| PTO Power | 21.8 hp | NOT FOUND |
|---|
| Alternator | Not Published | 42 A, 12 V |
|---|
| Air Cleaner | Not Published | Dry with Clogging Sensor |
|---|
| Engine Type | Diesel | 3-Cylinder Diesel Engine |
|---|
| Fuel System | Not Published | — |
|---|
| Displacement | 97.6 in³ | 80.5 in³ |
|---|
| No. of Cylinders | 3 | 3 |
|---|
| Rated Engine Speed | 2400 rpm | 2500 rpm |
|---|
| Cooling System Type | Not Published | NOT FOUND — no cooling system type explicitly stated for the H26 in any retrieved source |
|---|
| Engine Manufacturer | Not Published | Mitsubishi |
|---|
| Engine Power (Gross) | 24.5 hp | 26 hp |
|---|
| Engine Emissions Constraints | Not Published | NOT FOUND |
|---|
| Engine Model | — | NOT FOUND |
|---|
|
|---|
| Weight with ROPS and Loader | Not Published | — |
|---|
| Weight with Cab and Loader | Not Applicable | — |
|---|
|
|---|
| Warranty Length & Coverage | 24 months / 1,500 hours (whichever occurs first) | — |
|---|
|
|---|
| Pump Type | Not Published | — |
|---|
| Steering Flow | 4.5 gpm | — |
|---|
| Implement Flow | 6.9 gpm | — |
|---|
| Total Hydraulic Flow | 11.4 gpm | — |
|---|
| Hydraulic System Type | Not Published | — |
|---|
| Rear Remote Hydraulic Flow | Not Published | — |
|---|
| Overall Hydraulic Pump Flow | 11.4 gpm | — |
|---|
| No. of Optional Remote Valves | 2 pairs (optional) | 3 DA (Cabin) |
|---|
| No. of Standard Remote Valves | Not Published | 1 DA |
|---|
|
|---|
| PTO Rear | 540 rpm | — |
|---|
| PTO Type | Live | — |
|---|
| Lift Control Type | Hydraulic position control system | NOT FOUND |
|---|
| Hitch Lift Capacity | 1,631 lb | — |
|---|
| Mid-PTO Availability | 1,976 rpm (optional) | Yes - Mid & Rear PTO standard |
|---|
| Category, 3-Point Hitch | Category 1 | — |
|---|
| Hitch Lift Capacity (at 24”) | 1,631 lb | — |
|---|
|
|---|
| R3 Turf - Rear | Not Published | 13.80-16 |
|---|
| R3 Turf - Front | Not Published | 25x8.50-14 |
|---|
| Tire Size & Options | Not Published | — |
|---|
| R4 Industrial - Rear | Not Published | 33x15.50-16.5 |
|---|
| R4 Industrial - Front | Not Published | 23x8.50-12 |
|---|
| R1 Agricultural - Rear | Not Published | 280/70 R18 |
|---|
| R1 Agricultural - Front | Not Published | 6.5/80-12 | 280/70 R18 |
|---|
|
|---|
| Coolant Capacity | Not Published | — |
|---|
| Crankcase Capacity | Not Published | — |
|---|
| Fuel Tank Capacity | 9.0 gal | — |
|---|
| Front Axle Fluid Capacity | Rear (Std); Mid (optional) | — |
|---|
| Transmission / Hydraulic System Capacity | Not Published | — |
|---|
|
|---|
| Loader Lift Height | Not Published | — |
|---|
| Loader Breakout Force | Not Published | NOT FOUND |
|---|
| Quick Attach Loader System | Standard quick attach mounting system | YES optional |
|---|
| Loader Lift Capacity (Full Height) | 1,369 lb | — |
|---|
|
|---|
| Clutch | Not Published | Wet Type Clutch for PTO |
|---|
| No. of Speeds | Infinite, 3-range (HST); 9F x 3R (MST) | 2-speed hydrostatic |
|---|
| Transmission Type | 3-range HST (HST); Manual 9F x 3R (MST) | Hydrostatic |
|---|
| Max Travel Speed (Forward) | 9.7 mph (15.6 km/hr) (HST); 9.4 mph (15.2 km/hr) (MST) | 21.03 Km/Hr @2660 |
|---|
| Max Travel Speed (Reverse) | 8.7 mph (14.0 km/hr) (HST); 6.2 mph (9.9 km/hr) (MST) | NOT FOUND |
|---|
| Differential Lock & Limited Slip Options | Std | — |
|---|
|
|---|
| Brakes | Wet multi-disc | — |
|---|
| Steering | Hydrostatic power steering | Power Steering |
|---|
| Frame Type | Not Published | — |
|---|
| Front Axle Type | Not Published | 4WD |
|---|
| Drawbar Capacity | Not Published | — |
|---|
| Front Axle Rating | Not Published | — |
|---|
| Seat Suspension & Adjustability | Adjustable seat (Std) | Suspended seat with: suspension adjustment knob (knob 2), vertical height adjustment knob (knob 3), horizontal fore/aft lever (lever 1); operator weight range adjustable 50-308.6 lbf |
|---|
|
|---|
| Wheelbase | 65.7 in | 61.8 in |
|---|
| Overall Width | 62.4 in | — |
|---|
| Ground Clearance | 11.7 in | — |
|---|
| Height to Top of ROPS | 92.2 in | 92.5 in |
|---|
| Height to Top of Cab Model | Not Applicable | NOT FOUND — H26 is listed as ROPS-only in all sources; no cab model height found |
|---|
| Height to Top of ROPS (folded) | Not Published | NOT FOUND |
|---|
| Min. Turn Radius without Brakes | 96.5 in | — |
|---|
| Overall Length with 3-Point Hitch | 120.9 in | — |
|---|
|
|---|
