Case IH Farmall 35A vs Case IH Farmall 35A Mechanical

Every published spec for both machines, side by side. The verdict below is computed straight from the spec sheets, not opinion.

Across 9 measurable specs, this matchup is a dead heat: 1 categories to the Case IH Farmall 35A, 1 to the Case IH Farmall 35A Mechanical, 7 tied. Machine pages: Case IH Farmall 35A and Case IH Farmall 35A Mechanical.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Spec	Case IH Farmall 35A	Case IH Farmall 35A Mechanical
Engine HP (hp)	35 hp	35 hp
PTO HP (hp)	30.1 hp	▲ 31 hp
Weight (lb)	3,042 lb	3,042 lb
Loader Lift (lb)	890 lb	890 lb
3-Pt Lift (24 in) (lb)	1,596 lb	1,596 lb
Lift Height (in)	98 in	98 in
Breakout Force (lbf)	1,900 lbf	1,900 lbf
Hydraulic Flow (gpm)	13.3 gpm	13.3 gpm
Travel Speed (mph)	▲ 14.8 mph	14.2 mph

The headline numbers at a glance.

Case IH Farmall 35ACase IH Farmall 35A Mechanical

Engine HPhp

▲35 hp

PTO HPhp

30.1 hp

▲31 hp

Weightlb

▲3,042 lb

Loader Liftlb

▲890 lb

3-Pt Lift (24 in)lb

▲1,596 lb

Share↓ Image 𝕏 f ✉

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	Case IHFarmall 35A	Case IHFarmall 35A Mechanical


Engine Manufacturer	LS Mtron	LS Mtron
Engine Model	Not Published	Not Published
Engine Type	3-cylinder, Tier 4 B/Final	3-cylinder, Tier 4 B/Final
No. of Cylinders	3	3
Displacement	114.7 in³	114.7 in³
Rated Engine Speed	2600 rpm	2600 rpm
Engine Power (Gross)	35 hp	35 hp
PTO Power	30.1 hp	31 hp
Engine Emissions Constraints	Tier 4	Tier 4
Cooling System Type	Not Published	Not Published
Air Cleaner	Not Published	Not Published
Fuel System	Not Published	Not Published
Alternator	85 A, 12 V	Not Published

Pump Type	Not Published	Not Published
Implement Flow	8.4 gpm	8.4 gpm
Steering Flow	Not Published	Not Published
Total Hydraulic Flow	13.3 gpm	13.3 gpm
Overall Hydraulic Pump Flow	Not Published	Not Published
Hydraulic System Type	Open center	Open center
Rear Remote Hydraulic Flow	Not Published	Not Published
No. of Standard Remote Valves	0	0
No. of Optional Remote Valves	3	3

Fuel Tank Capacity	12.6 gal	12.6 gal
Coolant Capacity	Not Published	Not Published
Crankcase Capacity	Not Published	Not Published
Transmission / Hydraulic System Capacity	Not Published	Not Published
Front Axle Fluid Capacity	Not Published	Not Published

PTO Type	Independent, electro-hydraulic engagement	Independent, electro-hydraulic engagement
PTO Rear	540 rpm	540 rpm
Mid-PTO Availability	Optional, 2,000 rpm	Not Published
Category, 3-Point Hitch	Category I	Category I
Hitch Lift Capacity	Not Published	Not Published
Hitch Lift Capacity (at 24”)	1,596 lb	1,596 lb
Lift Control Type	Mechanical Draft Control (MDC)	Mechanical Draft Control (MDC)

Transmission Type	3-range hydrostatic (optional)	12x12 mechanical shuttle with synchro shift (dry clutch) (standard)
No. of Speeds	3 ranges	12 forward, 12 reverse
Max Travel Speed (Forward)	14.8 mph (with R4 tires)	14.2 mph
Max Travel Speed (Reverse)	Not Published	Not Published
Clutch	n/a (no clutch on hydrostatic)	Dry clutch
Differential Lock & Limited Slip Options	Mechanical differential lock	Mechanical differential lock

Frame Type	Not Published	Not Published
Steering	Not Published	Not Published
Brakes	Not Published	Not Published
Seat Suspension & Adjustability	Adjustable suspension seat	Adjustable suspension seat
Front Axle Type	Mechanical Front Drive (MFD)	Mechanical Front Drive (MFD)
Front Axle Rating	Not Published	Not Published
Drawbar Capacity	Not Published	Not Published

Overall Width	66.5 in	66.5 in
Wheelbase	66.2 in	66.2 in
Ground Clearance	Not Published	Not Published
Min. Turn Radius without Brakes	10.5 ft	10.5 ft
Height to Top of ROPS	96.2 in	96.2 in
Height to Top of ROPS (folded)	74.2 in	74.2 in
Height to Top of Cab Model	Not Published	Not Published
Overall Length	119.4 in	119.4 in

Tractor Weight (Base)	3,042 lb	3,042 lb
Weight with ROPS and Loader	Not Published	Not Published
Weight with Cab and Loader	Not Published	Not Published

Tire Size & Options	R1 Agricultural, R3 Turf, or R4 Industrial	R1 Agricultural, R3 Turf, or R4 Industrial
R1 Agricultural - Front	7x14	7x14
R1 Agricultural - Rear	11.2x24	11.2x24
R3 Turf - Front	25x8.50-14	25x8.50-14
R3 Turf - Rear	41x14.00-20	41x14.00-20
R4 Industrial - Front	25x8.50-14	25x8.50-14
R4 Industrial - Rear	43x16.00-20	43x16.00-20

Quick Attach Loader System	Not Published	Not Published
Loader Model	L340A	L340A
Loader Lift Height	98 in	98 in
Loader Lift Capacity (Full Height)	890 lb at 31.5 in forward of pivot pin	890 lb at 31.5 in forward of pivot pin
Loader Breakout Force	1,900 lb	1,900 lb

Warranty Length & Coverage	Basic 2 years; powertrain 4 additional years (6-year total)	Basic 2 years; powertrain 4 additional years (6-year total)

Find a Case IH dealer near you

Case IH Farmall 35A vs Case IH Farmall 35A Mechanical: Quick Answers

Which has more horsepower, the Case IH Farmall 35A or the Case IH Farmall 35A Mechanical?: They are effectively tied: both machines are rated at 35 hp hp for engine hp.
Which has more PTO horsepower, the Case IH Farmall 35A or the Case IH Farmall 35A Mechanical?: The Case IH Farmall 35A Mechanical leads on pto hp at 31 hp hp, compared to 30.1 hp hp for the Case IH Farmall 35A.
Which is heavier, the Case IH Farmall 35A or the Case IH Farmall 35A Mechanical?: They are effectively tied: both machines are rated at 3,042 lb lb for weight.
Which has more loader lift capacity, the Case IH Farmall 35A or the Case IH Farmall 35A Mechanical?: They are effectively tied: both machines are rated at 890 lb lb for loader lift.
Which has more three-point hitch lift capacity, the Case IH Farmall 35A or the Case IH Farmall 35A Mechanical?: They are effectively tied: both machines are rated at 1,596 lb lb for 3-pt lift (24 in).

More Head-to-Heads

Farmall 35A Mechanical

Farmall 35A Mechanical

Farmall 35A Mechanical

Farmall 35A Mechanical

Bad Boy Tractors

4035 Cab

Compare

Category Verdict

Spec	Case IH Farmall 35A	Case IH Farmall 35A Mechanical
Engine HP (hp)	35 hp	35 hp
PTO HP (hp)	30.1 hp	▲ 31 hp
Weight (lb)	3,042 lb	3,042 lb
Loader Lift (lb)	890 lb	890 lb
3-Pt Lift (24 in) (lb)	1,596 lb	1,596 lb
Lift Height (in)	98 in	98 in
Breakout Force (lbf)	1,900 lbf	1,900 lbf
Hydraulic Flow (gpm)	13.3 gpm	13.3 gpm
Travel Speed (mph)	▲ 14.8 mph	14.2 mph

The headline numbers at a glance.

Case IH Farmall 35ACase IH Farmall 35A Mechanical

Engine HPhp

▲35 hp

PTO HPhp

30.1 hp

▲31 hp

Weightlb

▲3,042 lb

Loader Liftlb

▲890 lb

3-Pt Lift (24 in)lb

▲1,596 lb

Share↓ Image 𝕏 f ✉

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	Case IHFarmall 35A	Case IHFarmall 35A Mechanical


Engine Manufacturer	LS Mtron	LS Mtron
Engine Model	Not Published	Not Published
Engine Type	3-cylinder, Tier 4 B/Final	3-cylinder, Tier 4 B/Final
No. of Cylinders	3	3
Displacement	114.7 in³	114.7 in³
Rated Engine Speed	2600 rpm	2600 rpm
Engine Power (Gross)	35 hp	35 hp
PTO Power	30.1 hp	31 hp
Engine Emissions Constraints	Tier 4	Tier 4
Cooling System Type	Not Published	Not Published
Air Cleaner	Not Published	Not Published
Fuel System	Not Published	Not Published
Alternator	85 A, 12 V	Not Published

Pump Type	Not Published	Not Published
Implement Flow	8.4 gpm	8.4 gpm
Steering Flow	Not Published	Not Published
Total Hydraulic Flow	13.3 gpm	13.3 gpm
Overall Hydraulic Pump Flow	Not Published	Not Published
Hydraulic System Type	Open center	Open center
Rear Remote Hydraulic Flow	Not Published	Not Published
No. of Standard Remote Valves	0	0
No. of Optional Remote Valves	3	3

Fuel Tank Capacity	12.6 gal	12.6 gal
Coolant Capacity	Not Published	Not Published
Crankcase Capacity	Not Published	Not Published
Transmission / Hydraulic System Capacity	Not Published	Not Published
Front Axle Fluid Capacity	Not Published	Not Published

PTO Type	Independent, electro-hydraulic engagement	Independent, electro-hydraulic engagement
PTO Rear	540 rpm	540 rpm
Mid-PTO Availability	Optional, 2,000 rpm	Not Published
Category, 3-Point Hitch	Category I	Category I
Hitch Lift Capacity	Not Published	Not Published
Hitch Lift Capacity (at 24”)	1,596 lb	1,596 lb
Lift Control Type	Mechanical Draft Control (MDC)	Mechanical Draft Control (MDC)

Transmission Type	3-range hydrostatic (optional)	12x12 mechanical shuttle with synchro shift (dry clutch) (standard)
No. of Speeds	3 ranges	12 forward, 12 reverse
Max Travel Speed (Forward)	14.8 mph (with R4 tires)	14.2 mph
Max Travel Speed (Reverse)	Not Published	Not Published
Clutch	n/a (no clutch on hydrostatic)	Dry clutch
Differential Lock & Limited Slip Options	Mechanical differential lock	Mechanical differential lock

Frame Type	Not Published	Not Published
Steering	Not Published	Not Published
Brakes	Not Published	Not Published
Seat Suspension & Adjustability	Adjustable suspension seat	Adjustable suspension seat
Front Axle Type	Mechanical Front Drive (MFD)	Mechanical Front Drive (MFD)
Front Axle Rating	Not Published	Not Published
Drawbar Capacity	Not Published	Not Published

Overall Width	66.5 in	66.5 in
Wheelbase	66.2 in	66.2 in
Ground Clearance	Not Published	Not Published
Min. Turn Radius without Brakes	10.5 ft	10.5 ft
Height to Top of ROPS	96.2 in	96.2 in
Height to Top of ROPS (folded)	74.2 in	74.2 in
Height to Top of Cab Model	Not Published	Not Published
Overall Length	119.4 in	119.4 in

Tractor Weight (Base)	3,042 lb	3,042 lb
Weight with ROPS and Loader	Not Published	Not Published
Weight with Cab and Loader	Not Published	Not Published

Tire Size & Options	R1 Agricultural, R3 Turf, or R4 Industrial	R1 Agricultural, R3 Turf, or R4 Industrial
R1 Agricultural - Front	7x14	7x14
R1 Agricultural - Rear	11.2x24	11.2x24
R3 Turf - Front	25x8.50-14	25x8.50-14
R3 Turf - Rear	41x14.00-20	41x14.00-20
R4 Industrial - Front	25x8.50-14	25x8.50-14
R4 Industrial - Rear	43x16.00-20	43x16.00-20

Quick Attach Loader System	Not Published	Not Published
Loader Model	L340A	L340A
Loader Lift Height	98 in	98 in
Loader Lift Capacity (Full Height)	890 lb at 31.5 in forward of pivot pin	890 lb at 31.5 in forward of pivot pin
Loader Breakout Force	1,900 lb	1,900 lb

Warranty Length & Coverage	Basic 2 years; powertrain 4 additional years (6-year total)	Basic 2 years; powertrain 4 additional years (6-year total)

Find a Case IH dealer near you

Case IH Farmall 35A vs Case IH Farmall 35A Mechanical: Quick Answers

Which has more horsepower, the Case IH Farmall 35A or the Case IH Farmall 35A Mechanical?

They are effectively tied: both machines are rated at 35 hp hp for engine hp.

Which has more PTO horsepower, the Case IH Farmall 35A or the Case IH Farmall 35A Mechanical?

The Case IH Farmall 35A Mechanical leads on pto hp at 31 hp hp, compared to 30.1 hp hp for the Case IH Farmall 35A.

Which is heavier, the Case IH Farmall 35A or the Case IH Farmall 35A Mechanical?

They are effectively tied: both machines are rated at 3,042 lb lb for weight.

Which has more loader lift capacity, the Case IH Farmall 35A or the Case IH Farmall 35A Mechanical?

They are effectively tied: both machines are rated at 890 lb lb for loader lift.

Which has more three-point hitch lift capacity, the Case IH Farmall 35A or the Case IH Farmall 35A Mechanical?

They are effectively tied: both machines are rated at 1,596 lb lb for 3-pt lift (24 in).
