Bad Boy Tractors 5045 Cab vs New Holland Boomer 40

Across 9 measurable specs, the Bad Boy Tractors 5045 Cab leads 9 categories to 0. Machine pages: Bad Boy Tractors 5045 Cab and New Holland Boomer 40.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	Bad Boy Tractors5045 Cab	New HollandBoomer 40

▶Engine
Engine Manufacturer	TYM	LS Mtron
Engine Model	A2300N3	L3CRV-T4
Engine Type	4 cylinder water-cooled diesel, naturally aspirated	3-cylinder, turbocharged, liquid-cooled diesel
No. of Cylinders	4	3
Displacement	139.5 in³	114.7 in³
Rated Engine Speed	2600 rpm	2600 rpm
Engine Power (Gross)	48 hp	40 hp
PTO Power	38.4 hp	Gear: 34 hp; HST: 32 hp
Engine Emissions Constraints	Tier 4	Tier 4B (final)
Cooling System Type	Water-cooled	Liquid cooled
Air Cleaner	Dry element	Replaceable primary and inner elements
Fuel System	Not Published	Electronically controlled common rail direct injection
Alternator	70 A, 12 V	ROPS: 70 A, 12 V; Cab: 85 A, 12 V
▶Hydraulics
Pump Type	Not Published	Gear
Implement Flow	10.7 gpm	8.2 gpm
Steering Flow	5 gpm	Gear: 4.2 gpm; HST: 5.3 gpm
Total Hydraulic Flow	15.7 gpm	Gear: 12.4 gpm; HST: 13.5 gpm
Overall Hydraulic Pump Flow	15.7 gpm	Gear: 12.4 gpm; HST: 13.5 gpm
Hydraulic System Type	Open center	Open center
Rear Remote Hydraulic Flow	Not Published	Not Published
No. of Standard Remote Valves	4 ports	1
No. of Optional Remote Valves	Not Published	Up to 2 (second valve optional)
▶Fluid Capacity
Fuel Tank Capacity	11.8 gal	ROPS: 10.5 gal; Cab: 12.4 gal
Coolant Capacity	1.56 gal	7.5 qt
Crankcase Capacity	1.20 gal	5.8 qt
Transmission / Hydraulic System Capacity	10.04 gal	8.5 gal
Front Axle Fluid Capacity	1.90 gal	6.87 qt
▶PTO & Hitch
PTO Type	Independent	Independent, electro-hydraulic engagement
PTO Rear	540 / 540E rpm	540 rpm
Mid-PTO Availability	Not Published	Standard (2000 rpm)
Category, 3-Point Hitch	Category I	Category I
Hitch Lift Capacity	3,306 lb	1,808 lb
Hitch Lift Capacity (at 24”)	2,425 lb	1,345 lb
Lift Control Type	Position control	Position control (draft control optional)
▶Transmission & Drivetrain
Transmission Type	Hydrostatic (HST), 4-range	Gear: 12x12 synchronized shuttle shift (SSS); HST: 3-range hydrostatic, dual pedal
No. of Speeds	4 range (HST)	Gear: 12F/12R; HST: 3-range
Max Travel Speed (Forward)	19.5 mph	Gear: 14.2 mph; HST: 14.8 mph
Max Travel Speed (Reverse)	19.5 mph	Gear: 13.63 mph; HST: 13.60 mph
Clutch	None (HST)	Gear: dry single disc (9.4 in); HST: n/a
Differential Lock & Limited Slip Options	Rear differential lock (standard)	Mechanical rear differential lock (pedal)
▶Chassis, Steering & Controls
Frame Type	Compact utility tractor, 4WD	Not Published
Steering	Hydrostatic power steering	Power steering
Brakes	Wet, multi-disc	Wet multi-disc
Seat Suspension & Adjustability	Heated leather seat (cab)	ROPS: adjustable suspension seat (fore/aft, weight and height adjustment); Cab: cloth seat with weight control, easy fore/aft movement and adjustable armrests
Front Axle Type	Selectable 4WD	Four-wheel drive (FWD)
Front Axle Rating	Not Published	Not Published
Drawbar Capacity	Not Published	Not Published
▶Dimensions & Maneuverability
Overall Width	64.9 in	66.4 in
Wheelbase	71.1 in	66 in
Ground Clearance	15.5 in	Not Published
Min. Turn Radius without Brakes	9.18 ft (with brake applied)	9.2 ft (with brake applied)
Height to Top of ROPS	Not Published	92.7 in
Height to Top of ROPS (folded)	Not Published	Not Published
Height to Top of Cab Model	97.0 in	90 in
Overall Length	127.4 in (with 3-point hitch)	119 in
▶Weight
Tractor Weight (Base)	4,349 lb	ROPS Gear: 2,804 lb; ROPS HST: 2,870 lb; Cab: 3,574 lb
Weight with ROPS and Loader	Not Published	Not Published
Weight with Cab and Loader	Not Published	Not Published
▶Tire Options
Tire Size & Options	9.5-16 front / 13.6-26 rear (ag)	R1 Agricultural, R3 Turf, R4 Industrial
R1 Agricultural - Front	9.5-16	7-14
R1 Agricultural - Rear	13.6-26	11.2-24
R3 Turf - Front	Not Published	25x8.50-14
R3 Turf - Rear	Not Published	41x14.00-20
R4 Industrial - Front	Not Published	25x8.50-14
R4 Industrial - Rear	Not Published	43x16.00-20
▶Loader & Attachments
Quick Attach Loader System	SSQA	Tool-free loader mount; optional skid-steer quick-attach plates
Loader Model	BBL500	250TLA
Loader Lift Height	106.6 in	250TLA: 104 in (at pivot pin)
Loader Lift Capacity (Full Height)	2,700 lb (at pivot pin)	250TLA: 1,822 lb (at bucket pivot pin, max height)
Loader Breakout Force	3,660 lb	250TLA: 3,257 lb (at bucket pivot pin)
▶Warranty
Warranty Length & Coverage	Basic 24 months or 1,000 hours; powertrain 72 months or 2,000 hours	Basic 2 years or 750 hours; powertrain 4 more years (6 years or 1,500 hours total)
▶ITC Company Accessories
Accessories that fit	Brush Guard Side Guards $199.99 Bolt onto the side of the OEM guard and offers wrap around protection Branson TYM 15/20 Series--Bad Boy 40/50 Series Brush Screen $250.00	None tagged yet

Find a Bad Boy dealer near you→Find a New Holland dealer near you→

Bad Boy Tractors 5045 Cab vs New Holland Boomer 40: Quick Answers

Which has more horsepower, the Bad Boy Tractors 5045 Cab or the New Holland Boomer 40?

The Bad Boy Tractors 5045 Cab leads on engine hp at 48 hp hp, compared to 40 hp hp for the New Holland Boomer 40.

Which has more PTO horsepower, the Bad Boy Tractors 5045 Cab or the New Holland Boomer 40?

The Bad Boy Tractors 5045 Cab leads on pto hp at 38.4 hp hp, compared to 34 hp hp for the New Holland Boomer 40.

Which is heavier, the Bad Boy Tractors 5045 Cab or the New Holland Boomer 40?

The Bad Boy Tractors 5045 Cab leads on weight at 4,349 lb lb, compared to 3,574 lb lb for the New Holland Boomer 40.

Which has more loader lift capacity, the Bad Boy Tractors 5045 Cab or the New Holland Boomer 40?

The Bad Boy Tractors 5045 Cab leads on loader lift at 2,700 lb lb, compared to 1,822 lb lb for the New Holland Boomer 40.

Which has more three-point hitch lift capacity, the Bad Boy Tractors 5045 Cab or the New Holland Boomer 40?

The Bad Boy Tractors 5045 Cab leads on 3-pt lift (24 in) at 2,425 lb lb, compared to 1,345 lb lb for the New Holland Boomer 40.
