▶ EnginePTO Power 18.1 hp — Alternator 40 A, 12 V — Air Cleaner Not Published — Engine Type 3-cylinder, naturally aspirated diesel — Fuel System Diesel — Displacement 77.2 in³ — No. of Cylinders 3 — Rated Engine Speed 3200 rpm — Cooling System Type Liquid cooled — Engine Manufacturer YANMAR — Engine Power (Gross) 23.9 hp — Engine Emissions Constraints Tier 4 — ▶ WeightWeight with ROPS and Loader 1,715 lb — Weight with Cab and Loader Not Applicable — ▶ WarrantyWarranty Length & Coverage Tractor (private individual usage): 24 months or 2,000 hours; Powertrain (engine and transmission core components): 10 years or 3,000 hours; Attachments: 1-year limited warranty — ▶ HydraulicsPump Type open center — Steering Flow 3.7 US gal/min — Implement Flow 4.3 US gal/min — Total Hydraulic Flow 8.0 gpm (implement + steering combined) — Hydraulic System Type Position Control, Open Center — Rear Remote Hydraulic Flow 4.3 gpm (implement circuit); 3.7 gpm dedicated to steering — Overall Hydraulic Pump Flow 8 gpm — No. of Optional Remote Valves Not Published — No. of Standard Remote Valves 2 (dual rear remote valves, standard) — ▶ PTO & HitchPTO Rear 1.4 in OD, 6 Splines; Independent; 554 RPM @ 3,200 Engine RPM — PTO Type Hydraulic Clutch, Independent — Lift Control Type Position Control — Hitch Lift Capacity 1,209 lb — Mid-PTO Availability SAE16/32, 15 Splines; Independent; 2,057 RPM @ 3,200 Engine RPM — Category, 3-Point Hitch Limited Category 1 — Hitch Lift Capacity (at 24”) 1,209 lb — ▶ Tire OptionsR3 Turf - Rear 33x12.5-16.5 4PR — R3 Turf - Front 23x8.50-12 4PR — Tire Size & Options R3 Turf or R4 Industrial standard; R4 front: 23x8.50-12 4PR, R4 rear: 12-16.5 10PR — R4 Industrial - Rear 12-16.5 10PR — R4 Industrial - Front 23x8.50-12 4PR — R1 Agricultural - Rear Not Applicable — R1 Agricultural - Front Not Applicable — ▶ Fluid CapacityCoolant Capacity 3.0 US qt — Crankcase Capacity 3.6 US qt — Fuel Tank Capacity 6.1 US gal — Front Axle Fluid Capacity 3.7 US gal — Transmission / Hydraulic System Capacity 4.1 US gal — ▶ Loader & AttachmentsLoader Lift Height 79 in. to pivot pin; 58 in. under level bucket — Loader Breakout Force 2,090 lb at pivot pin — Quick Attach Loader System Quick Attach — Loader Lift Capacity (Full Height) 1,200 lb at pivot pin — ▶ Transmission & DrivetrainClutch Not Applicable — No. of Speeds 2 ranges — Transmission Type Hydrostatic Transmission, Dual Range Speeds — Max Travel Speed (Forward) Low: 0-5.9 mph (0-5.8 mph), High: 0-12.3 mph (0-12.2 mph) — Max Travel Speed (Reverse) Low: 0-4.1 mph (0-4.1 mph), High: 0-8.5 mph (0-8.5 mph) — Differential Lock & Limited Slip Options Differential Lock — ▶ Chassis, Steering & ControlsBrakes Wet Disk — Steering Hydrostatic Power — Frame Type Full Frame Chassis — Front Axle Type Yanmar-designed 4WD front axle with oscillation — Drawbar Capacity Not Published — Front Axle Rating Not Published — Seat Suspension & Adjustability High-back seat with armrests on spring suspension platform; fore-and-aft adjustment; swivels for backhoe operation — ▶ Dimensions & ManeuverabilityWheelbase 63.0 in. — Overall Width 54.6 in. with R4 Tires — Ground Clearance 8.5 in. with R4 Tires — Height to Top of ROPS 85.8 in. with R4 Tires — Height to Top of Cab Model Not Applicable — Height to Top of ROPS (folded) 70.4 in. with Folded ROPS, R4 Tires, Top of Steering Wheel — Min. Turn Radius without Brakes 8.5 ft. (2.6 m) — Overall Length with 3-Point Hitch 105.8 in. —
