TYM 3015 vs TYM T234
Every published spec for both machines, side by side. The verdict below is computed straight from the spec sheets, not opinion.
Across 9 measurable specs, the TYM 3015 leads 9 categories to 0. Machine pages: TYM 3015 and TYM T234.
Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.
Category Verdict
| Spec | TYM 3015 | TYM T234 |
|---|---|---|
| Engine HP (hp) | ▲ 30 hp | 24.4 hp |
| PTO HP (hp) | ▲ 25 hp | 18.3 hp |
| Weight (lb) | ▲ 3,183 lb | 1,907 lb |
| Loader Lift (lb) | ▲ 2,200 lb | 1,380 lb |
| 3-Pt Lift (24 in) (lb) | ▲ 2,425 lb | 1,102 lb |
| Lift Height (in) | ▲ 104.9 in | 86.9 in |
| Breakout Force (lbf) | ▲ 3,422 lbf | 2,059 lbf |
| Hydraulic Flow (gpm) | ▲ 11.9 gpm | 6.7 gpm |
| Travel Speed (mph) | ▲ 18.8 mph | 9.6 mph |
Full Spec Sheet
Every published spec, side by side, including the details the graphs above don't chart.
| Spec | TYM3015 | TYMT234 |
|---|
| Engine Manufacturer | TYM | Mitsubishi |
|---|---|---|
| Engine Model | T1700N3 | S3L2 |
| Engine Type | 3-cylinder, naturally aspirated diesel | 3-cylinder, naturally aspirated diesel |
| No. of Cylinders | 3 | 3 |
| Displacement | 104.5 in³ | 80.4 in³ |
| Rated Engine Speed | 2600 rpm | 2500 rpm |
| Engine Power (Gross) | 30 hp | 24.4 hp |
| PTO Power | 25 hp | 18.3 hp |
| Engine Emissions Constraints | Tier 4 | Tier 4 |
| Cooling System Type | Not Published | Liquid-cooled |
| Air Cleaner | Dry element | Dual dry |
| Fuel System | IDI (indirect injection) | Indirect fuel injection |
| Alternator | 50 A, 12 V | 50 A, 12 V |
TYM 3015 vs TYM T234: Quick Answers
- Which has more horsepower, the TYM 3015 or the TYM T234?
- The TYM 3015 leads on engine hp at 30 hp hp, compared to 24.4 hp hp for the TYM T234.
- Which has more PTO horsepower, the TYM 3015 or the TYM T234?
- The TYM 3015 leads on pto hp at 25 hp hp, compared to 18.3 hp hp for the TYM T234.
- Which is heavier, the TYM 3015 or the TYM T234?
- The TYM 3015 leads on weight at 3,183 lb lb, compared to 1,907 lb lb for the TYM T234.
- Which has more loader lift capacity, the TYM 3015 or the TYM T234?
- The TYM 3015 leads on loader lift at 2,200 lb lb, compared to 1,380 lb lb for the TYM T234.
- Which has more three-point hitch lift capacity, the TYM 3015 or the TYM T234?
- The TYM 3015 leads on 3-pt lift (24 in) at 2,425 lb lb, compared to 1,102 lb lb for the TYM T234.
