Case IH Farmall 35A Mechanical vs New Holland Workmaster 35

Every published spec for both machines, side by side. The verdict below is computed straight from the spec sheets, not opinion.

Across 9 measurable specs, the New Holland Workmaster 35 leads 5 categories to 3 (1 tied). Machine pages: Case IH Farmall 35A Mechanical and New Holland Workmaster 35.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Spec	Case IH Farmall 35A Mechanical	New Holland Workmaster 35
Engine HP (hp)	35 hp	35 hp
PTO HP (hp)	▲ 31 hp	29.7 hp
Weight (lb)	3,042 lb	▲ 3,067 lb
Loader Lift (lb)	890 lb	▲ 1,500 lb
3-Pt Lift (24 in) (lb)	▲ 1,596 lb	1,433 lb
Lift Height (in)	▲ 98 in	91.5 in
Breakout Force (lbf)	1,900 lbf	▲ 2,700 lbf
Hydraulic Flow (gpm)	13.3 gpm	▲ 13.5 gpm
Travel Speed (mph)	14.2 mph	▲ 14.8 mph

The headline numbers at a glance.

Case IH Farmall 35A MechanicalNew Holland Workmaster 35

Engine HPhp

▲35 hp

PTO HPhp

▲31 hp

29.7 hp

28 hp

GearHST

Weightlb

3,042 lb

▲3,067 lb

Loader Liftlb

890 lb

▲1,500 lb

3-Pt Lift (24 in)lb

▲1,596 lb

1,433 lb

Share↓ Image 𝕏 f ✉

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	Case IHFarmall 35A Mechanical	New HollandWorkmaster 35


Engine Manufacturer	LS Mtron	LS Mtron
Engine Model	Not Published	L3C19-T5
Engine Type	3-cylinder, Tier 4 B/Final	3-cylinder, turbocharged, liquid-cooled diesel
No. of Cylinders	3	3
Displacement	114.7 in³	114.7 in³
Rated Engine Speed	2600 rpm	2600 rpm
Engine Power (Gross)	35 hp	35 hp
PTO Power	31 hp	Gear: 29.7 hp; HST: 28 hp
Engine Emissions Constraints	Tier 4	Tier 4
Cooling System Type	Not Published	Pressurized liquid with recirculating bypass
Air Cleaner	Not Published	Dual element (primary and inner safety element)
Fuel System	Not Published	High pressure common rail, ECU-controlled timing
Alternator	Not Published	70 A, 12 V

Pump Type	Not Published	Gear
Implement Flow	8.4 gpm	8.2 gpm
Steering Flow	Not Published	Gear: 4.2 gpm; HST: 5.3 gpm
Total Hydraulic Flow	13.3 gpm	Gear: 12.4 gpm; HST: 13.5 gpm
Overall Hydraulic Pump Flow	Not Published	Gear: 12.4 gpm; HST: 13.5 gpm
Hydraulic System Type	Open center	Open center
Rear Remote Hydraulic Flow	Not Published	Not Published
No. of Standard Remote Valves	0	Not Published
No. of Optional Remote Valves	3	1 or 2

Fuel Tank Capacity	12.6 gal	7.4 gal
Coolant Capacity	Not Published	7.5 qt
Crankcase Capacity	Not Published	5.8 qt
Transmission / Hydraulic System Capacity	Not Published	8.5 gal
Front Axle Fluid Capacity	Not Published	6.9 qt

PTO Type	Independent, electro-hydraulic engagement	Independent, electro-hydraulic engagement
PTO Rear	540 rpm	540 rpm
Mid-PTO Availability	Not Published	HST: Standard; Gear: Optional (2,000 rpm)
Category, 3-Point Hitch	Category I	Category I
Hitch Lift Capacity	Not Published	1,808 lb
Hitch Lift Capacity (at 24”)	1,596 lb	1,433 lb
Lift Control Type	Mechanical Draft Control (MDC)	Position control

Transmission Type	12x12 mechanical shuttle with synchro shift (dry clutch) (standard)	Gear: 12x12 synchronized shuttle; HST: 3-range hydrostatic, dual pedal
No. of Speeds	12 forward, 12 reverse	Gear: 12F/12R; HST: Infinite (3 ranges)
Max Travel Speed (Forward)	14.2 mph	Gear: 14.2 mph; HST: 14.8 mph
Max Travel Speed (Reverse)	Not Published	Gear: 13.63 mph; HST: 14.96 mph
Clutch	Dry clutch	Gear: 9.4 in single dry disc; HST: Not applicable
Differential Lock & Limited Slip Options	Mechanical differential lock	Mechanical rear differential lock

Frame Type	Not Published	Not Published
Steering	Not Published	Power steering
Brakes	Not Published	Wet, multi-disc
Seat Suspension & Adjustability	Adjustable suspension seat	Mechanical suspension seat, fore/aft adjustable, tilting
Front Axle Type	Mechanical Front Drive (MFD)	4WD
Front Axle Rating	Not Published	Not Published
Drawbar Capacity	Not Published	Not Published

Overall Width	66.5 in	66.5 in
Wheelbase	66.2 in	67.5 in
Ground Clearance	Not Published	13 in
Min. Turn Radius without Brakes	10.5 ft	123 in (left turn); 124 in (right turn)
Height to Top of ROPS	96.2 in	87.7 in
Height to Top of ROPS (folded)	74.2 in	Not Published
Height to Top of Cab Model	Not Published	Not Published
Overall Length	119.4 in	121 in

Tractor Weight (Base)	3,042 lb	3,067 lb
Weight with ROPS and Loader	Not Published	Not Published
Weight with Cab and Loader	Not Published	Not Published

Tire Size & Options	R1 Agricultural, R3 Turf, or R4 Industrial	R1 Agricultural, R3 Turf, R4 Industrial
R1 Agricultural - Front	7x14	7-14
R1 Agricultural - Rear	11.2x24	11.2-24
R3 Turf - Front	25x8.50-14	25x8.50-14
R3 Turf - Rear	41x14.00-20	41x14.00-20
R4 Industrial - Front	25x8.50-14	25x8.50-14
R4 Industrial - Rear	43x16.00-20	43x16-20

Quick Attach Loader System	Not Published	140TL: tool-free quick-mount system; optional skid-steer quick-attach plates
Loader Model	L340A	140TL
Loader Lift Height	98 in	140TL: 91.5 in (at pivot pin)
Loader Lift Capacity (Full Height)	890 lb at 31.5 in forward of pivot pin	140TL: 1,500 lb (at bucket pivot pin, max height)
Loader Breakout Force	1,900 lb	140TL: 2,700 lb (at bucket pivot pin)

Warranty Length & Coverage	Basic 2 years; powertrain 4 additional years (6-year total)	Basic 2 years or 750 hours; powertrain to 6 years or 1,500 hours total

Find a Case IH dealer near you Find a New Holland dealer near you

Case IH Farmall 35A Mechanical vs New Holland Workmaster 35: Quick Answers

Which has more horsepower, the Case IH Farmall 35A Mechanical or the New Holland Workmaster 35?: They are effectively tied: both machines are rated at 35 hp hp for engine hp.
Which has more PTO horsepower, the Case IH Farmall 35A Mechanical or the New Holland Workmaster 35?: The Case IH Farmall 35A Mechanical leads on pto hp at 31 hp hp, compared to 29.7 hp hp for the New Holland Workmaster 35.
Which is heavier, the Case IH Farmall 35A Mechanical or the New Holland Workmaster 35?: The New Holland Workmaster 35 leads on weight at 3,067 lb lb, compared to 3,042 lb lb for the Case IH Farmall 35A Mechanical.
Which has more loader lift capacity, the Case IH Farmall 35A Mechanical or the New Holland Workmaster 35?: The New Holland Workmaster 35 leads on loader lift at 1,500 lb lb, compared to 890 lb lb for the Case IH Farmall 35A Mechanical.
Which has more three-point hitch lift capacity, the Case IH Farmall 35A Mechanical or the New Holland Workmaster 35?: The Case IH Farmall 35A Mechanical leads on 3-pt lift (24 in) at 1,596 lb lb, compared to 1,433 lb lb for the New Holland Workmaster 35.

More Head-to-Heads

Case IH

Farmall 35A Mechanical

Farmall 35A Mechanical

Farmall 35A Mechanical

Farmall 35A Mechanical

Category Verdict

Spec	Case IH Farmall 35A Mechanical	New Holland Workmaster 35
Engine HP (hp)	35 hp	35 hp
PTO HP (hp)	▲ 31 hp	29.7 hp
Weight (lb)	3,042 lb	▲ 3,067 lb
Loader Lift (lb)	890 lb	▲ 1,500 lb
3-Pt Lift (24 in) (lb)	▲ 1,596 lb	1,433 lb
Lift Height (in)	▲ 98 in	91.5 in
Breakout Force (lbf)	1,900 lbf	▲ 2,700 lbf
Hydraulic Flow (gpm)	13.3 gpm	▲ 13.5 gpm
Travel Speed (mph)	14.2 mph	▲ 14.8 mph

The headline numbers at a glance.

Case IH Farmall 35A MechanicalNew Holland Workmaster 35

Engine HPhp

▲35 hp

PTO HPhp

▲31 hp

29.7 hp

28 hp

GearHST

Weightlb

3,042 lb

▲3,067 lb

Loader Liftlb

890 lb

▲1,500 lb

3-Pt Lift (24 in)lb

▲1,596 lb

1,433 lb

Share↓ Image 𝕏 f ✉

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	Case IHFarmall 35A Mechanical	New HollandWorkmaster 35


Engine Manufacturer	LS Mtron	LS Mtron
Engine Model	Not Published	L3C19-T5
Engine Type	3-cylinder, Tier 4 B/Final	3-cylinder, turbocharged, liquid-cooled diesel
No. of Cylinders	3	3
Displacement	114.7 in³	114.7 in³
Rated Engine Speed	2600 rpm	2600 rpm
Engine Power (Gross)	35 hp	35 hp
PTO Power	31 hp	Gear: 29.7 hp; HST: 28 hp
Engine Emissions Constraints	Tier 4	Tier 4
Cooling System Type	Not Published	Pressurized liquid with recirculating bypass
Air Cleaner	Not Published	Dual element (primary and inner safety element)
Fuel System	Not Published	High pressure common rail, ECU-controlled timing
Alternator	Not Published	70 A, 12 V

Pump Type	Not Published	Gear
Implement Flow	8.4 gpm	8.2 gpm
Steering Flow	Not Published	Gear: 4.2 gpm; HST: 5.3 gpm
Total Hydraulic Flow	13.3 gpm	Gear: 12.4 gpm; HST: 13.5 gpm
Overall Hydraulic Pump Flow	Not Published	Gear: 12.4 gpm; HST: 13.5 gpm
Hydraulic System Type	Open center	Open center
Rear Remote Hydraulic Flow	Not Published	Not Published
No. of Standard Remote Valves	0	Not Published
No. of Optional Remote Valves	3	1 or 2

Fuel Tank Capacity	12.6 gal	7.4 gal
Coolant Capacity	Not Published	7.5 qt
Crankcase Capacity	Not Published	5.8 qt
Transmission / Hydraulic System Capacity	Not Published	8.5 gal
Front Axle Fluid Capacity	Not Published	6.9 qt

PTO Type	Independent, electro-hydraulic engagement	Independent, electro-hydraulic engagement
PTO Rear	540 rpm	540 rpm
Mid-PTO Availability	Not Published	HST: Standard; Gear: Optional (2,000 rpm)
Category, 3-Point Hitch	Category I	Category I
Hitch Lift Capacity	Not Published	1,808 lb
Hitch Lift Capacity (at 24”)	1,596 lb	1,433 lb
Lift Control Type	Mechanical Draft Control (MDC)	Position control

Transmission Type	12x12 mechanical shuttle with synchro shift (dry clutch) (standard)	Gear: 12x12 synchronized shuttle; HST: 3-range hydrostatic, dual pedal
No. of Speeds	12 forward, 12 reverse	Gear: 12F/12R; HST: Infinite (3 ranges)
Max Travel Speed (Forward)	14.2 mph	Gear: 14.2 mph; HST: 14.8 mph
Max Travel Speed (Reverse)	Not Published	Gear: 13.63 mph; HST: 14.96 mph
Clutch	Dry clutch	Gear: 9.4 in single dry disc; HST: Not applicable
Differential Lock & Limited Slip Options	Mechanical differential lock	Mechanical rear differential lock

Frame Type	Not Published	Not Published
Steering	Not Published	Power steering
Brakes	Not Published	Wet, multi-disc
Seat Suspension & Adjustability	Adjustable suspension seat	Mechanical suspension seat, fore/aft adjustable, tilting
Front Axle Type	Mechanical Front Drive (MFD)	4WD
Front Axle Rating	Not Published	Not Published
Drawbar Capacity	Not Published	Not Published

Overall Width	66.5 in	66.5 in
Wheelbase	66.2 in	67.5 in
Ground Clearance	Not Published	13 in
Min. Turn Radius without Brakes	10.5 ft	123 in (left turn); 124 in (right turn)
Height to Top of ROPS	96.2 in	87.7 in
Height to Top of ROPS (folded)	74.2 in	Not Published
Height to Top of Cab Model	Not Published	Not Published
Overall Length	119.4 in	121 in

Tractor Weight (Base)	3,042 lb	3,067 lb
Weight with ROPS and Loader	Not Published	Not Published
Weight with Cab and Loader	Not Published	Not Published

Tire Size & Options	R1 Agricultural, R3 Turf, or R4 Industrial	R1 Agricultural, R3 Turf, R4 Industrial
R1 Agricultural - Front	7x14	7-14
R1 Agricultural - Rear	11.2x24	11.2-24
R3 Turf - Front	25x8.50-14	25x8.50-14
R3 Turf - Rear	41x14.00-20	41x14.00-20
R4 Industrial - Front	25x8.50-14	25x8.50-14
R4 Industrial - Rear	43x16.00-20	43x16-20

Quick Attach Loader System	Not Published	140TL: tool-free quick-mount system; optional skid-steer quick-attach plates
Loader Model	L340A	140TL
Loader Lift Height	98 in	140TL: 91.5 in (at pivot pin)
Loader Lift Capacity (Full Height)	890 lb at 31.5 in forward of pivot pin	140TL: 1,500 lb (at bucket pivot pin, max height)
Loader Breakout Force	1,900 lb	140TL: 2,700 lb (at bucket pivot pin)

Warranty Length & Coverage	Basic 2 years; powertrain 4 additional years (6-year total)	Basic 2 years or 750 hours; powertrain to 6 years or 1,500 hours total

Find a Case IH dealer near you Find a New Holland dealer near you

Case IH Farmall 35A Mechanical vs New Holland Workmaster 35: Quick Answers

Which has more horsepower, the Case IH Farmall 35A Mechanical or the New Holland Workmaster 35?

They are effectively tied: both machines are rated at 35 hp hp for engine hp.

Which has more PTO horsepower, the Case IH Farmall 35A Mechanical or the New Holland Workmaster 35?

The Case IH Farmall 35A Mechanical leads on pto hp at 31 hp hp, compared to 29.7 hp hp for the New Holland Workmaster 35.

Which is heavier, the Case IH Farmall 35A Mechanical or the New Holland Workmaster 35?

The New Holland Workmaster 35 leads on weight at 3,067 lb lb, compared to 3,042 lb lb for the Case IH Farmall 35A Mechanical.

Which has more loader lift capacity, the Case IH Farmall 35A Mechanical or the New Holland Workmaster 35?

The New Holland Workmaster 35 leads on loader lift at 1,500 lb lb, compared to 890 lb lb for the Case IH Farmall 35A Mechanical.

Which has more three-point hitch lift capacity, the Case IH Farmall 35A Mechanical or the New Holland Workmaster 35?

The Case IH Farmall 35A Mechanical leads on 3-pt lift (24 in) at 1,596 lb lb, compared to 1,433 lb lb for the New Holland Workmaster 35.
