Bad Boy Tractors 4025 vs LS Tractor MT226ED

Across 8 measurable specs, the Bad Boy Tractors 4025 leads 6 categories to 2. Machine pages: Bad Boy Tractors 4025 and LS Tractor MT226ED.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	Bad Boy Tractors4025	LS TractorMT226ED

▶Engine
Engine Manufacturer	TYM	MHI
Engine Model	A1700N6-BUTR_3	S3L2-W463GTAC
Engine Type	Vertical, 4-stroke, water-cooled diesel	3-cylinder, liquid-cooled, diesel, naturally aspirated, IDI
No. of Cylinders	3	3
Displacement	104.5 in³	80.4 in³
Rated Engine Speed	2100 rpm	2500 rpm
Engine Power (Gross)	25 hp	24.6 hp
PTO Power	19.1 hp	19.2 hp
Engine Emissions Constraints	Not Published	Tier 4
Cooling System Type	Water-cooled	Liquid-cooled
Air Cleaner	Dry	Dry
Fuel System	Not Published	IDI (indirect injection)
Alternator	50 A, 12 V	50 A, 12 V
▶Hydraulics
Pump Type	Gear type (primary 0.8 in³/rev, secondary 0.4 in³/rev)	Gear pump
Implement Flow	7.5 gpm	7.9 gpm
Steering Flow	4 gpm	4.6 gpm
Total Hydraulic Flow	11.5 gpm	12.5 gpm
Overall Hydraulic Pump Flow	11.5 gpm	12.5 gpm
Hydraulic System Type	Open center	Open center
Rear Remote Hydraulic Flow	Not Published	Not Published
No. of Standard Remote Valves	Not Published	None
No. of Optional Remote Valves	Up to 2	Not Published
▶Fluid Capacity
Fuel Tank Capacity	7.13 gal	10.6 gal
Coolant Capacity	1.32 gal	Not Published
Crankcase Capacity	1.14 gal	Not Published
Transmission / Hydraulic System Capacity	9.77 gal	Not Published
Front Axle Fluid Capacity	Not Published	Not Published
▶PTO & Hitch
PTO Type	Independent	Transmission driven
PTO Rear	540 rpm	Standard (540 rpm)
Mid-PTO Availability	Not Published	Available (option)
Category, 3-Point Hitch	Category I	Category I
Hitch Lift Capacity	3,307 lb	Not Published
Hitch Lift Capacity (at 24”)	2,425 lb	1,433 lb
Lift Control Type	Position control	Position control
▶Transmission & Drivetrain
Transmission Type	Hydrostatic (HST)	Synchro Shuttle
No. of Speeds	3 range (A/B/C)	F12 x R12
Max Travel Speed (Forward)	Not Published	Not Published
Max Travel Speed (Reverse)	Not Published	Not Published
Clutch	None (HST)	Dry Single
Differential Lock & Limited Slip Options	Rear differential lock	Mechanical differential lock (pedal)
▶Chassis, Steering & Controls
Frame Type	Heavy-duty steel frame with cast iron axles	Not Published
Steering	Fully hydraulic power steering	Hydrostatic power steering
Brakes	Wet multi-disc	Wet, multi-disc
Seat Suspension & Adjustability	Not Published	Not Published
Front Axle Type	Selectable 4WD	Front wheel mechanical assist (4WD)
Front Axle Rating	Not Published	Not Published
Drawbar Capacity	Not Published	Not Published
▶Dimensions & Maneuverability
Overall Width	56.7 in	66 in
Wheelbase	65.7 in	66 in
Ground Clearance	13.1 in	Not Published
Min. Turn Radius without Brakes	Not Published	Not Published
Height to Top of ROPS	104.06 in	95 in
Height to Top of ROPS (folded)	Not Published	Not Published
Height to Top of Cab Model	Not Published	Not Published
Overall Length	134.88 in	119 in (frame to link)
▶Weight
Tractor Weight (Base)	2,970 lb	2,963 lb
Weight with ROPS and Loader	Not Published	Not Published
Weight with Cab and Loader	Not Published	Not Published
▶Tire Options
Tire Size & Options	R4 Industrial (25x8.50-14 / 15-19.5)	Ag, Industrial, VT and Turf; VT same size as Industrial
R1 Agricultural - Front	8.0-16	7-14
R1 Agricultural - Rear	12.4-24	11.2-24
R3 Turf - Front	Not Published	25x8.50-14
R3 Turf - Rear	Not Published	41x14.00-20
R4 Industrial - Front	25x8.50-14	27x8.50-15
R4 Industrial - Rear	15-19.5	43x16.00-20
▶Loader & Attachments
Quick Attach Loader System	Quick attach front loader	LL3001, LL3002: ISO 24410 Quick Attaching Coupler
Loader Model	BBL400	LL3001 and LL3002
Loader Lift Height	104 in	LL3001 and LL3002: 94.3 in
Loader Lift Capacity (Full Height)	2,200 lb (at pivot pin)	LL3001 and LL3002: 1,599 lb (at pivot pin, maximum height)
Loader Breakout Force	3,660 lbf	LL3001 and LL3002: 2,962 lb (at pivot pin)
▶Warranty
Warranty Length & Coverage	Basic 24 months or 1,000 hours; powertrain 72 months or 2,000 hours; loader and backhoe 24 months from shipment, 12 months from sale, or 500 hours	Two-year bumper to bumper; six-year limited powertrain
▶ITC Company Accessories
Accessories that fit	Brush Guard Side Guards $199.99 Bolt onto the side of the OEM guard and offers wrap around protection Branson TYM 15/20 Series--Bad Boy 40/50 Series Brush Screen $250.00 Branson / TYM 15 Series Fuel Tank Cover $250.00	None tagged yet

Find a Bad Boy dealer near you→Find a LS Tractor dealer near you→

Bad Boy Tractors 4025 vs LS Tractor MT226ED: Quick Answers

Which has more horsepower, the Bad Boy Tractors 4025 or the LS Tractor MT226ED?

The Bad Boy Tractors 4025 leads on engine hp at 25 hp hp, compared to 24.6 hp hp for the LS Tractor MT226ED.

Which has more PTO horsepower, the Bad Boy Tractors 4025 or the LS Tractor MT226ED?

The LS Tractor MT226ED leads on pto hp at 19.2 hp hp, compared to 19.1 hp hp for the Bad Boy Tractors 4025.

Which is heavier, the Bad Boy Tractors 4025 or the LS Tractor MT226ED?

The Bad Boy Tractors 4025 leads on weight at 2,970 lb lb, compared to 2,963 lb lb for the LS Tractor MT226ED.

Which has more loader lift capacity, the Bad Boy Tractors 4025 or the LS Tractor MT226ED?

The Bad Boy Tractors 4025 leads on loader lift at 2,200 lb lb, compared to 1,599 lb lb for the LS Tractor MT226ED.

Which has more three-point hitch lift capacity, the Bad Boy Tractors 4025 or the LS Tractor MT226ED?

The Bad Boy Tractors 4025 leads on 3-pt lift (24 in) at 2,425 lb lb, compared to 1,433 lb lb for the LS Tractor MT226ED.
