Every published spec, side by side, including the details the graphs above don't chart.
Spec
TYMT4058PC
YanmarYT359
Engine Manufacturer
TYM
YANMAR
Engine Model
T2300T1-UTC_4
n/a
Engine Type
4-cylinder, turbocharged diesel
4-cylinder, naturally aspirated diesel
No. of Cylinders
4
4
Displacement
139.5 in³
202.5 in³
Rated Engine Speed
2600 rpm
2500 rpm
Engine Power (Gross)
58 hp
58.9 hp
PTO Power
48 hp
52 hp
Engine Emissions Constraints
Tier 4
Tier 4
Cooling System Type
Not Published
Liquid cooled
Air Cleaner
Dry element
Dual stage cyclonic (resin 6.5")
Fuel System
IDI (indirect injection)
Common rail direct injection
Alternator
70 A, 12 V
55 A, 12 V
Pump Type
Single gear pump
Not Published
Implement Flow
11.4 gpm
9.4 gpm
Steering Flow
5.13 gpm
5.3 gpm
Total Hydraulic Flow
16.5 gpm
14.7 gpm
Overall Hydraulic Pump Flow
16.5 gpm
14.7 gpm
Hydraulic System Type
Not Published
Open center
Rear Remote Hydraulic Flow
Not Published
Not Published
No. of Standard Remote Valves
Loader: 6; Rear: 6
2
No. of Optional Remote Valves
Not Published
1
Fuel Tank Capacity
15.3 gal
12.7 gal
Coolant Capacity
6.2 qt
7.8 qt
Crankcase Capacity
4.8 qt
8.0 qt
Transmission / Hydraulic System Capacity
11.62 gal
7.7 gal
Front Axle Fluid Capacity
6.8 qt
2.4 gal
PTO Type
Independent
Independent (electro-hydraulic)
PTO Rear
540 rpm
540 rpm
Mid-PTO Availability
Not Published
Not Published
Category, 3-Point Hitch
Category II
Category I
Hitch Lift Capacity
4,409 lb
3,307 lb
Hitch Lift Capacity (at 24”)
3,748 lb
2,756 lb
Lift Control Type
Position and draft control (electronic)
Position control
Transmission Type
Power shuttle
I-HMT (Integrated Hydro Mechanical Transmission)
No. of Speeds
F12 x R12
3 ranges (variable speed)
Max Travel Speed (Forward)
24.04 mph
18 mph
Max Travel Speed (Reverse)
19.39 mph
18 mph
Clutch
Wet, multi-disc
Clutch-less shifting (i-HMT)
Differential Lock & Limited Slip Options
Standard differential lock
Rear differential lock (foot pedal engagement)
Frame Type
Not Published
Not Published
Steering
Hydrostatic
Fully hydraulic power steering
Brakes
Wet, multi-disc
Mechanical wet disc
Seat Suspension & Adjustability
Suspension seat
Not Published
Front Axle Type
4WD (selectable 2WD/4WD)
Selectable 2WD/4WD engagement
Front Axle Rating
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Overall Length with 3-Point Hitch
141.5 in
132.1 in
Overall Width
68.9 in
70.6 in
Wheelbase
78.7 in
77.4 in
Ground Clearance
18.1 in
12.8 in
Min. Turn Radius without Brakes
L: 139.7 in; R: 141.9 in
Not Published
Height to Top of ROPS
Not Published
95.7 in
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
99.2 in
Not Applicable
Tractor Weight (Base)
4,951.5 lb
n/a
Weight with ROPS and Loader
Not Published
5,135 lb
Weight with Cab and Loader
6,251.5 lb
Not Applicable
Tire Size & Options
R1 Agricultural, R3 Turf (golf), R4 Industrial
R1 Agricultural; R3 Turf; R4 Industrial
R1 Agricultural - Front
9.5-20
8.0 - 16.0
R1 Agricultural - Rear
14.9-28
14.9 - 24.0
R3 Turf - Front
29x12.5-15
27.0 - 10.5
R3 Turf - Rear
44x18.00-20
44 x 18 - 20.0
R4 Industrial - Front
10.5/80-18
10.0 - 16.5
R4 Industrial - Rear
16.9-24
17.5L - 24.0
Quick Attach Loader System
L4058PC: Quick attach mechanism
YL610: Skid-steer-style loader quick attachment system
Loader Model
L4058PC
n/a
Loader Lift Height
L4058PC: 117.5 in
113 in
Loader Lift Capacity (Full Height)
L4058PC: 3,437 lb
2,500 lb
Loader Breakout Force
L4058PC: 4,742 lb
3,969 lb
Warranty Length & Coverage
Up to 2 years or until the 2,000 hour mark, bumper-to-bumper warranty; 3,000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes
Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours; Attachments: 1-year limited warranty
