Bad Boy Tractors 4035 Cab vs Mahindra Max 26XL

Across 9 measurable specs, the Bad Boy Tractors 4035 Cab leads 9 categories to 0. Machine pages: Bad Boy Tractors 4035 Cab and Mahindra Max 26XL.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	Bad Boy Tractors4035 Cab	MahindraMax 26XL

▶Engine
Engine Manufacturer	TYM	Mitsubishi
Engine Model	A1700N4-BUTC_4	S3L2
Engine Type	Vertical, water-cooled 4-cycle diesel	Four-stroke, indirect injection, water-cooled diesel
No. of Cylinders	3	3
Displacement	104.5 in³	80.4 in³
Rated Engine Speed	2600 rpm	2600 rpm
Engine Power (Gross)	35 hp	25.6 hp
PTO Power	29.5 hp	HST: 20 hp; Shuttle: 21.5 hp
Engine Emissions Constraints	Not Published	Tier 4
Cooling System Type	Water-cooled	Water-cooled
Air Cleaner	Not Published	Not Published
Fuel System	Not Published	Indirect injection
Alternator	50 A, 12 V	50 A, 12 V
▶Hydraulics
Pump Type	Not Published	Not Published
Implement Flow	8.2 gpm	5.8 gpm
Steering Flow	4.4 gpm	2.7 gpm
Total Hydraulic Flow	12.6 gpm	8.5 gpm (5.8 + 2.7, computed)
Overall Hydraulic Pump Flow	12.6 gpm	8.5 gpm (5.8 + 2.7, computed)
Hydraulic System Type	Open center	Open center
Rear Remote Hydraulic Flow	Not Published	Not Published
No. of Standard Remote Valves	Not Published	Not Published
No. of Optional Remote Valves	Up to 2	1
▶Fluid Capacity
Fuel Tank Capacity	7.13 gal	6.1 gal
Coolant Capacity	1.32 gal	Not Published
Crankcase Capacity	1.14 gal	Not Published
Transmission / Hydraulic System Capacity	9.77 gal	Not Published
Front Axle Fluid Capacity	1.69 gal	Not Published
▶PTO & Hitch
PTO Type	Independent	Live (HST); Trans (Shuttle)
PTO Rear	540 rpm	540 rpm @ 2376 rpm
Mid-PTO Availability	Not Published	2000 @ 2526 rpm
Category, 3-Point Hitch	Category I	Category I
Hitch Lift Capacity	3,307 lb	2,205 lb
Hitch Lift Capacity (at 24”)	2,425 lb	Not Published
Lift Control Type	Position control	Position control
▶Transmission & Drivetrain
Transmission Type	Hydrostatic (HST), 3-range	HST: HST, 2 ranges; Shuttle: synchro-mesh F/R shuttle, constant-mesh gear
No. of Speeds	3 range (HST)	Infinite (HST); 8F / 8R (Shuttle)
Max Travel Speed (Forward)	18.21 mph	10.0 mph (HST); 11.2 mph (Shuttle)
Max Travel Speed (Reverse)	18.21 mph	5.1 mph (HST); 9.4 mph (Shuttle)
Clutch	None (HST)	Single plate, dry
Differential Lock & Limited Slip Options	Rear differential lock	Not Published
▶Chassis, Steering & Controls
Frame Type	Not Published	Full-length tractor frame
Steering	Electro-hydraulic power steering	Hydrostatic power steering
Brakes	Wet, multi-disc	Wet disc
Seat Suspension & Adjustability	Heated leather seat (cab)	Not Published
Front Axle Type	Selectable 4WD	Not Published
Front Axle Rating	Not Published	Not Published
Drawbar Capacity	Not Published	Not Published
▶Dimensions & Maneuverability
Overall Width	55.6 in	54.3 in
Wheelbase	65.7 in	Not Published
Ground Clearance	13.19 in	Not Published
Min. Turn Radius without Brakes	Not Published	6.6 ft
Height to Top of ROPS	Not Published	84.3 in (with industrial tires)
Height to Top of ROPS (folded)	Not Published	Not Published
Height to Top of Cab Model	85.9 in	Not Published
Overall Length	134.88 in	109.3 in
▶Weight
Tractor Weight (Base)	3,551 lb	1,863 lb (HST); 1,819 lb (Shuttle) (operating weight)
Weight with ROPS and Loader	Not Published	Not Published
Weight with Cab and Loader	Not Published	Not Published
▶Tire Options
Tire Size & Options	R1 ag 7-16 / 11.2-24 (standard); R4 industrial 28x8.50-15 / 43x16.00-20	Ag, Industrial, Turf
R1 Agricultural - Front	7-16	7x12
R1 Agricultural - Rear	11.2-24	9.5x16
R3 Turf - Front	Not Published	23x8.5-12
R3 Turf - Rear	Not Published	33x12.5-16.5
R4 Industrial - Front	28x8.50-15	23x8.5-12
R4 Industrial - Rear	43x16.00-20	12x16.5
▶Loader & Attachments
Quick Attach Loader System	SSQA	Not Published
Loader Model	BBL400	Max 26L
Loader Lift Height	104 in	Max 26L: 82.7 in
Loader Lift Capacity (Full Height)	2,200 lb (at pivot pin)	Max 26L: 1,402 lb (at pivot pin)
Loader Breakout Force	3,660 lb	Max 26L: 2,690 lb (at pivot pin)
▶Warranty
Warranty Length & Coverage	Basic 24 months or 1,000 hours; powertrain 72 months or 2,000 hours	7-year limited powertrain warranty
▶ITC Company Accessories
Accessories that fit	Brush Guard Side Guards $199.99 Bolt onto the side of the OEM guard and offers wrap around protection Branson TYM 15/20 Series--Bad Boy 40/50 Series Brush Screen $250.00 Branson / TYM 15 Series Fuel Tank Cover $250.00	None tagged yet

Find a Bad Boy dealer near you→Find a Mahindra dealer near you→

Bad Boy Tractors 4035 Cab vs Mahindra Max 26XL: Quick Answers

Which has more horsepower, the Bad Boy Tractors 4035 Cab or the Mahindra Max 26XL?

The Bad Boy Tractors 4035 Cab leads on engine hp at 35 hp hp, compared to 25.6 hp hp for the Mahindra Max 26XL.

Which has more PTO horsepower, the Bad Boy Tractors 4035 Cab or the Mahindra Max 26XL?

The Bad Boy Tractors 4035 Cab leads on pto hp at 29.5 hp hp, compared to 21.5 hp hp for the Mahindra Max 26XL.

Which is heavier, the Bad Boy Tractors 4035 Cab or the Mahindra Max 26XL?

The Bad Boy Tractors 4035 Cab leads on weight at 3,551 lb lb, compared to 1,863 lb lb for the Mahindra Max 26XL.

Which has more loader lift capacity, the Bad Boy Tractors 4035 Cab or the Mahindra Max 26XL?

The Bad Boy Tractors 4035 Cab leads on loader lift at 2,200 lb lb, compared to 1,402 lb lb for the Mahindra Max 26XL.

Which has more three-point hitch lift capacity, the Bad Boy Tractors 4035 Cab or the Mahindra Max 26XL?

The Bad Boy Tractors 4035 Cab leads on 3-pt lift (24 in) at 2,425 lb lb, compared to 2,205 lb lb for the Mahindra Max 26XL.
