Bad Boy Tractors 1022 vs Kubota B2401

Across 5 measurable specs, the Kubota B2401 leads 4 categories to 1. Machine pages: Bad Boy Tractors 1022 and Kubota B2401.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	Bad Boy Tractors1022	KubotaB2401

▶Engine
PTO Power	15.4 hp	19.2 (14.3) HP (kW)
Alternator	40 A, 12 V	40 A
Air Cleaner	Single Dry	Dual paper element
Engine Type	Natural Aspiration	E-TVCS, liquid cooled, 3-cylinder diesel
Fuel System	Diesel	Radial air flow
Displacement	60.6 (993)	68.5 (1123) cu. in. (cc)
No. of Cylinders	3	3
Rated Engine Speed	3,200	2600 rpm
Cooling System Type	Water cooled	Liquid Cooled
Engine Manufacturer	Yanmar	Kubota
Engine Power (Gross)	21.5 hp	21.9 (16.3) HP (kW)
Engine Emissions Constraints	Tier 4	Tier 4
▶Weight
Tractor Weight (Base)	1,433 (650)	1,404 lbs.
Weight with ROPS and Loader	1,433 lb	1,521 lbs.
Weight with Cab and Loader	Not Published	—
▶Warranty
Warranty Length & Coverage	7-year powertrain warranty	Full warranty: 2 years / 2,000 hours; Powertrain warranty: 6 years / 2,000 hours
▶Hydraulics
Pump Type	Single Gear Pump with Flow Divider	Dual pump
Steering Flow	2.11 gpm	2.6 gpm 9.8 lpm
Implement Flow	4.17 (15.8)	4.0 gpm
Total Hydraulic Flow	6.97 (26.4)	7.0 (26.4) gpm (ℓ/min.)
Hydraulic System Type	Not Published	Open center
Rear Remote Hydraulic Flow	Not Published	Front & Rear outlet
Overall Hydraulic Pump Flow	6.97 gpm (max total flow)	7.0 (26.4) gpm (ℓ/min.)
No. of Optional Remote Valves	Up to 1	1
No. of Standard Remote Valves	Not Published	0
System Operating Pressure	—	2500 psi
▶PTO & Hitch
PTO Rear	540 rpm	540, 1000 rpm
PTO Type	Independent	Transmission driven with one way clutch
Lift Control Type	Position	Position control valve
Hitch Lift Capacity	1,100 lb	1653 (750) lbs. (kg)
Mid-PTO Availability	Optional (2,500 rpm)	2500 rpm
Category, 3-Point Hitch	Category I (N)	Category I
Hitch Lift Capacity (at 24”)	679 lb	1808 (820) lbs. (kg); 1411 (640) lbs. (kg); 1290 (585) lbs. (kg)
▶Tire Options
R3 Turf - Rear	TURF R 16X12.00-12	33x12.5-15
R3 Turf - Front	TURF F 16X7.50-8	23x8.50-12
Tire Size & Options	R1 (BAR) / R3 (TURF) / R4 (IND)	—
R4 Industrial - Rear	26X12-12	—
R4 Industrial - Front	18X8.50-10	—
R1 Agricultural - Rear	BAR R 24X12.00-12	9.5-16
R1 Agricultural - Front	BAR F 16X7.50-9	6-12
▶Fluid Capacity
Coolant Capacity	0.9 gal	4.0 (3.8) qts. (ℓ)
Crankcase Capacity	0.48 gal	3.3 (3.1) qts. (ℓ)
Fuel Tank Capacity	6.6 gal	6.1 gal.
Front Axle Fluid Capacity	2.6 qt	—
Transmission / Hydraulic System Capacity	3.6 gal	3.3 (12.5) gal (ℓ)
▶Loader & Attachments
Loader Lift Height	72.7 in (under level bucket); 78.5 in (pivot pin)	78.5"
Loader Breakout Force	1,531 lb (at pivot pin, ground level)	2,146 lbf.
Quick Attach Loader System	SSQA	LA435 Swift-Tach Loader; 1-lever Quick Coupler (standard); 2-Lever Quick Coupler (optional)
Loader Lift Capacity (Full Height)	992 lb (at pivot pin)	1,175 lbs.
▶Transmission & Drivetrain
Clutch	Dry single plate	Dry single plate
No. of Speeds	2 Range	9 Forward, 3 Reverse
Transmission Type	Hydrostatic transmission (HST)	Gear (9 Forward, 3 Reverse)
Max Travel Speed (Forward)	7.8 mph	0-11.7 (0-18.8) mph (km/h)
Max Travel Speed (Reverse)	Not Published	0-6.0 (0-9.6) mph (km/h)
Differential Lock & Limited Slip Options	Mechanical rear differential lock	Standard
▶Chassis, Steering & Controls
Brakes	Wet disc	Multi-plate wet disc
Steering	Hydrostatic	Integral type power steering
Frame Type	Sub-compact tractor, 4WD	—
Front Axle Type	Center pin front axle	Cast-iron front axle
Drawbar Capacity	Not Published	661.4 lb (660 lbs)
Front Axle Rating	Not Published	—
Seat Suspension & Adjustability	Standard adjustable seat	High-back seat (absorbs shock); NOTE: Deluxe seat with armrests and seat suspension listed for HST models only - not explicitly confirmed for B2401 gear-drive (DT) in spec sheet
▶Dimensions & Maneuverability
Wheelbase	53.1 (1,350)	61.4 (1560) in. (mm)
Overall Width	44.5 (1,130)	44.3 (1125) in. (mm)
Overall Length	94.2 (2,394)	93.9 in / 93.9 in
Ground Clearance	8.3 in.	12.0 (305) in. (mm)
Height to Top of ROPS	86.6 (2,200)	83.9 in.
Height to Top of Cab Model	Not Published	—
Height to Top of ROPS (folded)	Not Published	—
Min. Turn Radius without Brakes	86.6 (2,200)	6.9 (2.1) feet (m)
Overall Length with 3-Point Hitch	94.2 in	93.9 in.
▶ITC Company Accessories
Accessories that fit	None tagged yet	Kubota B2301/B2401/B2601 Brush Guard Insert Kit $259.00 Messick's partnership, staged by migration 0118

Bad Boy Tractors 1022 vs Kubota B2401: Quick Answers

Which is heavier, the Bad Boy Tractors 1022 or the Kubota B2401?

The Bad Boy Tractors 1022 leads on weight at 1,433 lb lb, compared to 1,404 lb lb for the Kubota B2401.

Which has more loader lift capacity, the Bad Boy Tractors 1022 or the Kubota B2401?

The Kubota B2401 leads on loader lift at 1,175 lb lb, compared to 992 lb lb for the Bad Boy Tractors 1022.
