	11.4 gpm
Total Hydraulic Flow	16.5 gpm	16.5 gpm
Hydraulic System Type	Open center	Open center
Rear Remote Hydraulic Flow	Not Published	Not Published
Overall Hydraulic Pump Flow	16.5 gpm	16.5 gpm
No. of Optional Remote Valves	Not Published	Up to 4
No. of Standard Remote Valves	0	0

PTO Rear	540 rpm	540/750 rpm
PTO Type	Independent	Independent
Lift Control Type	Position control	Position control
Hitch Lift Capacity	3,306 lb	3,306 lb
Mid-PTO Availability	Not Published	Not Published
Category, 3-Point Hitch	Category I	Category I
Hitch Lift Capacity (at 24”)	2,425 lb	2,425 lb

R3 Turf - Rear	Not Published	41x14-20 / 44x18-20
R3 Turf - Front	Not Published	27x8.5-15 / 29x12.5-15
Tire Size & Options	R1 Agricultural, R4 Industrial	R1 Agricultural, R3 Turf, R4 Industrial
R4 Industrial - Rear	420/70×24	17.5Lx24
R4 Industrial - Front	10-16.5	12-16.5
R1 Agricultural - Rear	12.4-24	13.6-26
R1 Agricultural - Front	8.0-16	9.5-16

Coolant Capacity	5.8 qt	6.2 qt
Crankcase Capacity	4.8 qt	4.8 qt
Fuel Tank Capacity	7.1 gal	11.8 gal
Front Axle Fluid Capacity	6.8 qt	6.8 qt
Transmission / Hydraulic System Capacity	HST: 9.8 gal; Gear: 9 gal	HST: 11.1 gal; Gear: 10.3 gal

Loader Lift Height	104.9 in	106.6 in
Loader Breakout Force	3,422 lb	3,660 lb
Quick Attach Loader System	BL150: Quick attachment assembly	BL200: Quick attach assembly (lever-lock)
Loader Lift Capacity (Full Height)	2,200 lb	2,701 lb

Clutch	HST: No; Gear: Dry single type	HST: Not Applicable; Gear: Dry single plate
No. of Speeds	HST: 3-Range; Gear: 12F / 12R	HST: 4-Range; Gear: F16 x R16 (4-Range)
Transmission Type	HST: HST; Gear: Synchromesh	HST: HST; Gear: Synchromesh
Max Travel Speed (Forward)	HST: 18.8 mph; Gear: 14.9 mph	HST: 19.5 mph; Gear: 16 mph
Max Travel Speed (Reverse)	Not Published	Not Published
Differential Lock & Limited Slip Options	Differential lock	Differential lock system

Brakes	Wet, Multi disc	Wet, multi disc
Steering	Hydrostatic	Hydrostatic
Frame Type	Not Published	Not Published
Front Axle Type	Not Published	Not Published
Drawbar Capacity	Not Published	Not Published
Front Axle Rating	Not Published	Not Published
Seat Suspension & Adjustability	Comfortable suspension seat	Suspension seat

Wheelbase	65.7 in	71.1 in
Overall Width	56.3 in	64.9 in
Ground Clearance	14.4 in	15.5 in
Height to Top of ROPS	97.3 in	98.4 in
Height to Top of Cab Model	Not Applicable	Not Applicable
Height to Top of ROPS (folded)	Not Published	Not Published
Min. Turn Radius without Brakes	L: 124.8 in; R: 121.3 in	L: 128.7 in; R: 126.0 in
Overall Length with 3-Point Hitch	120.9 in	127.4 in

Accessories that fit	Brush Guard Side Guards $199.99 Bolt onto the side of the OEM guard and offers wrap around protection Branson TYM 15/20 Series--Bad Boy 40/50 Series Brush Screen $250.00	Brush Guard Side Guards $199.99 Bolt onto the side of the OEM guard and offers wrap around protection Branson TYM 15/20 Series--Bad Boy 40/50 Series Brush Screen $250.00 TYM 20 Series Protection Package $2150.00

TYM 4815 vs TYM 4820: Quick Answers

Which has more horsepower, the TYM 4815 or the TYM 4820?: They are effectively tied: both machines are rated at 48 hp hp for engine hp.
Which has more PTO horsepower, the TYM 4815 or the TYM 4820?: The TYM 4815 leads on pto hp at 40 hp hp, compared to 38.4 hp hp for the TYM 4820.
Which has more loader lift capacity, the TYM 4815 or the TYM 4820?: The TYM 4820 leads on loader lift at 2,701 lb lb, compared to 2,200 lb lb for the TYM 4815.
Which has more three-point hitch lift capacity, the TYM 4815 or the TYM 4820?: They are effectively tied: both machines are rated at 2,425 lb lb for 3-pt lift (24 in).
