Bad Boy Tractors 5045 Cab vs Case IH Farmall 50A

Across 8 measurable specs, the Case IH Farmall 50A leads 6 categories to 2. Machine pages: Bad Boy Tractors 5045 Cab and Case IH Farmall 50A.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	Bad Boy Tractors5045 Cab	Case IHFarmall 50A

▶Engine
Engine Manufacturer	TYM	FPT
Engine Model	A2300N3	R 753 IE4
Engine Type	4 cylinder water-cooled diesel, naturally aspirated	3-cylinder, FPT turbocharged & aftercooled
No. of Cylinders	4	3
Displacement	139.5 in³	135.9 in³
Rated Engine Speed	2600 rpm	2600 rpm
Engine Power (Gross)	48 hp	53 hp
PTO Power	38.4 hp	45 hp
Engine Emissions Constraints	Tier 4	Tier 4
Cooling System Type	Water-cooled	Liquid-cooled
Air Cleaner	Dry element	Dry
Fuel System	Not Published	Electronic high pressure common rail
Alternator	70 A, 12 V	75 A
▶Hydraulics
Pump Type	Not Published	Engine-driven dual gear-type
Implement Flow	10.7 gpm	11.9 gpm
Steering Flow	5 gpm	5.5 gpm
Total Hydraulic Flow	15.7 gpm	17.4 gpm (11.9 + 5.5, computed)
Overall Hydraulic Pump Flow	15.7 gpm	Not Published
Hydraulic System Type	Open center	Open center
Rear Remote Hydraulic Flow	Not Published	Not Published
No. of Standard Remote Valves	4 ports	1
No. of Optional Remote Valves	Not Published	2
▶Fluid Capacity
Fuel Tank Capacity	11.8 gal	17.2 gal
Coolant Capacity	1.56 gal	Not Published
Crankcase Capacity	1.20 gal	Not Published
Transmission / Hydraulic System Capacity	10.04 gal	Not Published
Front Axle Fluid Capacity	1.90 gal	Not Published
▶PTO & Hitch
PTO Type	Independent	Independent
PTO Rear	540 / 540E rpm	540 / 540E
Mid-PTO Availability	Not Published	Not Published
Category, 3-Point Hitch	Category I	Category I/II
Hitch Lift Capacity	3,306 lb	Not Published
Hitch Lift Capacity (at 24”)	2,425 lb	2,701 lb
Lift Control Type	Position control	Mechanical Draft Control (MDC), top link sensing
▶Transmission & Drivetrain
Transmission Type	Hydrostatic (HST), 4-range	8x8 mechanical shuttle (dry clutch)
No. of Speeds	4 range (HST)	8 forward / 8 reverse
Max Travel Speed (Forward)	19.5 mph	Not Published
Max Travel Speed (Reverse)	19.5 mph	Not Published
Clutch	None (HST)	Dry clutch
Differential Lock & Limited Slip Options	Rear differential lock (standard)	Mechanical rear differential lock; limited-slip MFD front axle
▶Chassis, Steering & Controls
Frame Type	Compact utility tractor, 4WD	Not Published
Steering	Hydrostatic power steering	Hydrostatic steering
Brakes	Wet, multi-disc	Wet disc
Seat Suspension & Adjustability	Heated leather seat (cab)	Not Published
Front Axle Type	Selectable 4WD	2WD or MFD with limited slip
Front Axle Rating	Not Published	Not Published
Drawbar Capacity	Not Published	Not Published
▶Dimensions & Maneuverability
Overall Width	64.9 in	67.5 in
Wheelbase	71.1 in	MFD: 77.7 in; 2WD: 77.5 in
Ground Clearance	15.5 in	Not Published
Min. Turn Radius without Brakes	9.18 ft (with brake applied)	MFD: 190.9 in; 2WD: 135.8 in
Height to Top of ROPS	Not Published	MFD: 97.4 in; 2WD: 92.7 in
Height to Top of ROPS (folded)	Not Published	75.9 in
Height to Top of Cab Model	97.0 in	Not Published
Overall Length	127.4 in (with 3-point hitch)	MFD: 134.0 in; 2WD: 129.5 in
▶Weight
Tractor Weight (Base)	4,349 lb	MFD: 5,060 lb; 2WD: 4,442 lb
Weight with ROPS and Loader	Not Published	Not Published
Weight with Cab and Loader	Not Published	Not Published
▶Tire Options
Tire Size & Options	9.5-16 front / 13.6-26 rear (ag)	R1 agricultural (bar tread) or R4 industrial tread
R1 Agricultural - Front	9.5-16	MFD: 8.3x24; 2WD: 7.5x16
R1 Agricultural - Rear	13.6-26	MFD: 13.6x28; 2WD: 13.6x28
R3 Turf - Front	Not Published	Not Published
R3 Turf - Rear	Not Published	Not Published
R4 Industrial - Front	Not Published	MFD: 12.5x18
R4 Industrial - Rear	Not Published	MFD: 18.4x24
▶Loader & Attachments
Quick Attach Loader System	SSQA	Compatible loaders: L545, L555
Loader Model	BBL500	L545; L555
Loader Lift Height	106.6 in	L545: 106 in; L555: 105 in
Loader Lift Capacity (Full Height)	2,700 lb (at pivot pin)	L545 NSL: 1,565 lb; L545 MSL: 2,205 lb; L555 NSL: 1,940 lb; L555 MSL: 2,734 lb
Loader Breakout Force	3,660 lb	L545: 3,131 lb; L555: 3,527 lb
▶Warranty
Warranty Length & Coverage	Basic 24 months or 1,000 hours; powertrain 72 months or 2,000 hours	Not Published
▶ITC Company Accessories
Accessories that fit	Brush Guard Side Guards $199.99 Bolt onto the side of the OEM guard and offers wrap around protection Branson TYM 15/20 Series--Bad Boy 40/50 Series Brush Screen $250.00	None tagged yet

Find a Bad Boy dealer near you→Find a Case IH dealer near you→

Bad Boy Tractors 5045 Cab vs Case IH Farmall 50A: Quick Answers

Which has more horsepower, the Bad Boy Tractors 5045 Cab or the Case IH Farmall 50A?

The Case IH Farmall 50A leads on engine hp at 53 hp hp, compared to 48 hp hp for the Bad Boy Tractors 5045 Cab.

Which has more PTO horsepower, the Bad Boy Tractors 5045 Cab or the Case IH Farmall 50A?

The Case IH Farmall 50A leads on pto hp at 45 hp hp, compared to 38.4 hp hp for the Bad Boy Tractors 5045 Cab.

Which is heavier, the Bad Boy Tractors 5045 Cab or the Case IH Farmall 50A?

The Case IH Farmall 50A leads on weight at 5,060 lb lb, compared to 4,349 lb lb for the Bad Boy Tractors 5045 Cab.

Which has more loader lift capacity, the Bad Boy Tractors 5045 Cab or the Case IH Farmall 50A?

The Case IH Farmall 50A leads on loader lift at 2,734 lb lb, compared to 2,700 lb lb for the Bad Boy Tractors 5045 Cab.

Which has more three-point hitch lift capacity, the Bad Boy Tractors 5045 Cab or the Case IH Farmall 50A?

The Case IH Farmall 50A leads on 3-pt lift (24 in) at 2,701 lb lb, compared to 2,425 lb lb for the Bad Boy Tractors 5045 Cab.
