Bad Boy Tractors 4035 Cab vs John Deere 2032R

Across 8 measurable specs, the Bad Boy Tractors 4035 Cab leads 8 categories to 0. Machine pages: Bad Boy Tractors 4035 Cab and John Deere 2032R.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	Bad Boy Tractors4035 Cab	John Deere2032R

▶Engine
Engine Manufacturer	TYM	Yanmar
Engine Model	A1700N4-BUTC_4	3TNV88C-NJT2
Engine Type	Vertical, water-cooled 4-cycle diesel	Diesel
No. of Cylinders	3	3
Displacement	104.5 in³	100.2 in³
Rated Engine Speed	2600 rpm	2500 rpm
Engine Power (Gross)	35 hp	31.2 hp
PTO Power	29.5 hp	24.2 hp
Engine Emissions Constraints	Not Published	Not Published
Cooling System Type	Water-cooled	Liquid-cooled
Air Cleaner	Not Published	Dual element
Fuel System	Not Published	Direct injection
Alternator	50 A, 12 V	85 A
▶Hydraulics
Pump Type	Not Published	Tandem gear
Implement Flow	8.2 gpm	5.3 gpm
Steering Flow	4.4 gpm	4 gpm
Total Hydraulic Flow	12.6 gpm	9.3 gpm
Overall Hydraulic Pump Flow	12.6 gpm	9.3 gpm
Hydraulic System Type	Open center	Open center
Rear Remote Hydraulic Flow	Not Published	Not Published
No. of Standard Remote Valves	Not Published	Not Published
No. of Optional Remote Valves	Up to 2	Not Published
▶Fluid Capacity
Fuel Tank Capacity	7.13 gal	8.5 gal
Coolant Capacity	1.32 gal	4.2 qt
Crankcase Capacity	1.14 gal	4.5 qt
Transmission / Hydraulic System Capacity	9.77 gal	24.8 qt
Front Axle Fluid Capacity	1.69 gal	4 qt
▶PTO & Hitch
PTO Type	Independent	Independent
PTO Rear	540 rpm	540 rpm
Mid-PTO Availability	Not Published	2000 rpm
Category, 3-Point Hitch	Category I	Category 1
Hitch Lift Capacity	3,307 lb	1,433 lb
Hitch Lift Capacity (at 24”)	2,425 lb	1,356 lb
Lift Control Type	Position control	Position Control
▶Transmission & Drivetrain
Transmission Type	Hydrostatic (HST), 3-range	Hydrostatic
No. of Speeds	3 range (HST)	Infinite (2-range)
Max Travel Speed (Forward)	18.21 mph	Not Published
Max Travel Speed (Reverse)	18.21 mph	Not Published
Clutch	None (HST)	Not Published
Differential Lock & Limited Slip Options	Rear differential lock	Differential lock
▶Chassis, Steering & Controls
Frame Type	Not Published	Foldable ROPS
Steering	Electro-hydraulic power steering	Power
Brakes	Wet, multi-disc	Wet Disc
Seat Suspension & Adjustability	Heated leather seat (cab)	Not Published
Front Axle Type	Selectable 4WD	Not Published
Front Axle Rating	Not Published	1,940 lb
Drawbar Capacity	Not Published	Not Published
▶Dimensions & Maneuverability
Overall Width	55.6 in	55.1 in
Wheelbase	65.7 in	67.8 in
Ground Clearance	13.19 in	9.8 in (front axle)
Min. Turn Radius without Brakes	Not Published	98.4 in
Height to Top of ROPS	Not Published	92.3 in (R4 tires)
Height to Top of ROPS (folded)	Not Published	67.5 in
Height to Top of Cab Model	85.9 in	Not Published
Overall Length	134.88 in	117.5 in (with 3-point hitch)
▶Weight
Tractor Weight (Base)	3,551 lb	2,879 lb (with all fluids)
Weight with ROPS and Loader	Not Published	Not Published
Weight with Cab and Loader	Not Published	Not Published
▶Tire Options
Tire Size & Options	R1 ag 7-16 / 11.2-24 (standard); R4 industrial 28x8.50-15 / 43x16.00-20	R1 Ag, R3 Turf, R4 Industrial, R3 Turf Radial
R1 Agricultural - Front	7-16	Not Published
R1 Agricultural - Rear	11.2-24	Not Published
R3 Turf - Front	Not Published	23X8.50-14
R3 Turf - Rear	Not Published	14-17.5
R4 Industrial - Front	28x8.50-15	23x8.50-14
R4 Industrial - Rear	43x16.00-20	14-17.5
▶Loader & Attachments
Quick Attach Loader System	SSQA	220R Loader (Quik-Park)
Loader Model	BBL400	220R
Loader Lift Height	104 in	220R: 85 in (at pivot pin)
Loader Lift Capacity (Full Height)	2,200 lb (at pivot pin)	220R: 1,120 lb (at pivot pin, full height)
Loader Breakout Force	3,660 lb	220R: 1,949 lbf (at pivot pin)
▶Warranty
Warranty Length & Coverage	Basic 24 months or 1,000 hours; powertrain 72 months or 2,000 hours	Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours
▶ITC Company Accessories
Accessories that fit	Brush Guard Side Guards $199.99 Bolt onto the side of the OEM guard and offers wrap around protection Branson TYM 15/20 Series--Bad Boy 40/50 Series Brush Screen $250.00 Branson / TYM 15 Series Fuel Tank Cover $250.00	None tagged yet

Find a Bad Boy dealer near you→Find a John Deere dealer near you→

Bad Boy Tractors 4035 Cab vs John Deere 2032R: Quick Answers

Which has more horsepower, the Bad Boy Tractors 4035 Cab or the John Deere 2032R?

The Bad Boy Tractors 4035 Cab leads on engine hp at 35 hp hp, compared to 31.2 hp hp for the John Deere 2032R.

Which has more PTO horsepower, the Bad Boy Tractors 4035 Cab or the John Deere 2032R?

The Bad Boy Tractors 4035 Cab leads on pto hp at 29.5 hp hp, compared to 24.2 hp hp for the John Deere 2032R.

Which is heavier, the Bad Boy Tractors 4035 Cab or the John Deere 2032R?

The Bad Boy Tractors 4035 Cab leads on weight at 3,551 lb lb, compared to 2,879 lb lb for the John Deere 2032R.

Which has more loader lift capacity, the Bad Boy Tractors 4035 Cab or the John Deere 2032R?

The Bad Boy Tractors 4035 Cab leads on loader lift at 2,200 lb lb, compared to 1,120 lb lb for the John Deere 2032R.

Which has more three-point hitch lift capacity, the Bad Boy Tractors 4035 Cab or the John Deere 2032R?

The Bad Boy Tractors 4035 Cab leads on 3-pt lift (24 in) at 2,425 lb lb, compared to 1,356 lb lb for the John Deere 2032R.
