24 months / 1,500 hours (whichever occurs first) - covers defects in material and workmanship
Limited: Tractors (Non-Commercial Application) 24 months parts & labor; Extended (driveline): 48 months parts & labor
Pump Type
Gear
Not Published
Steering Flow
N/A
Not Published
Implement Flow
6.5 gpm (24.5 Lpm)
Not Published
Total Hydraulic Flow
7.2 gpm
6.5 gpm
Hydraulic System Type
Open Center
Open center
Rear Remote Hydraulic Flow
NOT FOUND
Not Published
Overall Hydraulic Pump Flow
7.2 gpm
6.5 gpm
No. of Optional Remote Valves
1 Pair
Not Published
No. of Standard Remote Valves
1
Not Published
PTO Rear
540 rpm
540 rpm
PTO Type
Independent
Independent
Lift Control Type
Hydraulic Position Control System
Position control
Hitch Lift Capacity
700 lb.
700 lbs (at 24 in)
Mid-PTO Availability
Standard: 2200 rpm
Available (2,200 rpm)
Category, 3-Point Hitch
Category 1 Limited
Category 1
Hitch Lift Capacity (at 24”)
700 lb
700 lbs
R3 Turf - Rear
26X12.00-12
26X12.00-12
R3 Turf - Front
18X8.5-10
18X8.5-8
Tire Size & Options
Front AG. (TURF, INDUSTRIAL) 18X8.5-10; Rear AG. (TURF, INDUSTRIAL) 26X12.00-12
TractorData lists industrial tire sizes (see R4 rows); other tire options not specified.
R4 Industrial - Rear
26X12.00-12
26X12.00-12
R4 Industrial - Front
18X8.5-10
18X8.50-10
R1 Agricultural - Rear
26X12.00-12
Not Applicable
R1 Agricultural - Front
18X8.5-10
Not Applicable
Coolant Capacity
2.0 (1.9) qts (L)
Not Published
Crankcase Capacity
5.2 (4.9) qts (L)
Not Published
Fuel Tank Capacity
6.7 gal.
6.7 gal
Front Axle Fluid Capacity
NOT FOUND
0.5 gal
Transmission / Hydraulic System Capacity
NOT FOUND
3.4 gal
Loader Model
FL6
—
Loader Lift Height
71.9 in.
70.9 in
Loader Breakout Force
1554 lb.
1,435.2 lb
Quick Attach Loader System
Standard Quick Attach Mounting System
Quick-attach (QA) bucket
Loader Lift Capacity (Full Height)
608 lb.
683.4 lb
Clutch
Clutch-free (Hydrostatic)
None
No. of Speeds
2
Infinite, 2 range (High/Low)
Transmission Type
2-Range HST
HST (hydrostatic)
Max Travel Speed (Forward)
11.1 mph (17.8 km/hr.)
10.3 mph
Max Travel Speed (Reverse)
7.6 mph (12.2 km/hr.)
7 mph
Differential Lock & Limited Slip Options
Std
Rear differential lock (standard)
Brakes
Wet Multi-disc
Wet disk type
Steering
Hydrostatic Power Steering
Power steering
Frame Type
Not Published
Not Published
Front Axle Type
Not Published
Not Published
Drawbar Capacity
7.7 kN / 1730 lb
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Suspension Seat ■
Not Published
Wheelbase
55.1 in.
55.12 in
Overall Width
46.0 in.
46.65 in
Ground Clearance
6.3 in.
6.38 in
Height to Top of ROPS
87.6 in.
87.63 in
Height to Top of Cab Model
NOT FOUND — no source lists a cab-model height. The CT1021 is an open-station (two-post folding ROPS) machine; a Field Cab is a dealer-installed option only, and no cab height spec was found in any source.
Not Applicable
Height to Top of ROPS (folded)
NOT FOUND — no source explicitly lists the folded ROPS height. The only height figure available across all sources is Height (ROPS) [upright]: 87.6 in (2225 mm)
