Bad Boy Tractors 3026 vs TYM 2205

Across 7 measurable specs, the Bad Boy Tractors 3026 leads 6 categories to 1. Machine pages: Bad Boy Tractors 3026 and TYM 2205.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	Bad Boy Tractors3026	TYM2205

▶Engine
Engine Manufacturer	TYM	Yanmar
Engine Model	A1100N2	3TNM74F
Engine Type	3 cylinder, water-cooled diesel, swirl chamber, natural aspiration	Diesel, swirl chamber combustion, naturally aspirated
No. of Cylinders	3	3
Displacement	70.7 in³	60.6 in³
Rated Engine Speed	2600 rpm	3200 rpm
Engine Power (Gross)	24 hp	21.5 hp
PTO Power	18 hp	15.1 hp
Engine Emissions Constraints	Tier 4	Tier 4
Cooling System Type	Water-cooled	Liquid-cooled
Air Cleaner	Dry element	Dry element
Fuel System	Indirect injection (swirl chamber)	Indirect injection (swirl chamber)
Alternator	50 A, 12 V	40 A, 12 V
▶Hydraulics
Pump Type	Gear type pump with primary and secondary pumps	Single gear pump with flow divider
Implement Flow	4.3 gpm	4.2 gpm
Steering Flow	3.1 gpm	2.1 gpm
Total Hydraulic Flow	7.4 gpm	6.3 gpm
Overall Hydraulic Pump Flow	7.7 gpm	Not Published
Hydraulic System Type	Open center	Not Published
Rear Remote Hydraulic Flow	Not Published	Not Published
No. of Standard Remote Valves	0	Not Published
No. of Optional Remote Valves	1	2
▶Fluid Capacity
Fuel Tank Capacity	6.08 gal	Not Published
Coolant Capacity	1.21 gal	Not Published
Crankcase Capacity	0.79 gal	Not Published
Transmission / Hydraulic System Capacity	2.90 gal	Not Published
Front Axle Fluid Capacity	0.79 gal	Not Published
▶PTO & Hitch
PTO Type	Live PTO (6 spline shaft)	Independent (rear and mid)
PTO Rear	540 / 960 rpm	540 rpm
Mid-PTO Availability	Optional, 2,500 rpm	Available, 2,500 rpm
Category, 3-Point Hitch	Category I	Category I
Hitch Lift Capacity	1,433 lb	1,100 lb
Hitch Lift Capacity (at 24”)	974 lb	Not Published
Lift Control Type	Position control	Position control
▶Transmission & Drivetrain
Transmission Type	Hydrostatic (HST)	Hydrostatic (HST)
No. of Speeds	3 range (L/M/H)	Infinite (2-range HST)
Max Travel Speed (Forward)	14.8 mph	8.4 mph
Max Travel Speed (Reverse)	14.8 mph	8.4 mph
Clutch	Dry, single plate	Not Published
Differential Lock & Limited Slip Options	Mechanical rear differential lock	Mechanical rear differential lock
▶Chassis, Steering & Controls
Frame Type	Steel frame with cast iron axles	Not Published
Steering	Hydrostatic power steering	Power-assisted hydrostatic
Brakes	Wet disc	Wet, multi-disc
Seat Suspension & Adjustability	Adjustable seat, flips up and back for rear backhoe operation	Not Published
Front Axle Type	Selectable 4WD	4WD (MFWD)
Front Axle Rating	Not Published	Not Published
Drawbar Capacity	Not Published	Not Published
▶Dimensions & Maneuverability
Overall Length with 3-Point Hitch	110 in	94.2 in
Overall Width	53.9 in	44.5 in
Wheelbase	65.7 in	53.1 in
Ground Clearance	16.4 in	8.3 in
Min. Turn Radius without Brakes	Not Published	Not Published
Height to Top of ROPS	91.4 in	86.6 in
Height to Top of ROPS (folded)	Not Published	Not Published
Height to Top of Cab Model	Not Published	Not Published
▶Weight
Tractor Weight (Base)	2,107 lb	1,472 lb
Weight with ROPS and Loader	Not Published	Not Published
Weight with Cab and Loader	Not Published	Not Published
▶Tire Options
Tire Size & Options	R1 Agricultural (11.2-20 rear standard), R4 Industrial (25x8.50-14 / 14-17.5)	Turf (TURF05): 18x8.50-10 front / 26x12.00-12 rear; Industrial (IND05): 18x8.50-10 front / 26x12.00-12 rear
R1 Agricultural - Front	7-16 6PR	Not Published
R1 Agricultural - Rear	11.2-20	Not Published
R3 Turf - Front	Not Published	18x8.50-10
R3 Turf - Rear	Not Published	26x12.00-12
R4 Industrial - Front	25x8.50-14	18x8.50-10
R4 Industrial - Rear	14-17.5	26x12.00-12
▶Loader & Attachments
Quick Attach Loader System	Quick attach front loader	Not Published
Loader Model	BBL300	BL92S
Loader Lift Height	87.5 in	Not Published
Loader Lift Capacity (Full Height)	1,314 lb	BL92S: 847 lb
Loader Breakout Force	1,960 lbf	Not Published
▶Warranty
Warranty Length & Coverage	Engine and powertrain: 72 months or 2,000 hours; other tractor parts: 24 months or 1,000 hours; loader and backhoe: 24 months from shipment, 12 months from sale, or 500 hours	Not Published
▶ITC Company Accessories
Accessories that fit	Branson TYM 2510 / 2610 and select 2400 series Brush Screen Insert $249.99	None tagged yet

Find a Bad Boy dealer near you→Find a TYM dealer near you→

Bad Boy Tractors 3026 vs TYM 2205: Quick Answers

Which has more horsepower, the Bad Boy Tractors 3026 or the TYM 2205?

The Bad Boy Tractors 3026 leads on engine hp at 24 hp hp, compared to 21.5 hp hp for the TYM 2205.

Which has more PTO horsepower, the Bad Boy Tractors 3026 or the TYM 2205?

The Bad Boy Tractors 3026 leads on pto hp at 18 hp hp, compared to 15.1 hp hp for the TYM 2205.

Which is heavier, the Bad Boy Tractors 3026 or the TYM 2205?

The Bad Boy Tractors 3026 leads on weight at 2,107 lb lb, compared to 1,472 lb lb for the TYM 2205.

Which has more loader lift capacity, the Bad Boy Tractors 3026 or the TYM 2205?

The Bad Boy Tractors 3026 leads on loader lift at 1,314 lb lb, compared to 847 lb lb for the TYM 2205.

Which has more three-point hitch lift capacity, the Bad Boy Tractors 3026 or the TYM 2205?

The TYM 2205 leads on 3-pt lift (24 in) at 1,100 lb lb, compared to 974 lb lb for the Bad Boy Tractors 3026.
