Bad Boy Tractors 3026 vs Kioti CS2220

Across 9 measurable specs, the Bad Boy Tractors 3026 leads 9 categories to 0. Machine pages: Bad Boy Tractors 3026 and Kioti CS2220.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	Bad Boy Tractors3026	KiotiCS2220

▶Engine
Engine Manufacturer	TYM	KIOTI
Engine Model	A1100N2	3C100LWH-U3
Engine Type	3 cylinder, water-cooled diesel, natural aspiration, swirl chamber	In-Line Vertical, Water-Cooled Diesel (3-cylinder)
No. of Cylinders	3	3
Displacement	71.7 in³	61.5 in³
Rated Engine Speed	2600 rpm	3200 rpm
Engine Power (Gross)	25 hp	21 hp
PTO Power	18 hp	16.3 hp
Engine Emissions Constraints	Tier 4	U.S. EPA non-road emission regulation
Cooling System Type	Water-cooled	Water-cooled
Air Cleaner	Dry element	Not Published
Fuel System	Indirect injection (swirl chamber)	Not Published
Alternator	50 A, 12 V	Not Published
▶Hydraulics
Pump Type	Gear type pump with primary and secondary pumps	Gear
Implement Flow	4.3 gpm	7.0 gpm
Steering Flow	3.1 gpm	Not Published
Total Hydraulic Flow	7.4 gpm	7.0 gpm
Overall Hydraulic Pump Flow	7.7 gpm	7.0 gpm
Hydraulic System Type	Open center	Open center
Rear Remote Hydraulic Flow	Not Published	Not Published
No. of Standard Remote Valves	0	Not Published
No. of Optional Remote Valves	1	Not Published
▶Fluid Capacity
Fuel Tank Capacity	6.08 gal	6.7 gal
Coolant Capacity	1.21 gal	0.87 gal
Crankcase Capacity	0.79 gal	1.0 gal
Transmission / Hydraulic System Capacity	2.90 gal	2.75 gal
Front Axle Fluid Capacity	0.79 gal	0.53 gal
▶PTO & Hitch
PTO Type	Live PTO (6 spline shaft)	Independent
PTO Rear	540 / 960 rpm	540 rpm
Mid-PTO Availability	Optional, 2,500 rpm	Available (2,200 rpm)
Category, 3-Point Hitch	Category I	Category I
Hitch Lift Capacity	1,433 lb	1,580 lb
Hitch Lift Capacity (at 24”)	974 lb	700 lb
Lift Control Type	Position control	Position
▶Transmission & Drivetrain
Transmission Type	Hydrostatic (HST)	Hydrostatic (HST)
No. of Speeds	3 range (L/M/H)	Infinite, 2 range (High/Low)
Max Travel Speed (Forward)	14.8 mph	9.6 mph
Max Travel Speed (Reverse)	14.8 mph	6.6 mph
Clutch	Dry, single plate	None (hydrostatic transmission)
Differential Lock & Limited Slip Options	Mechanical rear differential lock	Rear differential lock (standard)
▶Chassis, Steering & Controls
Frame Type	Steel frame with cast iron axles	Not Published
Steering	Hydrostatic power steering	Hydrostatic power steering
Brakes	Wet disc	Wet multi disc
Seat Suspension & Adjustability	Adjustable seat, flips up and back for rear backhoe operation	Not Published
Front Axle Type	Selectable 4WD	Mechanical 4WD
Front Axle Rating	Not Published	Not Published
Drawbar Capacity	Not Published	Not Published
▶Dimensions & Maneuverability
Overall Width	53.8 in	45.9 in
Wheelbase	65.7 in	55.1 in
Ground Clearance	16.4 in	6.4 in
Min. Turn Radius without Brakes	Not Published	8.2 ft (with brake applied)
Height to Top of ROPS	91.4 in	87.6 in
Height to Top of ROPS (folded)	Not Published	Not Published
Height to Top of Cab Model	Not Published	Not Published
Overall Length	110 in	99.3 in (with 3-point hitch)
▶Weight
Tractor Weight (Base)	2,106 lb	1,554 lb (with AG. tires)
Weight with ROPS and Loader	Not Published	Not Published
Weight with Cab and Loader	Not Published	Not Published
▶Tire Options
Tire Size & Options	R4 Industrial (25x8.50-14 front / 14x17.5 rear)	Agricultural, Turf and Industrial: 18x8.5-10 front, 26x12.00-12 rear
R1 Agricultural - Front	7-16 6PR	18x8.5-10
R1 Agricultural - Rear	11.2-20	26x12.00-12
R3 Turf - Front	Not Published	18x8.5-10
R3 Turf - Rear	Not Published	26x12.00-12
R4 Industrial - Front	25x8.50-14	18x8.5-10
R4 Industrial - Rear	14x17.5	26x12.00-12
▶Loader & Attachments
Quick Attach Loader System	Quick attach front loader	Quick attach (QA) bucket, 48 in
Loader Model	BBL300	SL2420
Loader Lift Height	86 in	SL2420: 73.7 in (at pivot pin)
Loader Lift Capacity (Full Height)	1,314 lb (at pivot pin)	SL2420: 1,062 lb
Loader Breakout Force	1,960 lbf	SL2420: 1,329 lb (at pivot pin)
▶Warranty
Warranty Length & Coverage	Basic 24 months or 1,000 hours; powertrain 72 months or 2,000 hours; loader and backhoe 24 months from shipment, 12 months from sale, or 500 hours	Non-commercial: basic 24 months, powertrain 72 months on qualifying tractors, unlimited hours, parts and labor
▶ITC Company Accessories
Accessories that fit	Branson TYM 2510 / 2610 and select 2400 series Brush Screen Insert $249.99	Brush Guard Side Guards $199.99 Bolt onto the side of the OEM guard and offers wrap around protection

Find a Bad Boy dealer near you→Find a KIOTI dealer near you→

Bad Boy Tractors 3026 vs Kioti CS2220: Quick Answers

Which has more horsepower, the Bad Boy Tractors 3026 or the Kioti CS2220?

The Bad Boy Tractors 3026 leads on engine hp at 25 hp hp, compared to 21 hp hp for the Kioti CS2220.

Which has more PTO horsepower, the Bad Boy Tractors 3026 or the Kioti CS2220?

The Bad Boy Tractors 3026 leads on pto hp at 18 hp hp, compared to 16.3 hp hp for the Kioti CS2220.

Which is heavier, the Bad Boy Tractors 3026 or the Kioti CS2220?

The Bad Boy Tractors 3026 leads on weight at 2,106 lb lb, compared to 1,554 lb lb for the Kioti CS2220.

Which has more loader lift capacity, the Bad Boy Tractors 3026 or the Kioti CS2220?

The Bad Boy Tractors 3026 leads on loader lift at 1,314 lb lb, compared to 1,062 lb lb for the Kioti CS2220.

Which has more three-point hitch lift capacity, the Bad Boy Tractors 3026 or the Kioti CS2220?

The Bad Boy Tractors 3026 leads on 3-pt lift (24 in) at 974 lb lb, compared to 700 lb lb for the Kioti CS2220.
