Bad Boy Tractors 4025 vs New Holland Workmaster 25S

Across 8 measurable specs, the Bad Boy Tractors 4025 leads 8 categories to 0. Machine pages: Bad Boy Tractors 4025 and New Holland Workmaster 25S.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	Bad Boy Tractors4025	New HollandWorkmaster 25S

▶Engine
Engine Manufacturer	TYM	Yanmar
Engine Model	A1700N6-BUTR_3	3TNV80F
Engine Type	Vertical, 4-stroke, water-cooled diesel	3-cylinder, naturally aspirated, liquid-cooled diesel
No. of Cylinders	3	3
Displacement	104.5 in³	77.3 in³
Rated Engine Speed	2100 rpm	3000 rpm
Engine Power (Gross)	25 hp	24.7 hp
PTO Power	19.1 hp	17.2 hp
Engine Emissions Constraints	Not Published	Tier 4
Cooling System Type	Water-cooled	Pressurized liquid with recirculating bypass
Air Cleaner	Dry	Single-element
Fuel System	Not Published	In-line injection pump, indirect injection (swirl chamber)
Alternator	50 A, 12 V	50 A
▶Hydraulics
Pump Type	Gear type (primary 0.8 in³/rev, secondary 0.4 in³/rev)	Gear
Implement Flow	7.5 gpm	4.6 gpm
Steering Flow	4 gpm	2.1 gpm
Total Hydraulic Flow	11.5 gpm	6.7 gpm
Overall Hydraulic Pump Flow	11.5 gpm	6.7 gpm
Hydraulic System Type	Open center	Open center
Rear Remote Hydraulic Flow	Not Published	Not Published
No. of Standard Remote Valves	Not Published	Not Published
No. of Optional Remote Valves	Up to 2	1
▶Fluid Capacity
Fuel Tank Capacity	7.13 gal	6.6 gal
Coolant Capacity	1.32 gal	3.49 qt
Crankcase Capacity	1.14 gal	3 qt
Transmission / Hydraulic System Capacity	9.77 gal	3.3 gal
Front Axle Fluid Capacity	Not Published	0.5 gal
▶PTO & Hitch
PTO Type	Independent	Independent, electro-hydraulic engagement
PTO Rear	540 rpm	540 rpm
Mid-PTO Availability	Not Published	Standard (2,500 rpm)
Category, 3-Point Hitch	Category I	Category I
Hitch Lift Capacity	3,307 lb	992 lb
Hitch Lift Capacity (at 24”)	2,425 lb	728 lb
Lift Control Type	Position control	Lift-hold-lower
▶Transmission & Drivetrain
Transmission Type	Hydrostatic (HST)	2-range hydrostatic, dual pedal
No. of Speeds	3 range (A/B/C)	Infinite (2 ranges)
Max Travel Speed (Forward)	Not Published	9.1 mph
Max Travel Speed (Reverse)	Not Published	5.5 mph
Clutch	None (HST)	Not Published
Differential Lock & Limited Slip Options	Rear differential lock	Mechanical, foot-operated rear differential lock
▶Chassis, Steering & Controls
Frame Type	Heavy-duty steel frame with cast iron axles	Not Published
Steering	Fully hydraulic power steering	Hydrostatic power steering
Brakes	Wet multi-disc	Wet, multi-disc
Seat Suspension & Adjustability	Not Published	Deluxe high-back seat with armrests and adjustable backrest
Front Axle Type	Selectable 4WD	4WD
Front Axle Rating	Not Published	Not Published
Drawbar Capacity	Not Published	Not Published
▶Dimensions & Maneuverability
Overall Width	56.7 in	46.7 in
Wheelbase	65.7 in	56.1 in
Ground Clearance	13.1 in	12 in
Min. Turn Radius without Brakes	Not Published	94 in
Height to Top of ROPS	104.06 in	87.4 in
Height to Top of ROPS (folded)	Not Published	64 in
Height to Top of Cab Model	Not Published	87.4 in
Overall Length	134.88 in	97.4 in
▶Weight
Tractor Weight (Base)	2,970 lb	ROPS: 1,444 lb; Cab: 1,805 lb
Weight with ROPS and Loader	Not Published	Not Published
Weight with Cab and Loader	Not Published	Not Published
▶Tire Options
Tire Size & Options	R4 Industrial (25x8.50-14 / 15-19.5)	R3 Turf, R4 Industrial
R1 Agricultural - Front	8.0-16	Not Published
R1 Agricultural - Rear	12.4-24	Not Published
R3 Turf - Front	Not Published	18x8.50-10
R3 Turf - Rear	Not Published	26x12.0-12
R4 Industrial - Front	25x8.50-14	18x8.50-10
R4 Industrial - Rear	15-19.5	26x12.0-12
▶Loader & Attachments
Quick Attach Loader System	Quick attach front loader	100LC: Quick Mount system, no tools needed
Loader Model	BBL400	100LC
Loader Lift Height	104 in	100LC: 72 in (at pivot pin)
Loader Lift Capacity (Full Height)	2,200 lb (at pivot pin)	100LC: 1,005 lb (at bucket pivot pin, max height)
Loader Breakout Force	3,660 lbf	100LC: 2,078 lb (at bucket pivot pin)
▶Warranty
Warranty Length & Coverage	Basic 24 months or 1,000 hours; powertrain 72 months or 2,000 hours; loader and backhoe 24 months from shipment, 12 months from sale, or 500 hours	Basic 2 years or 750 hours; powertrain to 6 years or 1,500 hours total
▶ITC Company Accessories
Accessories that fit	Brush Guard Side Guards $199.99 Bolt onto the side of the OEM guard and offers wrap around protection Branson TYM 15/20 Series--Bad Boy 40/50 Series Brush Screen $250.00 Branson / TYM 15 Series Fuel Tank Cover $250.00	None tagged yet

Find a Bad Boy dealer near you→Find a New Holland dealer near you→

Bad Boy Tractors 4025 vs New Holland Workmaster 25S: Quick Answers

Which has more horsepower, the Bad Boy Tractors 4025 or the New Holland Workmaster 25S?

The Bad Boy Tractors 4025 leads on engine hp at 25 hp hp, compared to 24.7 hp hp for the New Holland Workmaster 25S.

Which has more PTO horsepower, the Bad Boy Tractors 4025 or the New Holland Workmaster 25S?

The Bad Boy Tractors 4025 leads on pto hp at 19.1 hp hp, compared to 17.2 hp hp for the New Holland Workmaster 25S.

Which is heavier, the Bad Boy Tractors 4025 or the New Holland Workmaster 25S?

The Bad Boy Tractors 4025 leads on weight at 2,970 lb lb, compared to 1,805 lb lb for the New Holland Workmaster 25S.

Which has more loader lift capacity, the Bad Boy Tractors 4025 or the New Holland Workmaster 25S?

The Bad Boy Tractors 4025 leads on loader lift at 2,200 lb lb, compared to 1,005 lb lb for the New Holland Workmaster 25S.

Which has more three-point hitch lift capacity, the Bad Boy Tractors 4025 or the New Holland Workmaster 25S?

The Bad Boy Tractors 4025 leads on 3-pt lift (24 in) at 2,425 lb lb, compared to 728 lb lb for the New Holland Workmaster 25S.
